  • Page 1 MPS930b User’s Guide 59319501 my.okidata.com...

  • Page 2: Copyright Information

    Copyright Information ______________________________________ Copyright © 2009 by Oki Data Americas, Inc. All Rights Reserved. Document Information _____________________________________ B930 User Guide P/N 59319501, Revision 1.0 August 2009 Disclaimer _______________________________________________ Every effort has been made to ensure that the information in this document is complete, accurate, and up-to-date.
  • Page 3 OKI is not responsible for such data loss and any consequence caused by such data loss.
  • Page 4 This product is a “Class I Laser System” that does not emit dangerous laser beam. Operate the machine according to the instructions in the manual. Do not carry out any operation not mentioned in the manual. Otherwise, it may lead to unforeseen accident or machine breakdown. MPS930b User’s Guide> 4...
  • Page 5 Indicates items displayed on the computer and the printer Operator Panel. Also indicates the title of printed reports/lists from the printer. < > Indicates items such as hard buttons and indicators on the keyboard and printer. MPS930b User’s Guide> 5...
  • Page 6 Copyright material or trademarks without the consent of the owner • Postage stamps and other negotiable instruments This list is not inclusive and no liability is assumed for either its completeness or accuracy. In case of doubt, contact your legal counsel. MPS930b User’s Guide> 6...

  • Page 7: Table Of Contents

    Safety Notes ....... .40 Printer Orientation ......40 MPS930b User’s Guide> 7...
  • Page 8 Getting to Know Your Printer ....41 Front view ........41 Rear View .
  • Page 9 Creating a Shared Printer .....86 OKI LPR ....... . .87 Printing from UNIX .
  • Page 10 Error and Warning Messages ....128 Maintenance ....... . 136 Cleaning the Printer .

  • Page 11: Basic Printing Tasks

    OADING RAYS Trays 3 and 4 are pictured as the two tray feeder. The Tandem tray option is loaded in a similar manner. Pull out the Paper Tray(s). MPS930b User’s Guide> 11...
  • Page 12 Do not load paper exceeding the maximum fill line or the maximum capacity allowed. Align the right width guide with the paper width correctly. If the right width guide is not in place, the paper will not be properly fed and may cause a paper jam. MPS930b User’s Guide> 12...
  • Page 13 Slide the paper tray back into the machine. If custom sizes of paper are used, make the appropriate changes in your Printer Properties and at the Operator Panel as needed. MPS930b User’s Guide> 13...

  • Page 14: Loading Mpf (Tray 5)

    Side guides must be set accurately against the sides of paper. The printer uses the placement of these guides to calculate and verify the correct paper size. Lower the MPF tray. Adjust the paper guides to the size of the paper. MPS930b User’s Guide> 14...

  • Page 15: Loading Tray 6 Hcf

    If custom sizes of paper are used, make the appropriate changes in your Printer Properties and at the Operator Panel as needed 6 HCF OADING Pull out the tray. MPS930b User’s Guide> 15...
  • Page 16 If loading paper with a different width or length, adjust the width and length guides. Fan the paper to release sheets that may stick together. MPS930b User’s Guide> 16...

  • Page 17: Printing A Test Page

    Printer Properties. You may also enable this feature at the Operator Panel or by using the EWS. To print a test page through the driver: Select the Device Options tab within driver. Click Demo Print. Click OK. MPS930b User’s Guide> 17...

  • Page 18: Basic Printing

    So, 10 page number 1’s will print and then 10 page number 2’s will print. Collated jobs will print all pagesof the first copy and then all pages of the next. MPS930b User’s Guide> 18...

  • Page 19: Setting Orientation

    Panel or by using the EWS. To skip blank pages: Select the Paper Feed button in the Setup tab within your Printer Properties. The Paper Feed Options window appears. Select Skip Blank Pages. Click OK. Click OK. MPS930b User’s Guide> 19...

  • Page 20: Printing In Reverse Order

    To print on both sides of the paper from the your Printer Properties: Select Long-edge or Short-edge from the 2-sided printing pull-down in the Setup Tab of your Printer Properties. Select. Verify the page orientation and select the desired tray. Click OK. MPS930b User’s Guide> 20...

  • Page 21: Binding Preferences

    Toner may not fuse properly on the media, resulting in dirty and poor quality printouts. RANSPARENCIES Transparencies can be printed from any tray. They should only be printed on one side. Before printing transparencies: MPS930b User’s Guide> 21...
  • Page 22 Trays 1-4 NOTE > Do not load paper above the fill line. Adjust the paper guide to the size of the transparencies, if necessary. Change media type at Operator Panel via the Paper Menu’s Media Type selection. MPS930b User’s Guide> 22...

  • Page 23: Envelopes

    Insert the envelopes in the tray with the following considerations: • Place C4 envelopes short-edge feed in the tray. • Place Monarch, #10, C5, and DL envelopes long-edge feed in the tray. • Place the side to be printed facedown. MPS930b User’s Guide> 23...

  • Page 24: Postcards

    Loading and Printing in Tray 5 Insert the postcards in the tray with the following considerations: • Insert postcards long-edge feed and facedown. Place the top of the postcard to enter the printer first (left side of the printer) MPS930b User’s Guide> 24...

  • Page 25: Labels

    Loading and Printing Insert the postcards in the tray with the following considerations: • Tray MPF - Insert the label sheets long-edge feed and facedown. Place the top of the page toward the front of the printer. MPS930b User’s Guide> 25...
  • Page 26 Adjust the paper guides to the size of the label sheets. Change media type at Operator Panel via the Paper Menu’s Media Type selection. Select Label as the Media Type in the Media Type pulldown. Click OK. MPS930b User’s Guide> 26...

  • Page 27: Custom Size Paper

    Change media type at Operator Panel via that tray’s Media Menu option. Select the Paper Feed button in the Setup tab within your Printer Properties. The Paper Feed Options window appears. Select Custom Size. Enter the paper parameters and name. Click Add. MPS930b User’s Guide> 27...

  • Page 28: Tray Settings

    Printer Properties. You may also enable this feature at the Operator Panel or by using the EWS. To select the paper destination through your Printer Properties: Select the desired Destination from the Destination pulldown in the Setup Tab of your Printer Properties. Click OK. MPS930b User’s Guide> 28...

  • Page 29: Input Tray Linking

    Printer Properties. You may also enable this feature at the Operator Panel or by using the EWS. To select manual feed through your Printer Properties: Select the Paper Feed button in the Setup tab within your Printer Properties. The Paper Feed Options window appears. MPS930b User’s Guide> 29...

