Network and Storage Planning
Note:
duplicated in the snapshot. This will require you to allocate a much larger storage space than you
would otherwise need.
Snapshots are optional and may be created at any time after a file volume is created. Users can
add or extend snapshots at a later time if there is enough free space available in the volume
group.

High Availability

The NAS 8000 SAN high availability solution includes a cluster, or group, of two NAS servers
that function as a unified system. It also includes a Quorum server.
The main purpose of high-availability clusters is to provide a higher degree of storage
availability to client systems than is possible with a single server. This is accomplished by
eliminating single points of failure and providing functional redundancy. Uninterrupted
service is provided by failing over file serving capabilities (see
to a secondary server in the event of a failure in the primary server in the cluster.

Clusters

HA clusters provide a higher degree of storage availability than is possible with a single server.
This is provided by:
Note:
See the HP support web site at
Configuring and Using an HP NAS 8000 HA Cluster for more information.

Failover Packages

When a package failure is detected, the failover package is halted and fails over to another
node, provided that an eligible adoptive node is present. Each failover package and its
associated resources are monitored independently. This allows failures that are limited to a
single failover package to be handled without affecting the state of other failover packages.
14
If you take a snapshot of an empty file volume, every file added to that volume will be
The NAS servers provide failover services for each other.
The Quorum server manages the NAS servers, or cluster nodes, and provides cluster
arbitration services that prevent data corruption.
Hardware component redundancy designed to eliminate single points of failure. Each
cluster consists of two NAS servers (nodes) plus one Quorum server. The Quorum server
can be shared by multiple NAS Clusters.
All storage is grouped into separate units that are given names and are accessible only by
an assigned, unique virtual IP address. These separate units of storage are referred to as
failover packages. Storage is assigned to a failover package in units of volume groups. A
failover package may have one or more volume groups assigned to it.
HP currently supports a two-node cluster for the HP NAS 8000 solution.
HP StorageWorks NAS 8000 SAN High Availability, Solution Integration Manual (SIM)
http://hp.com/support/nas8000
Failover Packages on page 14)
for a technical paper called
