Page 1 Planning Guide hp surestore director fc-64...
Page 3 hp surestore director fc-64 Planning Guide Edition E0102 Order No. A6534-90903 Printed in U.S.A.
Page 4: Safety Instructions
Hewlett-Packard shall not be liable for errors Whenever it is likely that the protection has been contained herein or for incidental or consequential...
Page 5: Table Of Contents
CONTENTS 1 Introduction Overview ............. . 2 Director Overview.
Page 6 Storage and Shipping Environment ........25 Operating Environment .
Page 7 HP EFC Server, LAN, and Remote Access Support ......61 HP EFC Server............61 Remote User Workstations .
Page 8 Task 15: Plan a Multiswitch Fabric (Optional) ......107 Task 16: Plan Zone Sets for Multiple Directors (Optional) ....108 Task 17: Complete Planning Checklists.
Page 9 L..............139 M .
Page 10 viii...
Page 11 FIGURES 1 Rack-Mount Directors and HP EFC Server ........3 2 Out-of-Band Director Management .
Page 13 TABLES 1 Types of User Rights ............66 2 ISL Transfer Rate Versus Fabric Port Availability (Two-Director Fabric).
Page 15: Introduction
INTRODUCTION Overview Director Overview Director Features...
Page 16: Overview
Overview This chapter introduces storage area network (SAN) and Fibre Channel technologies, provides an overview of the HP Surestore Director FC-64, and describes the director’s capabilities and features. The 64-port director provides dynamic switched connections between Fibre Channel servers and devices in a SAN environment. Switches are managed and controlled through: •...
Page 17 Figure 1 Rack-Mount Directors and HP EFC Server The director supports mainframe and open-systems interconnection (OSI) computing environments and provides data transmission and flow control between device node ports (N_Ports) as dictated by the Fibre Channel Physical and Signaling Interface (FC-PH 4.3). The director provides dynamic switched connections for servers and devices manufactured by multiple original equipment manufacturers (OEMs).
Page 18: Director Overview
Director Overview The HP Surestore Director FC-64 provides high-performance port connections to end devices such as servers, mass storage devices, and other peripherals in a Fibre Channel switched network. Up to 64 Fibre Channel connections are provided through generic ports (G_Ports).
Page 19 • Low latency The latency is less than two microseconds between transmission of a frame at a source port to receipt of the frame at the corresponding destination port (with no port contention). • Local control Actions taking place at a device N_Port seldom affect operation of other ports, therefore servers need to maintain little or no information about other connected devices in a SAN.
Page 20 – An arbitrated loop topology connects multiple device node loop ports (NL_Ports) in a loop (or hub) configuration without benefit of a multiswitch fabric. Although the director does not support direct connection of arbitrated loop devices, such devices can communicate with the director through heterogeneous Fibre Channel devices. Contact your local HP sales office for supported devices.
Page 21: Director Management
Director Management Management access to the director is provided through an Ethernet LAN connection to the director’s control processor (CTP) card (out-of-band management). A LAN connection is required for each director. The following out-of-band management access methods are provided: • Management through the Enterprise Fabric Connectivity Manager (HP EFC Manager), and Product Manager applications.
Page 22 Figure 2 illustrates out-of-band director management. Figure 2 Out-of-Band Director Management Director Overview...
Page 23: Director Features
Director Features In addition to performance features and out-of-band management, the director provides: • High-availability features. • Connectivity features. • Security features. • Serviceability features. High-Availability Features Pairs of critical field-replaceable units (FRUs) installed in the director provide redundancy in case a FRU fails. When an active FRU fails, the backup FRU takes over operation automatically (failover) to maintain director and Fibre Channel link operation.
Page 24: Connectivity Features
• Power supplies The director contains two power supplies that share the electrical operating load. If one power supply fails, the other supply handles the full load. Separate receptacles at the rear of the director provide facility input power to each supply. For full redundancy, input power for each receptacle should come from a different source.
Page 25: Security Features
• Extended distance support (director-to-director): HP supports the following director-to-director long distance connections: – Up to ten kilometers using longwave SFP interswitch link (ISL) connections. – Up to 100 kilometers by setting a port’s buffer-to-buffer credit (BB_Credit) value to 60 and using dense wavelength division multiplexing (DWDM) equipment. HP supports DWDM customer-supplied equipment.
Page 26: Serviceability Features
• Remote user restrictions Remote user access to directors is either disabled or restricted to configured IP addresses. • SNMP workstation restrictions SNMP workstations can only access management information base (MIB) variables managed by the director SNMP agent. SNMP workstations must belong to SNMP communities configured through the Product Manager application.
Page 27 • System and threshold alerts, event logs, audit logs, link incident logs, threshold alert logs, and hardware logs that display director, Ethernet link, and Fibre Channel link status at the HP EFC Server or a remote workstation. • Diagnostic software that performs power-on self-tests (POSTs) and port diagnostics (internal and external loopback test).
Page 28 • SNMP management using the Fibre Alliance MIB that runs on the HP EFC Server. Up to 12 authorized management workstations can be configured through the HP EFC Manager application to receive unsolicited SNMP trap messages. The trap messages indicate operational state changes and failure conditions. For additional information, refer to the hp surestore director fc-64 SNMP Support Manual (A6534-90908).
Page 29: Director Hardware Description
DIRECTOR HARDWARE DESCRIPTION Director Description Director Specifications HP EFC Server Description...
Page 30: Director Description
Director Description This chapter provides a hardware description of the director and HP EFC Server, describes field- replaceable units (FRUs), and lists director and server specifications. Figure 3 illustrates the front of the director. Figure 3 Director FRUs (Front Access) Director FRUs accessed from the front include the: •...
Page 31: Front Bezel
Figure 4 illustrates the rear of the director. Figure 4 Director FRUs (Rear Access) Director FRUs accessed from the rear include the: • Power module assembly. • Fan modules. • Serial crossbar (SBAR) assemblies. • Radio frequency interference (RFI) shield (not shown). •...