  • Page 30: Media Check

    This is called job offsetting. When selected, the output position changes after the final sheet of the print job is printed. The next job is the offset (shifted a bit) to keep it separate from the previous print job. MPS930b User’s Guide> 30...

  • Page 31: Driver Settings

    Printer Properties. Enter a Name for the saved settings. Click OK. Click OK. To use saved settings: Select the desired setting_name from the Driver Settings pulldown in the Setup tab within your Printer Properties. Click OK. MPS930b User’s Guide> 31...

  • Page 32: Using The Hole Puncher

    Select the desired Hole Punch type from the Hole Punch pulldown. Click OK. Click OK. MPTYING THE UNCH ASTE ASKET See “Jam Area Locations” on page 146 for a decsription of door locations. Open Door G. Remove the Punch Waste Box and empty the contents. MPS930b User’s Guide> 32...

  • Page 33: Using The Stapler

    The following table displays the location of the staple(s) based on the staple location selected. STAPLING ORIENTATION STAPLE PLACEMENT SELECTION Upper-left Portrait Landscape MPS930b User’s Guide> 33...
  • Page 34 STAPLING ORIENTATION STAPLE PLACEMENT SELECTION Bottom-left Portrait Landscape Dual Portrait Landscape MPS930b User’s Guide> 34...
  • Page 35 Select the desired Stapling type from the Staple pulldown. Click OK. Click OK. Adding Staples Open Door G. NOTE > See instructions on the inside of door G. Slide the stapler toward you, then to the right. MPS930b User’s Guide> 35...
  • Page 36 Remove the staple unit by lifting it up and out. If present, remove the depleted staple cartridge. Insert a new staple cartridge. Insert the staple unit into the Finisher. Close door G. MPS930b User’s Guide> 36...

  • Page 37: Cancelling/Checking Printing

    Cancelling Print Jobs at the Computer Double-click the printer icon at the bottom right of the taskbar in Windows. From the displayed window, click the document name that you wish to delete and press the Delete key. MPS930b User’s Guide> 37...

  • Page 38: About This Manual

    Consisting of two LEDs, a display, and nine function buttons, the easy-to-read Operator Panel display shows the status of printer operation. Operator Panel push buttons allow you to access and view printer menus and status messages. MPS930b User’s Guide> 38...

  • Page 39: Conventions

    WARNING! A warning message indicates the possibility of personal injury if a specific procedure is not performed exactly as described in the guide. Pay close attention to these sections and read them fully to prevent possible injury. MPS930b User’s Guide> 39...

  • Page 40: Safety Notes

    Operator Panel, and the rear of the printer is opposite the front. The left and right sides of the printer are defined as the sides to the left and right, respectively, of a person who is facing the front of the printer. MPS930b User’s Guide> 40...

  • Page 41: Getting To Know Your Printer

    Multi Purpose Feeder Tray 5 Standard top bin output tray and transport to finisher Optional 2000-Sheet Feeder (Tray 6) Optional 2x 500-sheet A3 trays (2TM) or 2000-sheet A4/Letter dual input trays (TTM) Optional 3500-Sheet Finisher (3 possible configurations) MPS930b User’s Guide> 41...

  • Page 42: Rear View

    Exit 2 is used in conjunction with duplex unit and finisher, comes with the Duplex unit. Name Parallel Port, IEEE 1284 Ethernet 10/100 BaseT connection USB 2.0 connection Serial RS232 port Ground Fault Interrupt (GFI) reset Power cord connection MPS930b User’s Guide> 42...

  • Page 43: Internal Components

    Data I/O connector settings can be configured via the Operator Panel’s Interface Menu. There are settings for Ports, Parallel Setup, USB Setup, and Serial Setup See “Operator Panel” on page 200 for a detailed description of each setting. NTERNAL OMPONENTS Name Fuser Transfer Roll MPS930b User’s Guide> 43...

  • Page 44: Turning The Printer On And Off

    Remember to turn off the printer at the end of day or when the printer will not be used for an extended period of time. NOTE > When the printer is turned off, all print data still in memory will be erased MPS930b User’s Guide> 44...

  • Page 45: Available Printer Drivers

    Printing Properties accessed from the driver. PERATOR ANEL EATURES The Operator Panel is located on the front of the printer. It contains the display, indicators, and push buttons that allow you to view and MPS930b User’s Guide> 45...

  • Page 46: Lcd Display

    The display contains two lines of text, each with a maximum of sixteen characters. MPS930b User’s Guide> 46...

  • Page 47: Led Indicators

    Menu Enter the menu system. Select Select the menu or submenu that is shown on the second line of the display or to choose and save the setting shown on the second line of the display. MPS930b User’s Guide> 47...

  • Page 48: Embedded Web Server

    Operator Panel. To change settings for specific documents, you should use your Printer Properties options within the driver. To access the embedded web server you must be on an IP-based network and have access to a web browser. MPS930b User’s Guide> 48...

  • Page 49: Driver Printer Properties

    The driver allows you to set Printer Properties when you send a print job to the printer. These changes apply to the document or program in which you are currently working. To make changes that apply to MPS930b User’s Guide> 49...
  • Page 50 To access Printer Properties from an application: Select the Print option from your program. Select the desired B930 printer. Click Printer’s Properties button. MPS930b User’s Guide> 50...
  • Page 51 The Printer Properties window appears. To access Printer Properties from Printers and Faxes (Windows): Select the Printers and Faxes from your Start menu. Right-click the desired B930 printer and select Properties. MPS930b User’s Guide> 51...
  • Page 52 The Printer’s configuration window appears. On the General Tab, click Printing Preferences MPS930b User’s Guide> 52...

  • Page 53: Paper Usage

    > Using paper that is not suitable for this printer might lead to paper jams or poor print quality. To make full use of the printer features, we suggest using only paper that is recommended here. MPS930b User’s Guide> 53...

  • Page 54: Standard Paper

    Georgia-Pacific Microprint Laser 1000 - Executive 24 Lb. (Cut) Xerox Premier 80 GSM Berga Focus, 265.101 80 GSM Xerox Business (Saillat) 80 GSM Xerox A5 80GSM Premier 80 GSM Xerox Recycled (Steinbeins) 80 GSM Stra Enso Multicopy 100 GSM MPS930b User’s Guide> 54...

