Page 3 K S +...
Page 4: Safety Instructions
Notice Safety Instructions Format Conventions WARNING Caution Note Warranty this font...
Page 5 CONTENTS 1 hp surestore director fc-64 Operating Features...
Page 6 2 Operating the Director 3 Product Manager Overview...
Page 7 4 Monitoring and Managing the Director...
Page 8 5 Configuring the Director...
Page 9 6 Director Logs 7 Using Maintenance Features Using SNMP to Manage the Director...
Page 10: Product Manager Messages
Product Manager Messages viii...
Page 11 FPM Card Maps Regulatory Statements INDEX...
Page 13 FIGURES...
Page 15 xiii...
Page 17 TABLES...
Page 19 HP SURESTORE DIRECTOR FC-64 OPERATING FEATURES Overview Director Description HP EFC Server Description Ethernet Hub Remote User Workstations Embedded Web Server Hardware Features Director Features Hardware Operations Multiswitch Fabric Overview...
Page 20 Overview ProCurve 10/100 HP J3294A Hub 12 Link HP Hub Power Port 1 Only Link Fault Reset MDI-X (out) (in) HP Surestore FC-64 Director HP Omnibook EFC Server HP Surestore FC-64 Directors...
Page 21 Remote User Workstation(s) SNMP Management Workstation(s) 10/100 Mbps 10/100 Mbps Corporate LAN Corporate LAN HP Hub ProCurve 10/100 HP J3294A Hub 12 Link Power Link Port 1 Only Fault Reset MDI-X (out) (in) HP EFC Server Internet Connection Web Browser HP Surestore FC-64 Director...
Page 22: Director Description
Director Description...
Page 23 Cooling Fan Modules Fan Module LEDs Serial Crossbars (SBARs) SBAR LEDs AC Power Connectors Power Supply On/Off Maintenance Switch Port...
Page 26 Note...
Page 28: Hp Efc Server Description
HP EFC Server Description...
Page 30: Ethernet Hub
Ethernet Hub St at us ell ow = Se gm en 10 Mb ps gre en = M DI , lin k OK 10 0M bp 1 2 3 s, lin k M DI X off = no lin k fla sh ing S U P E R 4 5 6...
Page 31: Remote User Workstations
Remote User Workstations operating system.
Page 33: Embedded Web Server
Embedded Web Server Note...
Page 34: Hardware Features
Hardware Features...
Page 37 Note...
Page 38 HP EFC Server PC Client Backup PC Computer Name: EFCServer Computer Name: EFCClient1 10.1.1.1 10.2.1.1 ProCurve 10/100 Hub 12 ProCurve 10/100 Hub 12 HP J3294A Link HP J3294A Link Power Link Port 1 Only Power Link Port 1 Only Fault Fault Reset MDI-X...
Page 39: Director Features
Director Features Note...
Page 43 Note...
Page 45: Hardware Operations
Hardware Operations Note...
Page 46 Note...
Page 47 AUTION...
Page 48 Note...
Page 50 Multiswitch Fabric Overview...
Page 51 Host Host Host Host Host Host...
Page 52 Note...
Page 54 Note...
Page 56 Note...
Page 57 Note...
Page 61 OPERATING THE DIRECTOR Power Procedures Connectors, Controls, and Indicators Switching Power to the HP EFC Server...
Page 62: Power Procedures
Power Procedures WARNING A power cord is provided for each director power supply. To prevent electric shock when connecting the director to primary facility power, use only the supplied power cord(s), and ensure that the facility power receptacle is the correct type, supplies the required voltage, and is properly grounded.
Page 63 Note Note...
Page 64 AUTION...
Page 65: Connectors, Controls, And Indicators
Connectors, Controls, and Indicators...
Page 67 Card LED Port LEDs Port Connectors...
Page 68 Card LED Port LED IML Button Ethernet Connector...
Page 69 AUTION...