Page 32: Ctp Card
The system error LED illuminates when the director detects an event requiring immediate operator attention, such as a FRU failure. The LED remains illuminated as long as an event is active. The LED extinguishes when the Clear System Error Light function is selected from the Product Manager application.
Page 33: Fpm Card
FPM Card Each FPM card provides four full-duplex generic ports (G_Ports) that transmit or receive data at 1.0625 gigabits per second (Gbps). G_Port functionality depends on the type of cable attachment. FPM cards use non-open fiber control (OFC) Class 1 laser transceivers that comply with Section 21 of the Code of Federal Regulations (CFR), Subpart (J) as of the date of manufacture.
Page 34 – The green LED illuminates (or blinks if there is active traffic) and the amber LED extinguishes to indicate normal port operation. – The amber LED illuminates and the green LED extinguishes to indicate a port failure. – Both LEDs extinguish to indicate a port is operational but not communicating with an N_Port (no cable attached, loss of light, port blocked, or link recovery in process).
Page 35: Power Supply
Power Supply Redundant, load-sharing power supplies step down and rectify facility input power to provide 48-volt direct current (VDC) power to director FRUs. The power supplies also provide overvoltage and overcurrent protection. Either power supply can be replaced while the director is powered on and operational. Each power supply has a separate backplane connection to allow for different AC power sources.
Page 36: Fan Module
• A 9-pin maintenance port that provides a connection for a local terminal or dial-in connection for a remote terminal. Although the port is typically used by maintenance personnel, operations personnel use the port to configure network addresses. • An input filter and AC system harness (internal to the FRU) that provides the wiring to connect the AC power connectors to the power switch and power supplies (through the backplane).
Page 37: Backplane
Each SBAR assembly mounts flush on the backplane, and the FRU is comprised of the card and a steel carriage. The carriage provides protection for the back of the card, distributes cooling airflow, and assists in aligning the assembly during installation. The rear of the carriage contains a green LED that illuminates if the assembly is operational and active, and an amber LED that illuminates if the assembly fails.
Page 38: Director Specifications
Director Specifications This section lists physical characteristics, storage and shipping environment, operating environment, and service clearances for the HP Surestore Director FC-64. Physical Characteristics Dimensions Height: 39.7 centimeters (15.7 inches) Width: 44.5 centimeters (17.5 inches) Depth: 54.6 centimeters. (21.5 inches) Weight: 52.3 kilograms (115.0 pounds) Power requirements Input voltage: 100 to 240 V AC...
Page 39: Storage And Shipping Environment
Shock and vibration tolerance 60 Gs for 10 milliseconds without nonrecoverable errors Acoustical noise 70 dB “A” scale Inclination 10° maximum Storage and Shipping Environment Protective packaging must be provided to protect the director under all shipping methods (domestic and international). Shipping temperature -40°...
Page 40: Operating Environment
Operating Environment Temperature 40° F to 104° F (4° C to 40° C) Relative humidity 8% to 80% Maximum wet-bulb temperature 27° C (81° F) Altitude 10,000 feet (3,048 meters) Equipment Rack Service Clearances Front: 1 meter (39.37 inches) Rear: 1 meter (39.37 inches) Right side: No clearance required Left side: No clearance required Director Specifications...
Page 41: Hp Efc Server Description
HP EFC Server Description The HP EFC Server is a notebook personal computer (PC) that provides a central point of control for up to 48 LAN-connected directors or other supported products. However, note that the maximum number of switches per storage area network (SAN) fabric is 16. Contact your local HP sales representative for the latest information.
Page 42: Hp Efc Server Specifications
The HP EFC Server is dedicated to operation of the HP EFC Manager and Product Manager applications. The applications provide a graphical user interface (GUI) and management services, and implement Web and other server functions. Refer to Chapter 3 for information about the HP EFC Manager and Product Manager applications.
Page 43: Ethernet Hub
• 56K internal modem. • One internal 10/100 Mbps Ethernet adapter with RJ-45 connector (provides public LAN interface to directors and remote clients). Ethernet Hub The EFC Server and managed directors can be connected through a 10/100 Base-T Ethernet hub (Figure 7). A 12-port hub can be ordered from HP and is installed at the top front of the equipment rack.
Page 44: Embedded Web Server Interface
• UNIX workstation with color monitor, keyboard, and mouse, using a: – HP HA PA-RISC processor with a 360 MHz or greater clock speed, using the HP-UX 11 or higher operating system, AIX version 4.3.3 or higher operating system, Linux 2.2.5 or higher operating system. ®...
Page 45: Director Software Description
DIRECTOR SOFTWARE DESCRIPTION Director Firmware Backup and Restore Features Software Overview...
Page 46: Director Firmware
Director Firmware Director firmware provides services that manage and maintain Fibre Channel connections between ports. Although director hardware transmits Fibre Channel frames between source and destination ports, the firmware maintains routing tables required by the hardware to perform these switching functions. Director firmware also provides functions for system configuration, control, maintenance, and redundancy management, including: •...
Page 47 • Network Services This function provides TCP/IP transport layers to access management service subsystems from attached management clients. These clients include the HP EFC Server or an SNMP management station. • Application Services This function supports all software subsystems for system initialization, logging, and debugging.
Page 48: Backup And Restore Features
Backup and Restore Features The HP EFC Server provides two backup and restore features. One feature backs up (to the HP EFC Server) or restores the configuration file stored in nonvolatile random-access memory (NV-RAM) on a director’s CTP card. The other feature backs up (to the Zip drive) or restores the entire HP EFC Manager data directory.
Page 49 when the HP EFC Server is rebooted or when directory contents change. The HP EFC Manager data directory includes: – All HP EFC Manager configuration data (product definitions, user names, passwords, user rights, nicknames, session options, SNMP trap recipients, e-mail recipients, and Ethernet event notifications).