  • Page 55: Special Media Types

    Monarch Envelope Transparency Letter Paper Backed Transparency Transparency Letter Xerox Removable Stripe Transparency Specialty Letter Xerox Carbonless Paper 2-Part Specialty Legal Xerox Carbonless Paper 2-Part Specialty Letter Xerox Carbonless Paper 3-Part Specialty Legal Xerox Carbonless Paper 3-Part MPS930b User’s Guide> 55...
  • Page 56 Envelope Transparency 3M Type L Desktop Laser Transparencies Transparency Xerox Type B Universal White Stripe Heavy media 160 GSM Premier 160 GSM Heavy media 200 GSM Premier 200 GSM Heavy media 160 GSM Premier A3 Paper MPS930b User’s Guide> 56...

  • Page 57: Paper Tray Capacity

    100 sheets Card stock 120 sheets 400 sheets VAILABLE APER IZES All trays but MPF have paper size sensors to detect sizes. Paper Size Paper Tray Trays 1-4 Tray 6 and (210x297 mm) Letter (8.5”× 11”) MPS930b User’s Guide> 57...
  • Page 58 Tray 6 and (182x257mm) (257x364) Legal 13 (8.5”×13”) Legal 14 (8.5”×14”) (297x420mm) Tabloid (11” ×17”) (257x182mm) Executive (7.2" X 10.5") (148x210mm) Statement (5.5"x 8.5") Those listed below are categorized as “Irregular size paper” that cannot be detected automatically MPS930b User’s Guide> 58...

  • Page 59: Unusable Paper

    Do not use them. • full-color transparencies • Paper that is too thick or thin • Paper that has been printed on before (including color printing) • Wrinkled, folded, or torn paper • Wet paper MPS930b User’s Guide> 59...

  • Page 60: System Settings

    You can set a variety of system settings via the System, Quality, and Date/Time menus in your Operator Panel. These settings control items such as power saving, display language, and resolution. For complete descriptions of these settings see “Operator Panel” on page 200. MPS930b User’s Guide> 60...

  • Page 61: Power Saver Modes

    5,825 kWh/week for the 230V printer and 5,579 kWh/week for the 110V printer. If the times to Power Save or Sleep mode are increased by the operator, the product will no longer meet the power efficiency recommended for ENERGY STAR qualification MPS930b User’s Guide> 61...

  • Page 62: Advanced Printing Tasks

    This can save paper and is handy for draft reviews. You can print one, two, four, six, nine, or sixteen pages per sheet. Enable this feature is using your Printer Properties. To select the number of pages to print on a single page: MPS930b User’s Guide> 62...

  • Page 63: Booklets

    Enable this feature is using your Printer Properties. To print a booklet: Select Booklet from the Finishing Mode pulldown in the Setup Tab of your Printer Properties. Click Options. The Booklet window appears. Enter the desired parameters. MPS930b User’s Guide> 63...
  • Page 64 You can scale any page image to fit the paper size being used. The most convenient way to enable this feature is by using your Printer Properties. You may also enable this feature at the Operator Panel or by using the EWS. To scale the print image: MPS930b User’s Guide> 64...

  • Page 65: Automatically Resize Paper

    The Watermark Window appears. Click New. The configurable fields for watermark parameters are enabled. Enter the position of the text on the page. The position anchors the left corner of the text to a specific location regardless of rotation. MPS930b User’s Guide> 65...

  • Page 66: Brightness And Contrast

    You can choose to be notified by e-mail when your job has successfully printed. The most convenient way to enable this feature is by using your Printer Properties. You may also enable this feature using the EWS. MPS930b User’s Guide> 66...

  • Page 67: Job Storage And Secure Printing

    This is temporary storage. For long-term storage you need to store the job as described in “Stored Jobs” on page 67. Enable this feature is using your Printer Properties. To create a secure job: MPS930b User’s Guide> 67...

  • Page 68: Proof Print

    Operator Panel. To create a proof print: Select the Job Options tab within your Printer Properties. Set copies to at least 2. Click Proof and Print MPS930b User’s Guide> 68...

  • Page 69: Time Specified Printing

    The delayed print feature allows you to store the data in the printer and then print it automatically at the specified time. To create a time specified job: Select the Job Options tab within your Printer Properties. MPS930b User’s Guide> 69...
  • Page 70 To delete the job, press the Cancel Button. To Print the press the Forward (right) key You are asked for the number of copies to print. Use Next to enter the number of copies. Press Select. The job is printed or deleted as instructed. MPS930b User’s Guide> 70...

  • Page 71: Direct Pdf Printing

    Enable this feature is using your Printer Properties. To create an overlay: Access your printer’s properties from your application. Select the Layout tab within your Printer Properties. Click Overlay. The Overlay Window appears. Select Create New Overlay as the Overlay Function MPS930b User’s Guide> 71...

  • Page 72: Job Accounting

    Select the Job Accounting tab within the driver. Enter the User name and Job Account ID. Click OK. The job accounting information is collected on an internal accounting file within the printer. It can then be downloaded MPS930b User’s Guide> 72...
  • Page 73 .csv file by an administrator via the printer EWS and processed off line by the users accounting application. MPS930b User’s Guide> 73...

  • Page 74: Sending Files

    The types of files that are appropriate for sending with this feature are: • Print Data files – this includes any file containing: a) Simple printable text. b) PJL/PCL5/PCL6/PS/Epson FX print-data. c) PDF (Version 1.3 and earlier) • Firmware-Upgrade Files. MPS930b User’s Guide> 74...

  • Page 75: Networking

    2003 UNIX Macintosh NOTE When using Windows 95/98/Me, use OKI LPR. UNIX Filter are required to print PostScript data. UNIX Filter is compatible with the OSs in Solaris, HPUX and Linux (Redhat, SuSE). Macintosh Supports Mac OS 10.02 or later.

  • Page 76: Configuration

    Network Summary page. Note that the password is case sensitive and letters should be entered in upper case. The following explanation uses Windows XP and Internet Explorer version 6.0 as an example to manually set the printers IP address. MPS930b User’s Guide> 76...

  • Page 77: Printing From A Windows Computer

    Although there are many variants of Windows, the principles of network printing are the same. Microsoft provides on-line help with all of their operating systems and this is a good reference point for the exact details of each configuration option within Windows. MPS930b User’s Guide> 77...

