- Page 1 PRECISION BLUE BLUE TOOTH KEYLESS ENTRY VEHICLE SECURITY SYSTEM PRODUCT MANUAL...
- Page 2 Limited Lifetime Warranty This vehicle security system is warranted to the original purchaser, to be free from defects in material and workmanship. The manufacturer will repair or replace at its option, and free of charge for the first twelve (12) months, any part that proves defective in material or workmanship under normal installation, use, and service, provided the product is returned to the manufacturer freight prepaid.
-
Page 3: Table Of Contents
Table of Contents Arming ................Page 1 Disarming . -
Page 4: System Contents
About Your System Congratulations on your purchase of this state-of-the-art vehicle security system from ScyTek Electronics. With proper installation this system will provide superior protection and performance for many years to come. System Contents: Main Unit • Blue Tooth Transceiver Antenna •... -
Page 5: Arming
Cell Phone with Blue Tooth All ScyTek systems with Cnet capability combined with Precision Blue will arm and disarm the Alarm Arming To Arm the System: The system arms itself automatically, each time the ignition is turned off and the Cell Phone is out of range. -
Page 6: Adding/Replacing Bluetooth Phones
Adding/Replacing Bluetooth Phone (2 Phones maximum) 1- Set the BlueTooth enabled phone name to ScyTek. 2- Turn on the ignition key On, Off, and back On. 10 times. 3- The LED will illuminate. 4- Set the BlueTooth enabled phone to discoverable mode. 5- Turn Ignition Off. -
Page 7: System Programming
Entering System Programming To enter System Programming: 1. Turn on ignition. 2. Within 5 seconds, press the valet switch 5 times. · The Horn will provide three chirps, indicating that you have entered Programming. 3. Press the valet switch the number times equal to the System Option you want to change. ·... -
Page 8: System Installation
System Installation 1. Thoroughly read and become familiar with the installation instructions before beginning the installation. 2. Review system contents: Main Unit 1 Precision Blue Main Module 1 Main Harnesses ( 7 wires) 6-Pin Antenna Receiver harness • LED harness •... -
Page 9: System Wiring
System Wiring 8-Pin Main Harness Pin 1 GREEN WIRE: negative lock output (-) 500mA. Pin 2 BLUE WIRE: negative Unlock output (-) 500mA. Pin 3 ORANGE: Armed Output (-) 500mA. The ORANGE wire provides a ground output while armed to activate an optional starter defeat relay or other device such as a power window control module. -
Page 10: Door Lock Diagrams
Door Lock Diagrams Follow the diagrams below for connecting basic door lock systems. Negative Trigger Positive Trigger Reverse Polarity Vacuum Adding Actuator Page 6 - Precision Blue... - Page 11 Precision Blue - Page 7...
-
Page 12: Wiring Diagram
Wiring Diagram CNET PORT BLUETOOTH ANTENNA Valet Switch GREEN: Lock Output (-) 500mA. BLUE: Unlock Output (-) 500 mA. ORANGE: Armed Output (-) 500mA. BROWN/WHITE: Horn Output (-) 500mA. BLACK: System Ground Empty: YELLOW: Ignition Input (+ 12V ) RED: Main +12V Battery Input ScyTek Electronics 11627 Cantara Street...