Page 50: Software Overview
Software Overview This section describes the HP EFC Management Services and HP EFC Manager applications. The HP EFC Manager application includes the Product Manager and Fabric Manager applications. These applications provide a graphical user interface (GUI) and management services for monitoring and controlling directors. HP EFC Management Services Application The HP EFC Management Services application runs on the HP EFC Server and provides management services to the HP EFC Manager, Product Manager, and Fabric Manager...
Page 51: User Interface
The HP EFC Server also provides hypertext transfer protocol (HTTP) server functionality. Use of this protocol with a standard Web server allows the download of HP EFC Manager, Product Manager, and Fabric Manager applications from the HP EFC Server to remote workstations.
Page 52: Product View
• Open the Fabric Manager application to display all managed fabrics and to manage and monitor each fabric. • Identify new products and their associated network addresses to the HP EFC Server for access through the HP EFC Manager and Product Manager applications. Product View When the HP EFC Manager application opens, the default display is the Product View (Figure 8).
Page 53 A label below each product icon identifies the managed product by its configured name or internet protocol (IP) address. A colored alert symbol behind each product icon indicates the operational status of the product as follows: • A green circle indicates the product is fully operational. •...
Page 54: Fabric View
Manager application. Refer to Fabric Manager Application on page 44 for additional information. Figure 9 Fabric View The navigation control panel at the left side of the Fabric View provides the same administrative, operations, and maintenance task icons (with associated pop-up menus) provided by the Product View.
Page 55: Session View
Session View When the Session option is selected from the View icon, the Session View displays (Figure 10). A list of remote users logged into the HP EFC Manager application appears at the right panel of the window, and a navigation control panel with a series of icons appears at the left side of the window.
Page 56 • The date and time the remote user established a connection to the HP EFC Manager application. The navigation control panel at the left side of the Fabric View provides the same administrative, operations, and maintenance task icons (with associated pop-up menus) provided by the Product View.
Page 57: Hardware View
Figure 11 Hardware View An alert panel at the bottom of the navigation control panel displays a colored icon (green circle, yellow triangle, red diamond with yellow background, or grey square) that indicates director status. For example, for a single port failure, an entire FPM card failure, or a redundant FRU failure, a blinking red and yellow diamond appears on the card or FRU illustration in the Hardware View.
Page 58 click) open dialog boxes or menus that display FRU properties or allow users to perform operations and maintenance tasks. Fabric Manager Application The Fabric Manager application works in conjunction with the HP EFC Manager application, and is a Java-based GUI for managing and monitoring multiple Fibre Channel fabrics.
Page 59: Topology View
Figure 12 Topology View When the mouse cursor is moved over a fabric element or an ISL, the element or connection highlights in blue and a pop-up identification label appears. Mouse selections (right or left click) open dialog boxes or menus that display element properties or naming options, or allow users to perform operations and maintenance tasks.
Page 60 Embedded Web Server Interface The embedded Web server interface provides a GUI accessed through the Internet (locally or remotely) to manage the director. This interface is available with director firmware Version 1.1.2 (or later) installed, and does not replace nor offer the management capability of the HP EFC Manager and Product Manager applications (for example, the Web server does not support all director maintenance functions).
Page 61 Figure 13 View Panel (Embedded Web Server Interface) Task selection tabs appear at the top of the panel, a graphical representation of director hardware (front and rear) appears at the right side of the panel, and menu selections ( View , Configure , Monitor , Operations , and Help ) appear at the left side of the panel.
Page 62 • Monitor At the Monitor panel, the Port List (default), Port Stats, Active Zone Set, Log, and Node List task selection tabs appear. • Operations At the Operations panel, the Port Beaconing (default), Port Diagnostics, Port Reset, Online State, and Firmware Upgrade task selection tabs appear. •...
Page 63: Planning Considerations
PLANNING CONSIDERATIONS Planning a Fibre Channel SAN Configuration Port Connectivity and Fiber-Optic Cabling HP EFC Server, LAN, and Remote Access Support Security Provisions Multiswitch Fabric Support...
Page 64: Planning A Fibre Channel San Configuration
Planning a Fibre Channel SAN Configuration A Fibre Channel SAN configuration is created using the HP EFC Server, one or more HP Surestore Director FC-64s, and attached end devices such as servers and storage peripherals. Factors that affect initial SAN configuration planning include: •...
Page 65 • Migration from a proprietary to an open-systems interconnection (OSI) computing environment, and integration of channel and network architectures. OSI computing enables cross-platform communication and increases data availability to customer employees. • Cost savings through higher availability of mission-critical applications and devices. High availability is ensured by multiple device connections through more than one port, or more than one director.
Page 66: Integrating San Technology
• Scalability to meet growth requirements. A director with planned excess port capacity provides OSI connectivity for future servers, devices, and applications. Refer to Capacity Planning on page 53 for additional information. As part of the director planning and installation process, define the enterprise’s computing assets (operating systems, hardware, communication networks, database management systems, and business applications), and document all business and technical issues to be addressed.
Page 67: Capacity Planning
• Point-to-point A dedicated point-to-point connection through the director is simple to implement and should be considered for server-to-storage applications where high performance, high availability, or extended distances are required. • Multiswitch fabric Support of multiswitch fabric operation is a major feature of the director. Consider installation of multiple directors (or other switch elements) to form a high-availability fabric topology that supports multiple, full-bandwidth data transmission paths between servers and devices.
Page 68: Port Connectivity And Fiber-Optic Cabling
Port Connectivity and Fiber-Optic Cabling This section provides planning recommendations for director port connectivity and fiber- optic cabling. Specific recommendations are provided for: • Port requirements (number and type of ports). • Extended-distance ports. • High availability considerations. • Cabling and connectors. •...
Page 69 When equipped with native Fibre Channel adapters, this product contains a AUTION laser internal to the small form factor pluggable (SFP) transceiver module on the 4-port FPM cards. In the USA, the SFP module is certified as a Class 1 Laser product, conforming to the requirements contained in Department Of Health and Human Services (DSHS) regulation 21 CFR, Subchapter J.
