Network and Storage Planning
Table 2: Enumerations for Various Configurations (Continued)
PCI Slot 3 Names
NC3134 eth0, eth1
NC3134 eth0, eth1
NC3134 eth0, eth1
The following figure shows the physical port locations for the supported configurations, as
viewed from the back of the NAS server.
Figure 5: Port Locations for Supported Configurations on the NAS Server
20
Exp
Module Names
NC6132 eth4
NC7132 eth4
NC6132 eth4
HP StorageWorks NAS 8000 SAN High Availability, Solution Integration Manual (SIM)
PCI Slot 4 Names
NC3134 eth2, eth3
NC3134 eth2, eth3
NC3134 eth2, eth3
Exp
Module Names
NC6132 eth5
NC6132 eth5
NC7132 eth5
Total
Ports
6
6
6
