NOTE:

CT Group Ids for Replicated LUNs are supported in XP Business Copy

SRM maps LUNs with datastores using the Replicated Keys and LUN WWN, and then moves all

resources to the recovery site.

NOTE:

During initial setup, replicated LUNs need to be presented to both the protected and recovery ESX

hosts.

XP Virtualization Adapter local configuration

Figure 1

shows the local configuration for XP Virtualization Adapter on a Windows machine. The

Virtual Center server (VIC), SRM, and XP Virtualization Adapter are configured on Windows2003.

Figure 1 XP Virtualization Adapter configuration using local connection

Figure 2

shows the Telnet configuration for XP Virtualization Adapter on a Windows machine. The

Virtual Center server (VIC), SRM, and XP Virtualization Adapter are configured on Windows2003.

RAID Manager is on a remote host (for example, Linux, Solaris, or HP-UX).