Page 70: Extended-Distance Ports
Cost Effectiveness Cost is the secondary factor governing the choice of transceiver type and optical fiber. Shortwave laser transceivers and multimode cable offer a less expensive solution if data transmission distance is not critical. Device or Cable Restrictions The choice of transceiver and cable type may be restricted or dictated by: •...
Page 71 To provide high availability and load balancing for Fibre Channel traffic through a multiswitch fabric, multiple ISLs should be provided between directors that participate in critical data transfer paths. Multiple Directors Multiple directors can be installed in the enterprise to provide device availability and multiswitch fabric support.
Page 72: Cabling And Connectors
Cabling and Connectors Each FPM card provides four SFP optic transceivers with duplex LC connectors for attaching fiber-optic jumper cables. Figure 14 illustrates an SFP transceiver and duplex LC connector. Figure 14 SFP Transceiver and LC Duplex Connector Fiber-optic jumper cables are required to connect director ports to servers, devices, distribution panels, or other directors in a multiswitch fabric.
Page 73: Routing Fiber-Optic Cables
Routing Fiber-Optic Cables The director has a maximum of 16 FPM cards (64 ports) that may require fiber-optic cable connections and subsequent cable routing. In a Fibre Channel protocol OSI environment, ports are numbered by physical port number only. Figure 15 shows FPM card numbers (0 through 15) and port numbers (00 through 63).
Page 74 The need for additional fiber-optic cabling could grow rapidly. More cables may be required for connections to additional servers or storage devices, or for connections to additional directors as a multiswitch fabric is developed. The director may need to be moved for more efficient connection to other units, but still maintain its original connections.
Page 75: Hp Efc Server, Lan, And Remote Access Support
HP EFC Server, LAN, and Remote Access Support Out-of-band (non Fibre Channel) console access to the director is provided to perform operations and management functions. These functions are performed from one or more of the following consoles: • Through the HP EFC Server attached to the director’s CTP card. •...
Page 76: Remote User Workstations
HP EFC Server Connectivity The HP EFC Server provides an auto-detecting 10/100 Base-T Ethernet interface that connects to a hub. Each director CTP card also provides an auto-detecting 10/100 Base-T Ethernet interface that connects to a hub. A 12-port hub can be ordered from HP and installed at the top front of the equipment rack.
Page 77: Typical Network Configuration (One Ethernet Connection)
Remote workstations must have access to the LAN segment on which the HP EFC Server is installed. Director administrative functions are accessed through the LAN and HP EFC Server. The LAN interface can be: • Part of the customer’s public 10/100 Mbps LAN segment that provides access to managed directors.
Page 78: Typical Network Configuration (Two Ethernet Connections)
• Part of a second HP EFC Server interface that connects to the customer’s private intranet and allows operation of the Product Manager and Fabric Manager applications from remote user PCs or workstations. Connection to this LAN segment is optional and depends on customer requirements.
Page 79: Snmp Management Workstations
SNMP Management Workstations An SNMP agent that runs on the HP EFC Server can be configured through the HP EFC Manager application. This agent implements the Fibre Alliance management information base (MIB). The agent can be configured to send SNMP trap messages to up to 12 recipients.
Page 80: Security Provisions
Security Provisions Security provisions are available to restrict unauthorized access to the director and attached devices. Access to the director (through the HP EFC Manager application, Product Manager application, and Web server interface) is restricted by implementing password protection. Access to attached computing resources (including applications and data) is restricted by implementing name server zoning.
Page 81: Name Server Zoning
The system administrator can also use the HP EFC Manager application to assign remote workstation access to directors. Remote sessions can be allowed for anyone on a customer intranet, disallowed completely, or restricted to specific workstations. Remote users must log into the HP EFC Manager application with a user name and password, just as when logging in to the local HP EFC server.
Page 82 Benefits of Zoning System administrators create zones to increase network security measures, differentiate between operating systems, and prevent data loss or corruption by controlling access between devices (such as servers and data storage units), or between separate user groups (such as engineering or human resources). Zoning allows an administrator to establish: •...
Page 83 • The domain identification (ID) and physical port number of the director port to which the device is attached. If arbitrated loop devices are included by configuring a Brocade switch in a zone, the zone must be configured by WWN (zoning by port number is not supported by the switch).
Page 84 • Default zone The default zone consists of all devices not configured as members of a zone contained in the active zone set. If there is no active zone set, then all devices attached to the fabric are in the default zone. For the default zone: –...
Page 85 Factors to Consider When Implementing Zoning Consider the following factors when planning to implement zoning for one or more directors in the enterprise. In particular, consider the implications of zoning within a multiswitch fabric. • Reason(s) for zone implementation Determine if zoning is to be implemented for the enterprise. If so, evaluate if the purpose of zoning is to differentiate between operating systems, data sets, user groups, devices, processes, or some combination thereof.
Page 86 Server-level access control is called persistent binding. Persistent binding uses configuration information stored on the server, and is implemented through the server’s HBA driver. The process binds a server device name to a specific Fibre Channel storage volume or logical unit number (LUN), through a specific HBA and storage port WWN. For persistent binding: •...
Page 87 Obtaining Professional Services Planning and implementing the zoning feature is a complex and difficult task, especially for multiswitch fabrics. Consult your local HP sales office for the latest configuration information. Security Provisions...
Page 88: Multiswitch Fabric Support
Multiswitch Fabric Support A Fibre Channel topology that consists of one or more interconnected switch (or director) elements is called a fabric. The director operational software provides the ability to interconnect directors (through E_Port connections) to form a multiswitch fabric. Fabric elements cooperate to receive data from the N_Port of an attached device, route the data through the proper switch ports (F_Ports), and deliver the data to the N_Port of a destination device.
Page 89: Fabric Topology Limits
Fabric Topology Limits Operation of multiple directors in a fabric topology is subject to the following topology limits. Consider the impact of these limits when planning the fabric. • Fabric Elements Up to 16 interconnected directors are supported in a single fabric. Each fabric element is defined by a unique domain identification (domain ID) that ranges between 1 and 15.