Page 71 Cooling Fan Modules Fan Module LEDs Serial Crossbars (SBARs) AC Power SBAR LEDs Connectors Power Supply On/Off Maintenance Switch Port...
Page 73 Switching Power to the HP EFC Server Note...
Page 75: Product Manager Overview
PRODUCT MANAGER OVERVIEW FC-64 Product Manager Using the Product Manager Backing Up and Restoring Product Manager Data...
Page 76: Product Manager
FC-64 Product Manager...
Page 78 Remote User Workstation(s) SNMP Management Workstation(s) 10/100 Mbps 10/100 Mbps Corporate LAN Corporate LAN HP Hub ProCurve 10/100 Hub 12 HP J3294A Link Power Link Port 1 Only Fault Reset MDI-X (out) (in) HP EFC Server Internet Connection Web Browser HP Surestore FC-64 Director...
Page 79: Using The Product Manager
Using the Product Manager...
Page 82 Note...
Page 84 Note...
Page 87 Note...
Page 88 Note...
Page 92 Note...
Page 93 WARNING This operation resets all configuration including any optional features that have been installed. You will need to re-enter your feature key to enable all optional features after resetting the configuration.
Page 95 Alert Operator Director Status Table Symbol Panel Panel Text Text Meaning Green Online or Fully Operational All components and installed ports Circle Offline are operational; no failures. Yellow Degraded Redundant Failure A redundant component has failed, Triangle such as a power supply, and the backup component has taken over operation.
Page 96 Alert Operator Director Status Table Symbol Panel Panel Text Text Meaning Gray Never Connected Director status is unknown. This Square Link Timeout occurs if the Ethernet network Protocol Mismatch connection between the HP EFC Duplicate Session Server and the director cannot be Unknown Network established or if the CTP fails.
Page 108 Note...
Page 109 Note...
Page 110 Product Product Manager Rights Administrator Operator Maintenance Backup and Restore Configuration Channel Wrap (S/390 mode) Clear Audit Log Clear Event Log Clear Hardware Log Clear LIN Alert Clear LIN Log Clear System Error Light Configure Addresses - “Active” (S/390 mode) Configure Addresses - “Stored”...
Page 111 Product Product Manager Rights Administrator Operator Maintenance FRU Beaconing FRU Switchover Manage Firmware Port Diagnostics Port Beaconing Set Online State Swap Ports (S/390 mode only) Reset Configuration Reset Statistics Counters (Performance View) Reset Port Unit Beaconing View Event Log View Firmware View Hardware Log View LIN Log View SNMP...
Page 112: Backing Up And Restoring Product Manager Data
Backing Up and Restoring Product Manager Data...
Page 113 EfcData directory...
Page 115 Note...
Page 117: Monitoring And Managing The Director
MONITORING AND MANAGING THE DIRECTOR Hardware View Port List View FRU List View Node List View Performance View Port Operational States Link Incident Alerts...
Page 118: Hardware View
Hardware View...
Page 124 Note Note Note...
Page 125 Note...
Page 127 Note...
Page 128 Note Note...
Page 129 Note...
Page 130 Note AUTION...
Page 133 Note...
Page 134 Note...
Page 143: Port List View
Port List View...
Page 144 Note...
Page 146 Note...
Page 147: Fru List View
FRU List View...
Page 149: Node List View
Node List View...
Page 150 Note...
Page 153 Note...
Page 154: Performance View
Performance View...
Page 155 Note...
Page 160: Port Operational States
Port Operational States Port Indicators Alert Port State Green Amber Indicator Description Beaconing Off or On Blink Yellow The port is beaconing. The amber port LED Triangle blinks once every two seconds to enable users to find a specific port. Enable beaconing through the port’s pop-up menu on the Port Card View, Port List View, or Performance View.
Page 161 Port Indicators Alert Port State Green Amber Indicator Description No Light None No signal (light) is being received on the director port. This is a normal condition when there is no cable plugged into the port or when the power of the device attached to the other end of the link is off.