  • Page 78: Installation Of Tcp/Ip Protocol

    Windows platforms, the procedure for printing using TCP/IP is the same. Ensure that the TCP/IP protocol has been installed in Windows. This can be confirmed by checking the network settings from within the Operator Panel. If TCP/IP has not MPS930b User’s Guide> 78...
  • Page 79 Click [Start], select [Settings] and then click [Control Panel]. Double-click the [Network] icon. In the Network dialogue box, click the [Protocols] tab. If the [TCP/IP Protocol] is not listed, click [Add]. In the [Select Network Protocol] dialogue box, select [TCP/IP Protocol] and click [OK]. MPS930b User’s Guide> 79...
  • Page 80 In the [Select Network Component Type] dialogue box, select [Protocol] then click [Add]. In the [Select Network Protocol] dialogue box, select [Internet Protocol (TCP/IP)] then click [OK]. The Windows XP installation CD-ROM may be required. Follow the remaining dialogue box prompts. MPS930b User’s Guide> 80...

  • Page 81: Configuring As A Network Printer

    Ensure the appropriate printer driver has been installed in Windows. Install the Oki LPR utility as described in “OKI LPR” on page 87 of this manual and add the printer installed earlier. Windows NT 4.0 With Windows NT 4.0, you have two options for printing using TCP/...
  • Page 82 In order to use Microsoft LPR, it must first be installed on your system. OKI LPR Please follow the procedure described in the Windows 95/98/Me section in “OKI LPR” on page 87. Microsoft LPR To install this port, the following needs to be carried out: MPS930b User’s Guide> 82...
  • Page 83 IP address is entered, the Port Name will default to IP_172.168.1.31. Select [Next]. Additional port information will be required. Under [Device Type], select [Custom] then [Settings]. Ensure [Protocol] is set to [Raw]. Ensure [Port Number] is 9100 and [SNMP Status Enabled] is deselected. MPS930b User’s Guide> 83...
  • Page 84 In order to use Microsoft LPR, it must first be installed on your system. OKI LPR Please follow the procedure described in the Windows 95/98/Me in “OKI LPR” on page 87. Microsoft LPR To install this port, the following needs to be carried out: Select [Start].[Settings].[Control Panel].[Printers and Other Hardware].
  • Page 85 IP address is entered, the Port Name will default to IP_172.168.1.31. Click [Next]. [Additional Port Information Required] is displayed. Under [Device Type], select [Custom] then [Settings]. Ensure [Protocol] is set to [Raw]. Ensure [Port Number] is 9100 and [SNMP Status Enabled] is deselected. MPS930b User’s Guide> 85...

  • Page 86: Creating A Shared Printer

    Install the printer driver according to the on-screen instructions. Select [Network Printer] for the printer connection, then specify the shared printer created on Windows NT 4.0/Windows 2000/Windows XP/Windows Server 2003 in the previous section. MPS930b User’s Guide> 86...

  • Page 87: Oki Lpr

    Check [Yes, I want to launch OKI LPR Utility now] and click [Finish]. Check [Yes, I want to view the ReadMe File] if you want to read the Readme file. The OKI LPR utility starts. MPS930b User’s Guide> 87...

  • Page 88: Printing From Unix

    Refer to the On-Line Help for information on how to use the utility. UNINSTALL Stop the OKI LPR Utility. Right-click the OKI LPR icon in the system tray and click [Exit]. Select Start>Program>Okidata>OKI LPR Utility>Uninstall...
  • Page 89 Use the printer Operator Panel or the EWS to set the LPD port to [Enable] (default: [Enable]). NOTE > Before activating the LPD port, set the IP address of the printer. For details on how to set the IP address and the port, refer Printer Configuration. MPS930b User’s Guide> 89...

  • Page 90: Setting Up The Workstation

    1. Registering a printer (printer name: P001) supporting the PostScript language #lpadmin -p P001 -s printer1\!PS 2. Registering a printer (printer name: P002) supporting the PostScript language that feeds paper from an A4-size paper tray for duplex printing #lpadmin -p P002 -s printer1\!PS A4_DUP MPS930b User’s Guide> 90...

  • Page 91: Command Format

    OMMAND PTIONS The following command options are available: -d Printer name Specify the printer name registered by the "lpadmin" command as the -d option. If this option is omitted, the default printer lp will be specified. MPS930b User’s Guide> 91...

  • Page 92: Command Options

    $lp -d P001 -n3 file1 file2 Delete (Cancel) This cancel command is used to delete print data which has been sent to print. Command Format cancel [Printer name] [Job Number] OMMAND PTIONS The following command options are available: MPS930b User’s Guide> 92...

  • Page 93: Job Number

    When a command to delete print data is received, the file concerned will be deleted even if it is in the process of being printed. Only the print data available prior to file deletion will be printed. MPS930b User’s Guide> 93...

  • Page 94: Inquiry (Lpstat)

    " ". E.g. %lpstat -u "user1,user2,user3" -o [Printer name] This option displays the print data received. The printer name is specified in the argument. This option displays all the information. MPS930b User’s Guide> 94...

  • Page 95: C Option (Lpr Command)

    Also, when specifying the PostScript logical printer as a default printer on Unix, it is recommended not to user the -C option by "lpr" command. Function The following items can be set up by using the -C option: MPS930b User’s Guide> 95...
  • Page 96 > If the print data specifies a paper tray, the tray specification by the data becomes valid and that by the -C option becomes invalid. MPS930b User’s Guide> 96...
  • Page 97 Selects Heavy weight paper 1. PT2/pt2 Selects Heavy weight paper 2. POH/poh Selects Transparency. PRC/prc Selects Recycled paper. Specifying 2 sided Printing The following parameters can be specified: PARAMETER DESCRIPTION DUP/dup 2 sided printing as follows: MPS930b User’s Guide> 97...
  • Page 98 2 sided printing on 85 paper and long- side binding B5T/b5t 2 sided printing on B5 paper and short- side binding NOTE > If several parameters are specified in one "lpr" command, data may not be printed correctly. MPS930b User’s Guide> 98...
  • Page 99 > For some print language, the specification may be invalid. > The system default is used if no parameter is specified. > The color setting is not available on this printer. MPS930b User’s Guide> 99...

  • Page 100: Printing

    Mac OS 10.2 and up Setup Procedure The setting procedure is as follows: Use the printer Operator Panel or EWS to set the following port to [Enable]. > The EWS allows more detailed settings. Setting up the Macintosh MPS930b User’s Guide> 100...