Page 90 connections. In addition, each director in the fabric must be assigned a unique preferred domain ID. When planning to implement a fabric topology, consider the following connectivity and cabling concepts: • Physical characteristics and performance objectives Most enterprises have unique configurations determined by the characteristics of end devices, fabric elements, cost, and the installation’s performance objectives (such as high data transfer rate or high availability).
Page 91 Table 2 ISL Transfer Rate Versus Fabric Port Availability (Two-Director Fabric) Number of ISLs ISL Data Transfer Rate Available Fabric Ports 1.0625 Gbps 2.1250 Gbps 3.1875 Gbps 4.2500 Gbps 5.3125 Gbps 6.3750 Gbps 7.4375 Gbps 8.5000 Gbps • Load balancing Planning consideration must be given to the amount of data traffic expected through the fabric.
Page 92 Special consideration must also be given to devices that participate in frequent or critical data transfer operations. For example, in Figure 19, suppose device D is a server and device D is a storage unit and both devices participate in a critical nightly backup operation.
Page 93 At least one switch in a multiswitch fabric needs to be set as Principal or Default. If all switches are set to Never Principal, all of the interswitch links (ISLs) will segment. If all but one switch is set to Never Principal and the switch that was Principal goes offline, then all of the other ISLs will segment.
Page 94 • Path selection Directors are not manually configured with data transmission paths to each other. Participating directors automatically exchange information to determine the fabric topology and resulting minimum-hop data transfer paths through the fabric. These paths route Fibre Channel frames between devices attached to the fabric and enable operation of the fabric services firmware on each director.
Page 95 A rerouting delay parameter can be enabled by the Product Manager application that ensures the director guarantees correct frame order delivery. The delay period is equal to the error detect time out value (E_D_TOV) specified in the Product Manager application. Class 2 frames transmitted into the fabric during this delay period are rejected;...
Page 96 – Unresponsive switch Each director in a fabric periodically verifies operation of all attached directors. An ISL E_Port segments if the attached director does not respond to a verification request. – ELP retransmission failure timeout A director that exhibits a hardware failure or connectivity problem cannot transmit or receive Class F frames.
Page 97: Obtaining Professional Services
– Fabric A zoned and Fabric B unzoned The fabrics join successfully, and fabric B automatically inherits the zoning configuration from fabric A. – F abric A unzoned and Fabric B zoned The fabrics join successfully, and fabric A automatically inherits the zoning configuration from fabric B.
Page 98 Multiswitch Fabric Support...
Page 99: Configuration Planning Tasks
CONFIGURATION PLANNING TASKS Task 1: Prepare a Site Plan Task 2: Plan Fiber-Optic Cable Routing Task 3: Consider Interoperability with Fabric Elements and End Devices Task 4: Plan Console Management Support Task 5: Plan Ethernet Access Task 6: Plan Network Addresses Task 7: Plan SNMP Support (Optional) Task 8: Plan E-Mail Notification (Optional) Task 9: Establish Director and HP EFC Server Security...
Page 100 Task 13: Complete the Planning Worksheet Task 14: Plan AC Power Task 15: Plan a Multiswitch Fabric (Optional) Task 16: Plan Zone Sets for Multiple Directors (Optional) Task 17: Complete Planning Checklists...
Page 101: Task 1: Prepare A Site Plan
Task 1: Prepare a Site Plan For each director or equipment rack installed, design a site plan that provides efficient work flow, operator convenience and safety, and adequate service clearances for the equipment rack. A customer manager should review the site plan with a service representative and consider: •...
Page 102 • Equipment rack locations, Ethernet cabling, and the internet protocol (IP) addressing scheme to support optional rack interconnection and HP EFC Server consolidation. • Power requirements, including an optional uninterruptable power supply (UPS). • Security necessary to protect the installation’s physical integrity, while maintaining accessibility to the director.
Page 103: Task 2: Plan Fiber-Optic Cable Routing
Task 2: Plan Fiber-Optic Cable Routing Plan for sufficient singlemode and multimode fiber-optic cabling to meet the connectivity requirements for director-attached servers and devices. If a multiswitch fabric is to be enabled, plan for sufficient cabling to meet interswitch link (ISL) connectivity requirements.
Page 104: Task 3: Consider Interoperability With Fabric Elements And End Devices
Task 3: Consider Interoperability with Fabric Elements and End Devices HP conducts a substantial level of testing to ensure director interoperability with fabric elements and end devices provided by multiple original equipment manufacturers (OEMs). New devices are tested and qualified on a continual basis. Contact your local HP sales office for the latest configuration information.
Page 105: Task 4: Plan Console Management Support
Task 4: Plan Console Management Support Plan to implement one or more of the following to provide console management and support for the director: • HP EFC Server The rack-mounted HP EFC Server is used for director installation, initial software configuration, changing the configuration, and monitoring director operation.
Page 106: Task 5: Plan Ethernet Access
Task 5: Plan Ethernet Access The HP EFC Server and one or more directors are configured on a dedicated Ethernet LAN segment. No Ethernet access planning is required for a stand-alone rack. However, this task is required to: • Connect equipment racks Ethernet hubs in multiple equipment racks can be connected to provide HP EFC Server access to up to 48 directors or managed products (up to 16 interconnected directors are supported in a single fabric).
Page 107: Task 6: Plan Network Addresses
Task 6: Plan Network Addresses Depending on the configuration of the LAN on which directors and the HP EFC Server are installed, plan network addressing as follows: • If installing directors and the HP EFC Server on a dedicated (private) LAN segment, there is no requirement to change any default network addresses.
Page 108 • HP EFC Server – MAC address is unique. – IP address of the first Ethernet adapter is 10.1.1.1. – IP address of second Ethernet adapter is 10.1.1.2. – Subnet mask is 255.0.0.0. – Gateway address is blank. Task 6: Plan Network Addresses...