Page 162 Port Indicators Alert Port State Green Amber Indicator Description Segmented Yellow The E_Port is segmented preventing the E_Port Triangle two fabrics from joining (this only occurs when two directors are connected to each other). Display the Port Properties dialog box to view the segmentation reason. Testing Blink Yellow...
Page 163: Link Incident Alerts
Link Incident Alerts Note...
Page 165: Configuring The Director
CONFIGURING THE DIRECTOR Configure Identification Configure Operating Mode on page 152 Configure Operating Parameters Configure Ports Configure Port Addresses Configure SNMP Configure Open Systems Management Server Configure Feature Key Configure Date and Time Export Configuration Report Backing Up and Restoring Configuration Data...
Page 166: Configure Identification
Configure Identification...
Page 168: Configure Operating Mode
Configure Operating Mode...
Page 169 Release 2 compatibility mode (default). Select this mode if the fabric contains only the HP Director, McDATA directors or switches operating with release 2.X software or higher, or the McDATA ES-1000 switch.
Page 170: Configure Operating Parameters
Configure Operating Parameters Note Note that the distances of only 30 km is supported, but provisions are provided for distances up to 100 km Note...
Page 171 Note Note...
Page 172 Note...
Page 173 The Configure Operating Parameters dialog box displays. Note AUTION...
Page 175: Configure Ports
Configure Ports Note Note...
Page 179 Note Note...
Page 181 Configure Port Addresses...
Page 182 SRUWV LV QRW...
Page 185 Note...
Page 187: Configure Snmp
Configure SNMP Note...
Page 188 Note...
Page 189 (1 to 65535)
Page 190: Configure Open Systems Management Server
Configure Open Systems Management Server Note...
Page 191: Configure Feature Key
Configure Feature Key Note...
Page 193 Note...
Page 194: Configure Date And Time
Configure Date and Time...
Page 195 Note Note...
Page 196 Note...
Page 197: Export Configuration Report
Export Configuration Report Note The Export Configuration Report dialog box displays.
Page 199: Backing Up And Restoring Configuration Data
Backing Up and Restoring Configuration Data Note...
Page 201: Using Maintenance Features
USING MAINTENANCE FEATURES Run Port Diagnostics Collect Maintenance Data Execute an IPL Set Online State Manage Firmware Versions Enable E-Mail Notification Enable Call-Home Notification Backup and Restore Configuration Reset Configuration...
Page 202: Run Port Diagnostics
Run Port Diagnostics...
Page 204: Collect Maintenance Data
Collect Maintenance Data...
Page 205: Execute An Ipl
Execute an IPL AUTION Note...
Page 207: Set Online State
Set Online State AUTION...
Page 209: Manage Firmware Versions
Manage Firmware Versions...
Page 210: Enable E-Mail Notification
Enable E-Mail Notification Note...
Page 211: Enable Call-Home Notification
Enable Call-Home Notification...
Page 212: Backup And Restore Configuration
Backup and Restore Configuration Note...
Page 213 Note...
Page 214: Reset Configuration
Reset Configuration Note Note...
Page 215 AUTION Note Configuration Description Default Director Name NULL string Director Description “Fibre Channel Director” Director Contact “End User Contact (please configure)” Director Location “End User Contact (please configure)” Port Names NULL strings Port Blocked States Unblocked Extended Distance (10- Disabled 100km) LIN Alerts Disabled...
Page 216 Configuration Description Default Preferred Domain ID Buffer-to-Buffer Credit R_A_TOV 10 seconds (100 tenths) E_D_TOV 2 seconds (20 tenths) Director Priority Rerouting Delay Disabled SNMP Communities “public” — 5 NULL strings SNMP Write Authorizations Read only per community Trap Recipient IP 0 for each Addressees UDP Port...
Page 219 DIRECTOR LOGS Using Logs...
Page 220: Using Logs
Using Logs...