  • Page 101: Snmp Support

    SNMP S UPPORT The printer can be managed via a standard SNMP management station. The printer supports SNMP-v1, SNMP-v2c, MIB-II, Host Resources MIB, Printer MIB and OKI Data Private MIB. RECAUTIONS AND LIMITATIONS TCP/IP SING This section explains the precautions and limitations of using this printer with TCP/IP.

  • Page 102: Printing From Windows

    In the spool mode, up to 32 files can be printed by one command. Files that come after the 32nd file will be ignored. An instruction with more than 32 files will be treated by the printer as a print request of up to 32 files. MPS930b User’s Guide> 102...
  • Page 103 • Print data which is in the process of printing may not be deleted. Inquiry • Long file names will be truncated. • Up to 64 print instructions can be displayed. MPS930b User’s Guide> 103...
  • Page 104 Make sure the printer is free of all spooled data and switch off/on the printer. NOTE • The function to stop/eject print data spooled to the printer spool can be operated from the printer Operator Panel. MPS930b User’s Guide> 104...

  • Page 105: Installing Consumables

    Access to a live machine’s interior can cause electric shock. NSTALLING THE ARTRIDGE Drum Cartridge OKI Part # 56120801 When installing the Drum Cartridge, take note of the following points: • Do not subject it to direct sunlight or strong light.
  • Page 106 Open the printer front and side covers. Remove the Drum Cartridge from the packing. Remove the protective sheet from the Drum Cartridge. MPS930b User’s Guide> 106...
  • Page 107 Avoid contact with internal surfaces and limit exposure to light for no longer than 5 minutes. Avoid contact with fingers. Fold the handle down and slide the Drum Cartridge into the printer. MPS930b User’s Guide> 107...
  • Page 108 Seat the Drum Cartridge firmly into the printer. Remove and discard the protective strip. Close the printer covers. MPS930b User’s Guide> 108...

  • Page 109: Installing The Toner Cartridge

    NSTALLING THE ONER ARTRIDGE Toner Cartridge, (30K life), OKI Part#..52117101 When installing the Toner Cartridge, take note of the following points: WARNING > Never throw a Toner Cartridge into an open flame. It could cause an explosion and you can get burned.
  • Page 110 Remove the Toner Cartridge from its packing. Take the Toner Cartridge out of the box and shake it 8 to 10 times as shown in the diagram. MPS930b User’s Guide> 110...
  • Page 111 Slide the Toner Cartridge into the printer and seat firmly in place. Close the printer covers. MPS930b User’s Guide> 111...

  • Page 112: Troubleshooting

    Hardware or software failures that may require service support are presented as fatal errors. When the printer’s Operator Panel displays a fatal error message a fatal error message replaces the status lines MPS930b User’s Guide> 112...

  • Page 113: Poor Print Quality

    - If the Configuration Page is blank, replace the drum cartridge then reprint the Configuration Page. If the Configuration Page still is blank, contact technical support MPS930b User’s Guide> 113...
  • Page 114 2. The drum cartridge 3. Replace the transfer may be defective or at roller (in the the end of its life. maintenance kit). 3. The transfer roller may be defective. MPS930b User’s Guide> 114...
  • Page 115 2. Replace the drum 3. The fuser may be cartridge. defective. 3. Replace the fuser (in 4. The transfer roller may the maintenance kit). be defective. 4. Replace the transfer roller (in the maintenance kit). MPS930b User’s Guide> 115...
  • Page 116 2. Replace the paper. poor condition. 3. Replace the paper. 3. The paper may be 4. Replace the fuser damp. (contained in the 4. The fuser may be at maintenance kit). the end of its life. MPS930b User’s Guide> 116...
  • Page 117 Areas of the print are poor condition. 2. Replace the paper. extremely light or missing. 2. The paper may be 3. Replace the drum damp. cartridge. 3. The drum cartridge may be defective or at the end of its life. MPS930b User’s Guide> 117...

  • Page 118: No Power

    Is there any message Check the message, then displayed on the control carry out the action. panel? Is there any message Check the message, then displayed in the carry out the action. computer? MPS930b User’s Guide> 118...

  • Page 119: Printing Is Not Clear

    Place the printer on a flat location? stable surface. Are the paper tray guides Set the length guide and set in the correct width guide in the correct positions? positions. Did you print any picture Clean the feed roll. postcards? MPS930b User’s Guide> 119...

  • Page 120: Noise

    Technical Support. ETWORK ROUBLESHOOTING USING TCP/IP This section provides information on the possible causes, verifying methods and recommended actions pertaining to errors which may occur when the printer is used with TCP/IP. MPS930b User’s Guide> 120...
  • Page 121 Select [Properties] from the menu displayed and check the free space available. Action After erasing unnecessary files to increase the free space available, select [Pause Printing] from the [Document] menu of the printer window to enable printing to restart MPS930b User’s Guide> 121...

  • Page 122: Using Windowsnt 4.0/2000/Xp/Vista/Server 2003

    If a printer driver from another company is been selected. another maker is used, the printer may used) not print properly. MPS930b User’s Guide> 122...

  • Page 123: When Using Unix

    An irrecoverable Check the error Switch off the printer, then switch it on error has occurred message on the again. during print. printer Operator Panel. MPS930b User’s Guide> 123...

  • Page 124: Unable To Obtain The Desired Print Results

    Specify the print language consistent language and the print language with that used in the print data. print language specified is the used in the print print language data are different. used in the print data. MPS930b User’s Guide> 124...

  • Page 125: Using Ethertalk

    Chooser. Action 2 If garbled characters are still printed after the printer driver for the printer has been selected, contact service. If a printer driver of another maker is used, the printer may not print properly. MPS930b User’s Guide> 125...
  • Page 126 [Enable] and that the Start/ Stop setting is set to [Start]. Check whether Off-line is displayed on the printer Operator Panel. Action 2 If the printer still cannot be connected although all the above conditions are normal, contact service. MPS930b User’s Guide> 126...
  • Page 127 “Please reboot Cause The AppleTalk function of the printer has printer” is failed. displayed on the printer Operator Verification Switch off the printer, then switch it on Panel. again. Action If Please reboot printer still appears on MPS930b User’s Guide> 127...