Page 109: Task 7: Plan Snmp Support (Optional)
Task 7: Plan SNMP Support (Optional) As an option, network administrators can use the HP EFC Manager application to configure an SNMP agent that runs on the HP EFC Server. This agent can be configured to send generic SNMP trap messages to up to 12 recipients (SNMP management workstations).
Page 110: Task 8: Plan E-Mail Notification (Optional)
Task 8: Plan E-Mail Notification (Optional) As an option, network administrators can configure director e-mail support. The following support considerations are required if the e-mail notification feature is used: • Determine if e-mail notification is to be configured and used for significant system events.
Page 111: Task 9: Establish Director And Hp Efc Server Security Measures
Task 9: Establish Director and HP EFC Server Security Measures Effective network security measures are recommended for directors and the HP EFC Server. Physical access to the network should be limited and monitored, and password control should be strictly enforced. When planning security measures, consider the following: •...
Page 112: Task 10: Plan Phone Connections
Task 10: Plan Phone Connections Analog telephone connections are used by service personnel and for access to the HP EFC Server’s internal modem. Plan for one or more telephone connections near the HP EFC Server because of the following: • If a field-replaceable unit (FRU) in a managed director fails, the HP EFC Server provides a call-home feature that transmits a message through the server’s internal modem connection to a designated support center.
Page 113: Task 11: Diagram The Planned Configuration
Task 11: Diagram the Planned Configuration Determine peripheral devices that will connect to each director, and if and where connectivity should be limited (zoning). These devices may include servers, storage control devices, and other directors in a multiswitch fabric. Part of this task may have been performed when the configuration was determined. It might be helpful to draw the configuration diagram.
Page 114: Task 12: Assign Port Names And Nicknames
Task 12: Assign Port Names and Nicknames During the planning process, consider assigning names to director ports based upon devices connected to the ports. Though not required, port naming provides convenience and ease of use. Port naming also documents devices that connect through individual ports, and identifies what is attached to each port.
Page 115: Rules For Nicknames
Rules for Nicknames Nicknames can be up to 32 alphanumeric characters in length. Spaces, hyphens, and underscores are allowed within the nickname. Each nickname must be unique (corresponding to a unique WWN). Example nicknames include: Fabric-1 Host system DASD_001 Task 12: Assign Port Names and Nicknames...
Page 116: Task 13: Complete The Planning Worksheet
Task 13: Complete the Planning Worksheet The planning worksheet included in this task is a three-page form that depicts director port assignments. The worksheet lists each of the 64 director ports, and provides fields to identify devices that connect to the ports. Transfer information from the configuration diagram (completed while performing Task 11: Diagram the Planned Configuration on page 99) to the worksheet, and transfer port names and nicknames (assigned while performing Task 12: Assign Port Names and Nicknames on...
Page 117 HP Surestore Director FC-64 Name: ____________________________ Address: ____________________________ Unit Name: __________________________ Attached Devices Port Port Name Location Type Model Address Zone Task 13: Complete the Planning Worksheet...
Page 118 HP Surestore Director FC-64 Name: ____________________________ Address: ____________________________ Unit Name: __________________________ Attached Devices Task 13: Complete the Planning Worksheet...
Page 119 HP Surestore Director FC-64 Name: ____________________________ Address: ____________________________ Unit Name: __________________________ Attached Devices Task 13: Complete the Planning Worksheet...
Page 120: Task 14: Plan Ac Power
Task 14: Plan AC Power Plan for facility power sources for each equipment rack. Directors in the rack operate at 50 to 60 Hertz (Hz) and 100 to 240 volts alternating current (V AC), and requires a minimum dedicated 5-ampere service. If two power sources are supplied (optional but recommended for high availability), the equipment rack contains two customer-specified external power cords.
Page 121: Task 15: Plan A Multiswitch Fabric (Optional)
Task 15: Plan a Multiswitch Fabric (Optional) If a multiswitch fabric topology is to be implemented, carefully plan the physical characteristics and performance objectives of the topology, including the proposed number of directors (or other elements) in the fabric, characteristics of attached devices, cost, nondisruptive growth requirements, and service requirements.
Page 122: Task 16: Plan Zone Sets For Multiple Directors (Optional)
Task 16: Plan Zone Sets for Multiple Directors (Optional) If a name server zoning is to be implemented, carefully plan the characteristics and security objectives (differentiation of operating systems, data sets user groups, devices, or processes) of zone members, zones and zone sets. If a fabric topology is implemented, zoning is configured on a fabric- wide basis.
Page 123 • Zoning implications for a multiswitch fabric To ensure zoning is consistent across a multiswitch fabric, directors must have compatible operating parameters and unique domain IDs, the active zone set name must be consistent, and zones with the same name must have identical elements. •...
Page 124: Task 17: Complete Planning Checklists
Task 17: Complete Planning Checklists As a guide for planning tasks, complete the planning checklists under this task. Checklists provide detailed planning activities and provide space for a planned completion date for each activity. The customer’s management information system (MIS) project manager should examine the checklists and determine the personnel and resources required for completing planning and installation tasks.
Page 125 Table 3 lists physical planning and hardware installation tasks, and includes the task owner, due date, and comments. Table 3 Physical Planning and Hardware Installation Tasks Task Activity Owner Date Comments Locate the physical facilities. Connect the facility alternating If more than one director, consider current (AC) power circuits.
Page 126 Table 3 Physical Planning and Hardware Installation Tasks (cont’d) Task Activity Owner Date Comments Order and deliver fiber-optic Cables are purchased by the cables. customer separately. Plan to have them arrive and laid out before equipment rack delivery. Set up local area network (LAN) connections for HP EFC Server and directors.
Page 127 Table 4 lists operational setup tasks, and includes the task owner, due date, and comments. Table 4 Operational Setup Tasks Task Activity Owner Date Comments Obtain IP address and subnet Enterprise Fabric Connectivity (HP mask. EFC) Server (if installing on a LAN with non-director devices).