Page 225 000 - 199 System events 200 - 299 Power supply events 300 - 399 Fan module events 400 - 499 CTP card events 500 - 599 Port (FPM) card events 600-699 SBAR card events 800-899 Thermal events...
Page 227 Fan module Power supply module Control processor SBAR SBAR card BKPLNE Backplane FPM card...
Page 230 • Link reset protocol timeout occurred. • Timeout occurred for an appropriate response while in NOS receive state and after NOS is no longer recognized.
Page 231 USING SNMP TO MANAGE THE DIRECTOR Overview SNMP Support SNMPv1 Transports MIB-II Support Fibre Channel Fabric Element MIB Support FC-64 Private Enterprise MIB...
Page 232 Overview...
Page 233 root iso (1) org (3) dod (6) internet (1) experimental mgmt (2) private (4) Note Variables are also known as “objects.”...
Page 234 internet (1) experimental mgmt (2) private (4) Fabric Element MIB - II Surestore FC-64...
Page 235: Snmp Support
SNMP Support...
Page 236 SNMPv1 Transports...
Page 238: Mib-Ii Support
MIB-II Support mgmt (2) mib-2 (1) system (1) interface (2) at (3) ip (4) icmp (5) tcp (6) udp (7) snmp (11)
Page 240 Fibre Channel Fabric Element MIB Support experimental fibre channel (42) fcFabric (2) fcFe (1) fcConfig (1) fcFeOp (2) fcFeError (3) fcFeAcct (4) fcFeCap (5)
Page 241 Variable Provides the Number of: fcFxPortErrorModuleIndex Module index. fcFxPortErrorPortIndex Port index. LinkFailures Link failures detected by the F_Port. SyncLosses Synchronization losses detected by the F_Port. SignalLosses Signal loss errors detected by the F_Port. PrimSeqProtErrors Primitive sequence protocol errors detected by the F_Port. InvalidTxwords The number of invalid transmission words detected by the F_Port.
Page 242 Variable Provides the Number of Class 2: ModuleIndex Module index. PortIndex Port index. InFrames Frames received by the F_Port from its attached N_Port. OutFrames Frames delivered through the F_Port to its attached N_Port. InOctets Frame octets, including frame delimiters, received by the F_Port from its attached N_Port.
Page 243 Variable Provides the Number of Class 3: OutFrames Frames delivered through the F_Port to its attached N_Port. InOctets Frame octets, including frame delimiters, received by the F_Port from its attached N_Port. OutOctets Frame octets, including frame delimiters, delivered through the F_Port to its attached N_Port.
Page 244 Variable Provides: ModuleIndex Module index. FxPortIndex Port index. AdminStatus Desired state of the F_Port. The testing (3) state indicates no operational frames can be passed. When a fabric element initializes, all F_Ports start with fcFPortPhysAdminStatus in the offline (2) state. As the result of either explicit management action or per-configuration information accessible by the fabric element, fcFPortPhysAdminStatus is then changed to either the online (1) or testing (3) states or remains in the offline (2) state.
Page 245 Variable Provides: fcFxlogiFxPortIndex Port index. fcFxlogiNxPortIndex Node port index. FC-PHversAgrd Version of FC-PH that the F_Port has agreed to support from the fabric login. N_PtBBCredit Total number of buffers available for holding a class 1 connect-request, or class 2 or class 3 frames to be transmitted to the attached N_Port. It is for buffer-to-buffer flow control in the direction from F_Port to N_Port.
Page 246 Variable Provides: BbCreditModel A flag identifies the BB_Credit model used by the FxPort. The regular model refers to the Buffer-to-Buffer flow control mechanism defined in FC-PH [1] is used between the F_Port and the N_Port. It is fixed at regular (1) for the director. Variable Provides: ModuleIndex...
Page 247 Variable Provides: OperStatus The operational status of the module: online(1) the module is functioning properly; offline(2) the module is not available; testing(3) the module is under testing; and faulty(4) the module is defective in some way. LastChange This object contains the value of sysUpTime when the module entered its current operational status.