  • Page 128: Error And Warning Messages

    3-1 through 3-6 Paper Jam Fuser Area Jam Clear Area A 4-1 Paper Jam Exit Area Jam Clear Area A 4-3 Paper Jam Exit Area Jam Clear Area A/E 4-5 Paper Jam Exit Area Jam Clear Area A MPS930b User’s Guide> 128...
  • Page 129 4-1 Feed Error Paper Tray Area - Misfeed Jam Clear Area B/C 4-2 Feed Error Paper Tray Area - Misfeed Jam Clear Area B/C 4-3 Feed Error Paper Tray Area - Misfeed Jam Clear Area B MPS930b User’s Guide> 129...
  • Page 130 Clear Area G 4-47 Finish Jam Finisher Jam (Buffer Path sensor) Clear Area G 4-48 Finish Jam Finisher Jam (Buffer Path sensor) Clear Area G 4-51 through 4-56 Finish Jam Finisher Jam (Compile Exit sensor) Clear Area G MPS930b User’s Guide> 130...
  • Page 131 1-4 Tray Error Tray 4 Faulty Check Tray 4 1-3 Tray Error Tray 3 Faulty Check Tray 3 1-2 Tray Error Tray 2 Faulty Check Tray 2 1-1 Tray Error Tray 1 Faulty Check Tray 1 MPS930b User’s Guide> 131...
  • Page 132 Staple Cart Staple Pin Misfeed. Check Stapler Staple Suply Low Staple Pin Warning. Add Staples Stacker Full Stacker Tray is in "Paper Full' state. Remove Paper 5-11 FIN Error Mechanical failure in Stacker Tray Call Service MPS930b User’s Guide> 132...
  • Page 133 TM Non Volatile Memory Device ERROR Call Service 7-3 TM Error TM Non Volatile Memory BCD ERROR Call Service 7-8 TM Error TM MODEL ERROR Call Service 3-1 OCT1 Error OCT1 ERROR Call Service 3-2 OCT2 Error OCT2 ERROR Call Service MPS930b User’s Guide> 133...
  • Page 134 Drum EOL nearby DRUM warning 8-2 EP Cartridge Toner Cartridge (CRUM) NV Read/Write Error Replace EP Cart 8-3 EP Cartridge Toner Cartridge Communication failure Replace EP Cart 8-1 EP Cartridge Toner Cartidge Type Mismatch ID Mismatch MPS930b User’s Guide> 134...
  • Page 135 Tray 4 Missing Tray 5 Missing HCF Missing 5-4 FIN Error FINISHER Non Volatile Memory Device ERROR Call Service 5-8 FIN Error FINISHER MODEL ERROR Call Service 6-4 HCF Error HCF Non Volatile Memory Device ERROR Call Service MPS930b User’s Guide> 135...

  • Page 136: Maintenance

    Never use cleaning agents other than neutral detergent. LEANING THE INTERIOR After clearing paper jams or replacing the Toner Cartridge, inspect the interior of the printer before closing the top cover CAUTION MPS930b User’s Guide> 136...

  • Page 137: When Not In Use For A Long Time

    Refer to “Installing Accessories” on page 170 for details on uninstalling the optional accessories. > When lifting the printer, there should be 2 persons, one in front and one behind the printer, to firmly grip the MPS930b User’s Guide> 137...
  • Page 138 Never touch a power cord with wet hands. Danger of electric shock exists. When unplugging the machine, grasp the plug instead of the cord. Forcibly pulling on a cord can damage it and cause fire or electric shock. MPS930b User’s Guide> 138...
  • Page 139 Remove any paper in the MPF Tray (1). Pull out the remaining paper trays and remove any paper. Keep the paper wrapped and away from humidity and dirt. MPS930b User’s Guide> 139...
  • Page 140 Hold the Drum Cartridge by the grip to pull it out slowly. NOTE > It is necessary to remove the Toner Cartridge. If you move the printer with the Toner Cartridge installed, the toner may spill in the interior of the printer. MPS930b User’s Guide> 140...
  • Page 141 The toner will spill. > After removing the Toner Cartridge, put it into its original aluminum bag or wrap it with a thick cloth. Close the front cover and side covers securely. MPS930b User’s Guide> 141...

  • Page 142: Fuser Unit

    Access to a live machine’s interior can cause electric shock. EPLACING THE USER Switch off the power of the printer and leave it for 30 minutes until the fuser unit cools down. MPS930b User’s Guide> 142...
  • Page 143 Pull the Fuser toward you by holding the two handles. Fuser Unpack the new from its container. Carefully insert the Fuser by holding the two handles. Secure the Fuser by tightening the two knobs. Close the door. Switch the printer power on. MPS930b User’s Guide> 143...

  • Page 144: Transfer Roll Cartridge

    When the message to replace the transfer roll cartridge appears, replace the transfer roll cartridge. Otherwise, the printer will not continue to print. EPLACING THE RANSFER ARTRIDGE Switch off the power of the printer. Open the printer left side door. MPS930b User’s Guide> 144...

  • Page 145: Maintenance Kit

    Run sample prints to verify correct operation. AINTENANCE A Maintenance kit is required every 300,000 pages. It consists of: • Fuser Unit • Transfer Roller • Paper Feed Rollers Contact your service department to install the kit when the panel requests it. MPS930b User’s Guide> 145...

  • Page 146: Clearing Paper Jams

    Use caution; some components inside doors may be hot. NOTE > Paper jams could be due to the printer installation environment and type of paper used. OCATIONS AM AT Follow these steps to clear the jam MPS930b User’s Guide> 146...
  • Page 147 Open Door A. Pull the jammed paper out of the printer. If necessary, press the green handle to move the paper to make it easier to remove. Confirm that all paper fragments are removed. MPS930b User’s Guide> 147...

  • Page 148: Jam Atb

    Close Door A. AM AT Follow these steps to clear the jam. If the printer has the 2000-Sheet Feeder (Tray 6), slide the feeder away from the printer. MPS930b User’s Guide> 148...
  • Page 149 Open Door B. Pull the jammed paper out of the printer. Confirm that all paper fragments are removed. MPS930b User’s Guide> 149...

  • Page 150: Jam Atc

    Close Door B. If the printer has the 2000-Sheet Feeder (Tray 6), slide the feeder firmly against the printer. AM AT Follow these steps to clear the jam. MPS930b User’s Guide> 150...
  • Page 151 If the printer has the 2000-Sheet Feeder (Tray 6), slide the feeder away from the printer. Open Door C. MPS930b User’s Guide> 151...
  • Page 152 Pull the jammed paper out of the printer. Confirm that all paper fragments are removed. Close Door C. MPS930b User’s Guide> 152...