Page 128 Table 4 Operational Setup Tasks (cont’d) Task Activity Owner Date Comments Determine SNMP access to Obtain SNMP trap recipient IP directors. addresses. Determine SNMP information required (generic and director- specific). Determine if write permission is required for modifying SNMP variables. Determine if a multiswitch fabric is to be implemented.
Page 129: Regulatory Statements
REGULATORY STATEMENTS FCC EMC Statement (USA) EMC Statement (Canada) EMC Statement (European Union) Spécification ATI Classe A (France) VCCI EMC Statement (Japan) Harmonics Conformance (Japan) BSMI EMC Statement (Taiwan) RRL EMC Statement (Korea) Germany Noise Declaration Laser Safety Laser Safety...
Page 130: Fcc Emc Statement (Usa)
FCC EMC Statement (USA) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 131: Emc Statement (Canada)
EMC Statement (Canada) This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la Classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Appendix...
Page 132: Emc Statement (European Union)
EMC Statement (European Union) This is a Class A product. In a domestic environment this product may cause radio interference, in which case the user may be required to take adequate measures. Appendix...
Page 133: Spécification Ati Classe A (France)
Spécification ATI Classe A (France) DECLARATION D'INSTALLATION ET DE MISE EN EXPLOITATION d'un matériel de traitement de l'information (ATI), classé A en fonction des niveaux de perturbations radioélectriques émis, définis dans la norme européenne EN 55022 concernant la Compatibilité Electromagnétique. Appendix...
Page 134: Vcci Emc Statement (Japan)
VCCI EMC Statement (Japan) Appendix...
Page 135: Harmonics Conformance (Japan)
Harmonics Conformance (Japan) Appendix...
Page 136: Bsmi Emc Statement (Taiwan)
BSMI EMC Statement (Taiwan) Appendix...
Page 137: Rrl Emc Statement (Korea)
RRL EMC Statement (Korea) Appendix...
Page 138: Germany Noise Declaration
Germany Noise Declaration Schalldruckpegel Lp = 55 dB(A). Am Arbeitsplatz (operator position). Normaler Betrieb (normal operation). Nach ISO 7779:1999 (Typprüfung). Appendix...
Page 139: Laser Safety
Laser Safety When equipped with native Fibre Channel adapters, this product contains a laser internal to the small form factor pluggable (SFP) transceiver module contained on the 4-port Fibre Channel Adapter cards. In the USA, the SFP module is certified as a Class 1 Laser product, conforming to the requirements contained in Department Of Health and Human Services (DHHS) regulation 21 CFR, Subchapter J.
Page 140: Declaration Of Conformity
1) The Product was tested in a typical configuration with an HP9000 A Class server and an HP mass storage product. Roseville, January 23, 2001 European Contact: Your local Hewlett-Packard Sales and Service Office or Hewlett-Packard GmbH, Depart- ment HQ-TRE, Herrenberger Straße 130, D-71034 Böblingen (FAX: + 49-7031-14-3143) Appendix...
Page 141: Glossary
GLOSSARY The following cross-references are used in this glossary: Contrast with. This refers to a term that has an opposite or substantively different meaning. See. This refers the reader to another keyword or phrase for the same term. See also. This refers the reader to definite additional information contained in another entry.
Page 142 arbitration Process of selecting one device from a collection of devices that request service simultaneously. audit log Log summarizing actions (audit trail) made by the user. authentication Verification of identity for a person or process. beaconing Use of light-emitting diodes on ports, port cards, field-replaceable units, and directors to aid in the fault-isolation process;...
Page 143 blocked port Devices communicating with the port are prevented from logging into the director or communicating with other devices attached to the director. A blocked port continuously transmits the offline sequence. bridge Device that connects and passes packets between two network segments that use the same communications protocol.
Page 144 channel Point-to-point link that transports data from one point to the other. class of Fibre Channel service Defines the level of connection dedication, acknowledgment, and other characteristics of a connection. Class F Fibre Channel service Used by switches to communicate across interswitch links (ISLs) to configure, control, and coordinate a multiswitch fabric.
Page 145 connectionless Nondedicated link. Typically used to describe a link between nodes which allows the switch to forward Class 2 or Class 3 frames as ports allow. Contrast this to the dedicated bandwidth that is required in a Class 1 Fibre Channel Service point-to-point link.
Page 146 default Pertaining to an attribute, value, or option that is assumed when none is explicitly specified. default zone Contains all attached devices that are not members of a separate zone. destination address Address identifier that indicates the targeted destination of a data frame. device Product, connected to a managed director, that is not controlled directly by the Product Manager application.
Page 147 domain ID Number (1 through 31) that uniquely identifies a switch in a multiswitch fabric. A distinct domain ID is automatically allocated to each switch in the fabric by the principal switch. E_Port See expansion port. E_D_TOV See error detect time-out value. error detect time out value E_D_TOV defines the time the switch waits for an expected response before declaring an error condition.
Page 148 expansion port Physical interface on a Fibre Channel switch within a fabric, that attaches to an expansion (E_Port) on another Fibre Channel switch to form a multiswitch fabric. See also segmented E_Port. explicit fabric login Data field size, supported by an F-Port, that is agreed upon during fabric login. fabric Entity that interconnects N_Ports and is capable of routing (switching) Fibre Channel frames using the destination ID information in the Fibre Channel frame header...
Page 149 A standard fibre channel protocol used to run SCSI over fibre channel. FE-MIB See Fibre Channel fabric element. fiber optics Branch of optical technology concerned with the transmission of light pulses through fibers made of transparent materials such as glass, fused silica, and plastic. fiber Physical media types supported by the Fibre Channel specification, such as optical fiber, twisted pair, and coaxial cable.
Page 150 F_Port See fabric port. See field-replaceable unit. gateway address In TCP/IP, a device that connects two systems that use the same or different protocols. generic port Also known as G_Port. Physical interface on a director that can function either as a fabric port (F_Port) or an extension port (E_Port) depending on the port type to which it connects.