Page 248 Variable Provides: E_D_TOV Error detect time out value configured for the F_Port. The Error_Detect_Timeout Value is used as the timeout value for detecting an error condition. ClassSvcSupt Value indicating the set of classes of service supported by the F_Port. IntermixSupt Flag indicating if the F_Port supports an intermixed dedicated connection.
Page 249 Variable Provides BBCreditMin Minimum number of receive buffers available for holding a class 1 connect- request, or class 2 or class 3 frames from the attached N_Port. RxDataFldSzMax Maximum size in bytes of the data field in a frame that the F_Port is capable of receiving from its attached N_Port.
Page 250 FC-64 Private Enterprise MIB private (4) enterprise (1) McData (289) commDev (2) fibrechannel fcSwitch (1) ef-6000(2) ef-6000Sys(1) ef-6000Fru(2) ef-6000Port(3)
Page 251 Variable Provides: ef6000SysCurrentDate Current date information. ef6000SysBootDate Date and time of the last IPL of the director. ef6000SysFirmwareVersion Current version of the firmware. ef6000SysTypeNum ASCII type number of the director. ef6000SysModelNum ASCII model number of the director. ef6000SysMfg ASCII manufacturer of the director. ef6000SysPlantOfMfg ASCII plant of manufacturer of the director.
Page 252 Variable Provides: ef6000SysAdmStatus The desired administrative status of the director. A (read-write) management station may place the director in a desired state by setting this object accordingly. The desired administrative statuses are online (1) and offline (2). Online means setting the director to be accessible by an external Fibre Channel port, and offline means setting the director to be inaccessible.
Page 253 Variable Provides: ef6000FruPowerOnHours Number of the hours that the FRU has been in operation. ef6000FruTestDate Final test date of the module. This group contains information about the physical state, operational status, performance and error statistics of each Fibre Channel ports on the director. Variable Provides: ef6000PortIndex...
Page 254 Variable Provides: ef6000PortMedia A bit map to represent transmission media of the port. bit 0 single mode(sm), bit 1 reserved, bit 2 multi-mode 50m (m5), bit 3 multi-mode 62.5 (m6), bit 4-7 reserved. ef6000PortSpeed A bit map to represent transmission speed of the port. bit 0 100 Mbytes/Sec, bit 1 reserved, bit 2 200 Mbytes/Sec, bit 3 reserved, bit 4, 400 Mbytes/Sec, bit 5-7 reserved.
Page 255 Variable Provides: ef6000PortRxC2Frames The number of Class 2 frames that the port has received. ef6000PortTxC2Octets The number of Class 2 Octets that the port has transmitted. ef6000PortRxC2Octets The number of Class 2 Octets that the port has received. ef6000PortTxC3Words The number of class 3 4-byte words that the port has transmitted. (Primitive signals and primitive sequence are not included.) ef6000PortRxC3Words The number of class 3 4-byte words that the port has received.
Page 256 Trap Trap Type Enterprise Variable ef6000PortScn mcDataTrap {ef6000PortOpStatus} ef6000FruScn mcDataTrap {ef6000FruStatus}...
Page 257 Product Manager Messages...
Page 258 Message Cause/Solution Activating this configuration will Confirmation to activate a new address configuration. Click overwrite the current to confirm activating the new address configuration or click configuration end the operation. All configuration names must All address configurations must be save with unique names. be unique.
Page 259 Message Cause/Solution Could not find firmware file. Ensure file name and directory are correct. Firmware file selected was not found in the FTP directory. Cannot have spaces in field. Spaces are not allowed in this field. Remove the spaces or retype the field without spaces.
Page 260 Message Cause/Solution Cannot run diagnostics on an Port diagnostics cannot be performed on a port that is not uninstalled port. installed. Run diagnostics only on a port that is installed. Cannot run diagnostics while a A device is logged in to the port where a diagnostic test is device is logged-in to the port.