  • Page 153: Jam Atd

    If the printer has the 2000-Sheet Feeder (Tray 6), slide the feeder firmly against the printer. AM AT Follow these steps to clear the jam. Open Door D. MPS930b User’s Guide> 153...

  • Page 154: Jam Ate

    Pull the jammed paper out of the printer. Confirm that all paper fragments are removed. Close Door D. AM AT Follow these steps to clear the jam. MPS930b User’s Guide> 154...
  • Page 155 Open Door A. Open Door E. MPS930b User’s Guide> 155...
  • Page 156 Pull the jammed paper out of the printer. Confirm that all paper fragments are removed. Close Door E. MPS930b User’s Guide> 156...

  • Page 157: Jam Atf

    Close Door A. AM AT Follow these steps to clear the jam. Open Door F. MPS930b User’s Guide> 157...

  • Page 158: Jam Atg

    Pull the jammed paper out of the printer. Confirm that all paper fragments are removed. Close Door F. AM AT Follow these steps to clear the jam. MPS930b User’s Guide> 158...
  • Page 159 2a, handle 2b, or handle 3 as shown on the instruction labels. NOTE > If the stapler is in the way, slide the stapler toward you then to the right. If you opened handle 2a or handle 2b, rotate knob 2c counter clockwise as needed. MPS930b User’s Guide> 159...

  • Page 160: Jam Ath

    Pull the jammed paper out of the printer. Confirm that all paper fragments are removed. Close the handles opened in Step 3. Close Door G. AM AT Follow these steps to clear the jam. Lift Door H. MPS930b User’s Guide> 160...

  • Page 161: Jam At The Stacker Upper Tray

    Pull the jammed paper out of the printer. Confirm that all paper fragments are removed. Close Door H. AM AT THE TACKER PPER Follow these steps to clear the jam. Pull the jammed paper out of the stacker upper tray. MPS930b User’s Guide> 161...
  • Page 162 Open Door G. Close Door G. MPS930b User’s Guide> 162...

  • Page 163: Paper Jam In Tray 5 (Mpf)

    OK button. If the paper size shown on the Operator Panel does not match the size of the paper in the tray, change it to match. Open Door A. MPS930b User’s Guide> 163...

  • Page 164: Paper Jams In Trays 1-4

    Confirm that all paper fragments are removed. Close Door A. APER AMS IN RAYS Follow these steps to clear the paper jam in Trays 1-4. MPS930b User’s Guide> 164...
  • Page 165 Pull out the tray specified on the Operator Panel. Verify that the length and width guides are pressed against the paper. Push the tray completely into the printer. Specify the size of the paper in the Operator Panel. MPS930b User’s Guide> 165...
  • Page 166 Open Door A. Pull the jammed paper out of the printer. If necessary, press the green handle to move the paper to make it easier to remove. Confirm that all paper fragments are removed. MPS930b User’s Guide> 166...

  • Page 167: Paper Jam In Tray 6

    Close Door A. APER AM IN Follow these steps to clear the paper jam in Tray 6. Pull out Tray 6. Verify that the length and width guides are set correctly MPS930b User’s Guide> 167...
  • Page 168 The default setting is for 8.5 x 11 in. paper. You must change the guides for A4 paper. Push the tray completely into the printer. Specify the size of the paper in the Operator Panel. Open Door A. MPS930b User’s Guide> 168...
  • Page 169 Pull the jammed paper out of the printer. If necessary, press the green handle to move the paper to make it easier to remove. Confirm that all paper fragments are removed. Close Door A. MPS930b User’s Guide> 169...

  • Page 170: Installing Accessories

    Unpack the carton and confirm that the part numbers of the Duplex Transport and all components are correct. Ensure that all components are undamaged. NSTALLING THE UPLEX ODULE You can install an optional duplex module to this printer. MPS930b User’s Guide> 170...
  • Page 171 Unpack the Option Duplex, remove cushioning materials, and confirm that all attachments are available. Open Printer door A. MPS930b User’s Guide> 171...
  • Page 172 Remove cover and save for possible reuse. Slide the Exit 2 Module into position. MPS930b User’s Guide> 172...
  • Page 173 Close printer door A. Place the Duplex Unit in position while inserting the 2 hooks on the bottom of the unit into the shown locations in the receptors of the printer. MPS930b User’s Guide> 173...
  • Page 174 Lift the Duplex Unit until the upper hooks are latched in the printer. Open the Duplex Unit cover by lifting latch D. MPS930b User’s Guide> 174...
  • Page 175 Twist the 2 locking screws clockwise to secure the Duplex Unit to the printer. Close the Duplex Unit cover. MPS930b User’s Guide> 175...

  • Page 176: 1000 Sheet Feeder Or Tandem Tray Module

    (2) and replace the printer access cover (3). Connect the power cord. Turn on the power switch of the laser printer. Try some test duplex-printings to confirm that there is no problem. 1000 S HEET EEDER OR ANDEM ODULE MPS930b User’s Guide> 176...
  • Page 177 Place the Paper Feeder in an installation location. Fit the holes on the bottom of the laser printer with the four positioning bosses of the Paper Feeder, and place the laser printer on the Paper Feeder. MPS930b User’s Guide> 177...
  • Page 178 Remove the packing tape from the Paper Feeder. Slide out the 2 drawers. MPS930b User’s Guide> 178...
  • Page 179 Remove all packing materials from both drawers. Slide both drawers back into the Paper Feeder. Remove printer drawer 3. MPS930b User’s Guide> 179...
  • Page 180 Insert the 2 locking screws, turning clockwise to secure the printer to the Feeder. Replace drawer 3 back in the printer. MPS930b User’s Guide> 180...

  • Page 181: 2000 Sheet High Capacity Feeder

    1000 Sheet Feeder Interface Connector (2) and replace the printer Interface Panel Cover (3). Connect the power cord. Turn on the power switch of the laser printer. 2000 S HEET APACITY EEDER Switch OFF the printer power. Remove the power cord from the printer. MPS930b User’s Guide> 181...
  • Page 182 Unpack the Paper Feeder and remove cushioning materials. Slide the drawer out of the Paper Feeder. MPS930b User’s Guide> 182...
  • Page 183 Remove the packing material from the feeder drawer. Slide the drawer back into the feeder. Install the mounting bracket. MPS930b User’s Guide> 183...
  • Page 184 Slide the 2000 Sheet Feeder to the mounting plate guiding it on the locating pin until it latches. Remove the shipping hardware and discard. Adjust the feet on the feeder assembly to set the feeder position parallel to the printer. MPS930b User’s Guide> 184...
  • Page 185 Connect the feeder power cord into the printer accessory outlet. Slide the drawer out of the feeder. Remove the shipping screws. MPS930b User’s Guide> 185...

