- Page 1 ASTRA 300RS REMOTE START WITH KEYLESS ENTRY AUTOMATIC TRANSMISSION ONLY PRODUCT MANUAL...
-
Page 2: Remote Transmitter Description
Remote Transmitters Remote Transmitter Description Button 1 Button 2 Button 3 Button 4 The Astra 300 is supplied with two 4-button Remote Transmitters used to control system operations. Button 1 Locks the doors and when held for 2 seconds, activates the system’s Panic feature. Button 1 also locks the doors when the system is in Valet Mode. -
Page 3: Battery Replacement
System Operation 300RS Adding/Replacing One-Way Transmitters To replace lost or stolen transmitters or to add additional transmitters into the system, have all desired transmitters ready and follow the steps below. Note: Up to 4 transmitters can be programmed to operate the system. To erase any previously stored transmitter codes, be sure to program all 4 transmitter memory locations. -
Page 4: Remote Starting
· The parking lights will flash twice. Auxiliary Function Outputs The ASTRA 300RS are equipped with 1 Auxiliary Channel Output allowing the convenience features of the system to be further expanded. This output can be programmed for pulsed, timed, or latched operation, and used to add a number of optional features such as: power trunk release, power window activation, power sunroof control, auxiliary lighting, audio/video system control, and more. -
Page 5: System Installation
System Installation 1. Thoroughly read and become familiar with the installation instructions before beginning the installation. 2. Review system contents: Main Unit Two 4-Button Remote Transmitters Harnesses • 6-Wire starter harness • 3-Pin Power harness • 8-Pin main harness • 3-Pin door lock harness •... -
Page 6: Pin Main Harness
6-Wire Starter Harness Pin 1 RED - A: Main Power Input A (+). Connect to the battery or constant power wire at the ignition switch with a minimum 30 Amp supply. Remove the fuse until the installation is complete and all wiring is checked. Pin 2 RED - B: Main Power Input B (+). -
Page 7: System Programming
System Programming System Programming The system programming is compatible with both the LCD transmitter or the standard AM transmitter. Enter System Programming: 1. Turn on ignition. 2. Within 5 seconds, press the valet switch 5 times. · The horn will provide three chirps, indicating that you have entered Programming. 3. - Page 8 28. Starter Disable Output Mode. Select between Starter Disable output, Factory Rearm output and Second Auxiliary output, on the orange wire. 29. Selects between Astra 1000RS and Astra 4000RS - doesn’t apply to Astra 300RS. 30. When enabled doors unlock before start.
- Page 9 System Programming Brunch Feature Button 1 Button 2 Button 3 Lock/Unlock Chirps Silent Horn Chirps ON Extended Parking Lights Reset Mobilink Ignition Door Locking Ignition Door Unlocking Door Unlock Pulse Single Double Pulse Ignition before Unlock Door Lock Pulse Length 1 Sec 3 Sec 0.1 Sec...
-
Page 10: Door Lock Diagrams
Door Lock Diagrams Positive Trigger/ additional 2 relays reqiured Negative Trigger Reverse Polarity Adding Actuators... -
Page 11: Wiring Diagram
Red - Battery 2 (+) Red - +12v In (+) Power White - Parking Light Out (+/-) Black - Ground in (-) Astra 300RS White/Violet - Factroy Disarm Out (-) Blue/Orange - Ground When Running Out (-) Brown/White - Horn Out (-) Main Harnes...