Page 261 Message Cause/Solution Connection to HP EFC server The HP EFC Manager lost the network connection to the HP EFC Server. Restart the HP EFC Manager to connect to the HP lost. Click to exit EFC Server. application. Continuing may overwrite host Configurations sent from the host may be overwritten by HP programming.
Page 262 Message Cause/Solution Director must be offline to The director must be offline to configure operating parameters. configure. Set the director offline and reconfigure the Fibre Channel operating parameters. Do you want to continue with Requesting confirmation to proceed with an IPL. Click IPL? confirm the firmware deletion or click to end the...
Page 263 Message Cause/Solution Field cannot be blank. A blank field is not allowed in this dialog. Enter the required information in the blank field. Field has exceeded maximum The maximum number of characters allowed in this field has number of characters. been exceeded.
Page 264 Message Cause/Solution Invalid firmware file. Selected file is not a firmware file. Select the correct firmware file. Invalid network address. Network address specified is not known by the domain name server. Check the input address and specify the correct network address.
Page 265 Message Cause/Solution Invalid value for second (0 - 59). Value for second must be an integer from 0 through 59. Enter a value from 0 through 59. Invalid value for year. Value for year must be a four-digit year after 1980. Enter a correct four-digit value for the year.
Page 266 Message Cause/Solution No firmware versions to delete. There are no firmware versions in the firmware library to delete. N/A. An informational message. Non-redundant director must be If the director has only a single CTP card, it must be offline to offline to install firmware.
Page 267 Message Cause/Solution Send firmware operation failed. Send firmware has failed. Retry the operation. If the condition persists, contact support personnel. SNMP trap address not defined. An SNMP trap address must be defined if a community name is defined. Define an SNMP address. Director must be offline to The director must be offline to configure Fibre Channel configure.
Page 268 Message Cause/Solution The link to the director is not The link from the HP EFC Server to the director is not available. available. Check Ethernet connection. The maximum number of The maximum number of saved address configurations has address configurations has been reached.
Page 269 Message Cause/Solution You do not have rights to User does not have the rights to perform this action. An perform this action. informational message.
Page 271 FPM CARD MAPS...
Page 272 FPM Cards FPM Cards...
Page 273: Regulatory Statements
REGULATORY STATEMENTS FCC EMC Statement (USA) EMC Statement (Canada) EMC Statement (European Union) Spécification ATI Classe A (France) VCCI EMC Statement (Japan) Harmonics Conformance (Japan) BSMI EMC Statement (Taiwan) Germany Noise Declaration Laser Safety...
Page 274: Fcc Emc Statement (Usa)
FCC EMC Statement (USA)
Page 275: Emc Statement (Canada)
EMC Statement (Canada)
Page 276: Emc Statement (European Union)
EMC Statement (European Union)
Page 277: Spécification Ati Classe A (France)
Spécification ATI Classe A (France)
Page 278: Vcci Emc Statement (Japan)
VCCI EMC Statement (Japan)
Page 279: Harmonics Conformance (Japan)
Harmonics Conformance (Japan)
Page 280: Bsmi Emc Statement (Taiwan)
BSMI EMC Statement (Taiwan)
Page 281: Germany Noise Declaration
Germany Noise Declaration...
Page 282: Laser Safety
Laser Safety CLASS 1 LASER PRODUCT 21 CFR WARNING There are no user maintenance operations, service operations, or adjustments to be performed on the SFF module.
Page 283: Declaration Of Conformity
1) The Product was tested in a typical configuration with an HP9000 A Class server and an HP mass storage product. Roseville, January 23, 2001 European Contact: Your local Hewlett-Packard Sales and Service Office or Hewlett-Packard GmbH, Depart- ment HQ-TRE, Herrenberger Straße 130, D-71034 Böblingen (FAX: + 49-7031-14-3143)
