Network and Storage Planning
Note: Only one NIC per subnet can be configured. This limitation is required to prevent confusion as to which NIC to
bind a virtual IP address to when a failover package is started on a node or fails over. It is highly recommended that
'eth0' be configured as a dedicated heartbeat. See
port makes the heartbeat immune to heartbeat starvation due to high network traffic. To avoid subnet conflicts, use a
private subnet and IP address (e.g. 10.0.0.1) for the dedicated heartbeat, and direct connect the Ethernet CAT5
cross-over cable to the other node to eliminate the need for an Ethernet hub/switch that could fail. You may use an
additional port to provide redundant heartbeats in case of primary heartbeat failure.
IP Address
Gateway Address
Subnet Mask
Broadcast Address
DNS Domain Name
Primary DNS Server Address
Secondary DNS Servers
IP Address
Gateway Address
Subnet Mask
Broadcast Address
DNS Domain Name
Primary DNS Server Address
Secondary DNS Servers
IP Address
Gateway Address
Subnet Mask
Broadcast Address
DNS Domain Name
Primary DNS Server Address
Secondary DNS Servers
32
TCP/IP Settings NIC1 (installed network port eth0)
Figure 2
TCP/IP Settings NIC2
TCP/IP Settings NIC3
HP StorageWorks NAS 8000 SAN High Availability, Solution Integration Manual (SIM)
on page 10. Having a heartbeat on a dedicated network