Page 151 Removing and replacing a device’s components while the device continues to operate normally. HP EFC Hewlett-Packard Enterprise Fabric Connectivity. HP EFC Management Services application Software application that provides back-end product-independent services to the HP EFC Manager application. The application runs only on the HP EFC Server, and cannot be downloaded to remote workstations.
Page 152 In Fibre Channel, a device that connects nodes into a logical loop by using a physical star topology. See initial machine load. information message Message telling a user that a function is performing normally or has completed normally. See also error message and warning message. initial machine load Also known as IML.
Page 153 interswitch link Also known as ISL. Physical E_Port connection between two directors in a fabric. IP address See internet protocol address. See initial program load. See interswitch link. jumper cable Optical cable that provides physical attachment between two devices or between a device and a distribution panel.
Page 154 link incident Interruption to link due to loss of light or other causes. load balancing Ability to evenly distribute traffic over multiple interswitch links within a fabric. Load balancing on directors takes place automatically. logical unit number Also known as LUN. In Fibre Channel addressing, a logical unit number is a number assigned to a storage device which, in combination with the storage device’s node port’s world-wide name, represents a unique identifier for a logical device on a storage area network.
Page 155 managed product Hardware product that can be managed with the Product Manager application. For example, the HP Surestore Director FC-64 is a managed product. See also device. management information base Related set of software objects (variables) containing information about a managed device and accessed via SNMP from a network management station.
Page 156 name server zoning N_Port access management that allows N_Ports to communicate if and only if they belong to a common name server zone. network address Name or address that identifies a managed product, such as the HP Surestore Director FC_64 on a TCP/IP network. The network address can be either an IP address in dotted- decimal notation (comprised of four three-digit octets in the format xxx.xxx.xxx.xxx), or a domain name (as administered on a customer network).
Page 157 optical cable Fiber, multiple fibers, or a fiber bundle in a structure built to meet optical, mechanical, and environmental specifications. See also jumper cable, optical cable assembly, and trunk cable. optical cable assembly Optical cable that is connector-terminated. See jumper cable and optical cable. optical fiber connector Hardware component that transfers optical power between two optical fibers or bundles and is designed to be repeatedly connected and disconnected.
Page 158 persistent binding A form of server-level access control that uses configuration information to bind a server to a specific Fibre Channel storage volume (or logical device) using a unit number. port Receptacle on a device to which a cable leading to another device can be attached. port card Field-replaceable hardware component that provides the port connections for fiber cables and performs specific device-dependent logic functions.
Page 159 principal switch In a multiswitch fabric, the switch that allocates domain IDs to itself and to all other switches in the fabric. There is always one principal switch in a fabric. If a switch is not connected to any other switches, it acts as its own principal switch. product name User-configurable identifier assigned to a managed product.
Page 160 resource allocation time out value R_A_TOV is a value used to time out operations that depend on the maximum possible time that a frame could be delayed in a fabric and still be delivered. See storage area network. Subscriber connectors. segmented E_Port E_Port that has ceased to function as an E_Port within a multiswitch fabric due to an incompatibility between the fabrics that it joins.
Page 161 See system services processor. storage area network A high-performance data communications environment that interconnects computing and storage resources so that the resources can be effectively shared and consolidated. subnet mask Used by a computer to determine whether another computer with which it needs to communicate is located on a local or remote network.
Page 162 trap host SNMP management workstation that is configured to receive traps. trunk cable Cable consisting of multiple fiber pairs that do not directly attach to an active device. This cable usually exists between distribution panels and can be located within, or external to, a building.
Page 163 warning message Indication that a possible error has been detected. See also error message and information message. wrap plug See loopback plug. World-Wide Names Eight byte address that uniquely identifies a switch, or a node (end device), even on global networks. See World-Wide Names.
Page 164 zoning Grouping of several devices by function or by location. All devices connected to a connectivity product, such as the director, may be configured into one or more zones. See also zone. Glossary...
Page 165 INDEX port names 100 address gateway declaration of conformity 126 director 93 diagram planned configuration 99 EFC Server 94 dial-in access plan phone connection 98 director 93 disk drive 28 EFC Server 94 director 93 embedded Web server EFC server 94 interface 46 subnet mask planning browser access 65...
Page 166 Hewlett-Packard HP PA-RISC, remote plan e-mail support 96 workstation 30 plan network addresses 93 planning checklists completing 107, 108, 110 Intel Pentium processor, remote planning tasks workstation 29 assign nicknames 100, 101 Internet Explorer 46 assign port names 100 complete planning checklists 107, 108, 110...
Page 167 Taiwan, BSMI EMC statement 122 telephone plan phone connection 98 UNIX, remote workstation 30 user set password 127 user workstation planning support 91 VCCI EMC statement Japan 120 versions HP-UX operating system 30 Internet Explorer 30 Netscape Navigator 30 Solaris operating system 30 SunOS 30 video card, remote workstations 30 view panel, illustration 47...
Page 168 Index...
Page 169 Address: ZIP: City & State: Country: ___ Check here if you would like a reply. Hewlett-Packard has the right to use submitted suggestions without obligation, with all such ideas becoming the property of Hewlett-Packard. SNS Roseville Information Engineering A6534-90903 E0102...
Page 170 BUSINESS REPLY MAIL FIRST CLASS MAIL PERMIT NO. 256 ROSEVILLE, CA POSTAGE WILL BE PAID BY ADDRESSEE Attention: Information Engineering (MS 5668) Hewlett-Packard Company Scalable Network Storage 8000 Foothills Blvd. Roseville, CA 95747-9987 Fold Here Tape Please Do Not Staple...

HP Surestore 64 - Director Switch Planning Manual

1 Introduction

2 Director Hardware Description

3 Director Software Description

4 Planning Considerations

5 Configuration Planning Tasks

Regulatory Statements

Glossary

Quick Links

Related Manuals for HP Surestore 64 - Director Switch

Summary of Contents for HP Surestore 64 - Director Switch

Table of Contents
