Network and Storage Planning

HA Planning Worksheet

Node 1 Name
Node 2 Name
Cluster Name
Quorum Server Name
Quorum Server Polling Interval (the time interval between
checks of the quorum server status)
Primary Heartbeat NIC
Recommendation: Use one of the included network ports (eth0) as
a direct-connect dedicated heartbeat NIC.
This cannot be the same NIC designated as the system
management network card (below).
Secondary (or backup) Heartbeat NICs
Recommendation: Use at least one additional NIC in each NAS
server as a secondary heartbeat NIC.
Secondary heartbeat NICs are not direct connections.
System Management Port
The system management port is the port designated to access the
Command View NAS web interface.
This cannot be the same port designated as the primary
direct-connect heartbeat (above).
Heartbeat Interval
Network Polling Interval
Auto Start Time-out
Maximum Number of Failover Packages
26
Cluster Planning
HP StorageWorks NAS 8000 SAN High Availability, Solution Integration Manual (SIM)
(600s default)
Node 1:
Node 2:
Node 1:
Node 2:
Node 1:
Node 2:
(5s default)
(10s default)
(600s default)
(10 default)