  • Page 186: 3500 Sheet Finisher

    The finisher provides a main 3000 sheet lower stacker and a top 500 sheet stacker. It also provides a stapler for up to 50 sheets of standard paper and a hole punch. In Europe the punch has a 2 hole MPS930b User’s Guide> 186...
  • Page 187 4 hole capability while in the Americas, the punch is a 3 hole punch Switch OFF the printer power. Remove the power cord from the printer. Unpack the Horizontal Transport and position on top of the printer. MPS930b User’s Guide> 187...
  • Page 188 When installing the Horizontal Transport this guide needs to be moved from the body of the printer up to the Exit 2 module included with the duplex. Place the mounting bracket in position. MPS930b User’s Guide> 188...
  • Page 189 Insert the 2 mounting screws to secure the bracket. Remove all the packing materials from the Finisher. MPS930b User’s Guide> 189...
  • Page 190 Slide the Finisher into position engaging the latching hardware Insert the Stacker Lower catch tray. MPS930b User’s Guide> 190...
  • Page 191 Remove the access cover and plug in the Finisher interface cable. Remove the printer interface cover. Connect the interface connector and replace the cover. MPS930b User’s Guide> 191...
  • Page 192 Connect Finisher power cord to the printer accessory power connection. Level the Finisher making it parallel to the printer. MPS930b User’s Guide> 192...
  • Page 193 Open the Finisher door. Remove the internal tags and shipping brackets. MPS930b User’s Guide> 193...
  • Page 194 Move the catch to the right. Insert the staple module MPS930b User’s Guide> 194...
  • Page 195 Unpack the paper punch waste container. Insert the punch waste Dust container MPS930b User’s Guide> 195...

  • Page 196: Hard Disk Option

    Carefully review the safety precautions in the front of this guide before starting this installation procedure. Ensure that the printer power switch is set to the OFF [O] position. Disconnect the power cord from the printer. MPS930b User’s Guide> 196...
  • Page 197 Turn thumbscrews on controller assembly counter clockwise until loose and gently pull cover towards you to remove from printer. Carefully insert the Hard Drive into the socket, being careful not to damage the fragile pins. NEW GRAPHIC MPS930b User’s Guide> 197...

  • Page 198: Installing The Memory Option And Compact Flash

    ON [I] position. NSTALLING THE EMORY PTION AND OMPACT LASH Ensure that the printer power switch is set to the OFF [O] position. Disconnect the power cord from the printer. Remove side cover from printer. MPS930b User’s Guide> 198...
  • Page 199 RAM module. The Compact Flash is inserted in a similar manner. Reinstall the side covers in reverse order. Connect the power cord to the wall outlet. Turn the printer power switch to the ON [I] position. MPS930b User’s Guide> 199...

  • Page 200: Operator Panel

    Set the number of copies printed Duplex Enable duplex printing Duplex Binding Long Edge Choose the bind edge during duplex printing Paper Feed Tray 1 Select default paper source tray Default Orientation Portrait Set print orientation MPS930b User’s Guide> 200...
  • Page 201 Use less toner. 10 pt characters print legibly, but 8 pt characters do not. Output Tray Face Down Output paper tray Tray Output Linking Hole Punch Staple Mode White Page Skip Disable Enable skipping of blank pages Job Offset MPS930b User’s Guide> 201...
  • Page 202 Tray 2 Paper Size Letter Set the media size Tray 3 Paper Size use custom Set the media size Tray 4 Paper Size use custom Set the media size Tray 1 Media Type Plain Set the media type MPS930b User’s Guide> 202...
  • Page 203 Set the paper length (279mm) Tray 4 X Dimension 8.5 in Set the paper width (216 mm) Tray 4 Y Dimension 11.00 in Set the paper length (279mm) Tray 5 X Dimension 279mm Set the paper width MPS930b User’s Guide> 203...
  • Page 204 Font Pitch Default font pitch CR Function CR+LF LF Function Printer action on line feed A4 Print Width 78 Columns Default A4 width Print Area Normal Print boundaries FX Emulation Character Pitch 10 cpi Default font pitch MPS930b User’s Guide> 204...
  • Page 205 PS Protocol ASCII PS Protocol Serial Menu Serial Enable Enable Disable Communications Baud-Rate 9600 Serial baud rate Data Bits Serial data bits Stop Bits Serial stop bits Parity None Serial parity DTR Ready/Busy Serial Signal MPS930b User’s Guide> 205...
  • Page 206 Reset Job Accounting Info Spooling Start Spooling Enable Enable spooling to Flash spooling to or Hard drive Flash or Hard drive Stop Spooling Disable Disable spooling spooling Playback Print Print selected spool file selected spool file MPS930b User’s Guide> 206...
  • Page 207 Set by user or DHCP Subnet (Mask) Specified Set by user or DHCP Gateway Address Specified Set by user or DHCP Host Name Set IP Auto/Manually Automatic Enable DHCP Bonjour Rondezvous mDNS mDNS Host Name mDNS Service Name MPS930b User’s Guide> 207...
  • Page 208 Remote Printer Number EtherTalk Enable EtherTalk Zone Name EtherTalk Printer Name Email SMTP Send SMTP Server Name Printer Email Address Alert Settings Options SNMP Enable Enable SNMP server Select Version Disable SNMP Read Community SNMP Write community MPS930b User’s Guide> 208...
  • Page 209 Print media info and directory Disk Summary Execute Print media info and directory Format Disk Execute Format media Data Security Overwrite delete data with random data FLASH Menu Directories Delete Selected File Delete file Print Selected File Print file MPS930b User’s Guide> 209...
  • Page 210 User Flash Hard Drive Compact Flash Panel Lockout Panel Enable/Disable Password Configuration New Password Maintenance Reset /Restore Execute Reset menu to default Reset Printer Execute Reset menu to default Reset Network Card Execute Reset menu to default MPS930b User’s Guide> 210...
  • Page 211 Paper supply level level Tray 6 Level Current Paper supply level level Links Support Links Tray 4 Level Driver Download Technical Support Order Consumables Register Printer Download Firmware Other Link (1-5) Edit Links Send File Select File MPS930b User’s Guide> 211...

Table of Contents
