ULTIMATE U37 Rear Vent
Direct Vent Freestanding Gas Stove
www.regency-fi re.com
WARNING:
If the information in these instructions are not followed ex-
actly, a fi re or explosion may result causing property damage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other fl ammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualifi ed
installer, service agency or the gas supplier.
Tested by:
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
918-529b
MODELS:
U37-NG1 Natural Gas
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Installation Manual
U37-LP1 Propane
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical
switch: do not use any phone in
your building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas sup-
plier, call the fi re department.
Owners &
06/17/10
Advertisement
Table of Contents
Related Manuals for Regency ULTIMATE U37-NG1
Summary of Contents for Regency ULTIMATE U37-NG1
- Page 1 ULTIMATE U37 Rear Vent Owners & Direct Vent Freestanding Gas Stove Installation Manual www.regency-fi re.com MODELS: U37-NG1 Natural Gas U37-LP1 Propane WARNING: FOR YOUR SAFETY If the information in these instructions are not followed ex- What to do if you smell gas: actly, a fi...
- Page 2 Congratulations! You are the owner of a state-of-the-art ULTIMATE Rear Vent Direct Vent Gas Stove by FPI Fireplace ® Products International. The Regency Gas Series of hand crafted appliances has been designed to provide you with all the warmth and charm of a woodstove, at the fl ick of a switch. The models U37-NG1, and U37-LP1 of this series has been approved by Warnock Hersey for both safety and effi...
- Page 3 INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE ® This Regency product has been tested and listed by Warnock Hersey as a Direct Vent Wall Furnace to the following standards: ANSI Z21.88b-2003/CSA 2.33b-2003, and CAN/CGA-2.17-M91. This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured Home Installations, Sites, and Com- munities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada.
-
Page 4: Table Of Contents
Aeration Adjustment ............22 Log Set Installation ............22 Door Installation............24 Gas Pipe Pressure Testing ..........24 Louver Installation ............25 Wall Thermostat ............25 Optional Remote Control ..........25 Final Check..............25 Wiring Diagram ............26 ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 5: Safety Label
SAFETY LABEL ® This is a copy of the label that accompanies NOTE: Regency units are constantly being each ULTIMATE Rear Vent Direct Vent Free- improved. Check the label on the unit and if standing Gas Stove. We have printed a copy there is a difference, the label on the unit is the of the contents here for your review. -
Page 6: Requirements
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 7: Installation
SERIOUS HOUSE FIRE. CHILDREN AND ADULTS SHOULD BE ALERTED TO THE HAZARDS OF HIGH SURFACE TEMPERATURES, ESPE- CIALLY THE FIREPLACE GLASS, AND SHOULD STAY AWAY TO AVOID BURNS OR CLOTHING IGNITION. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 8: Important Message
fi replace. Emissions from burning wood or gas could contain chemicals known to the State of Cali- fornia to cause cancer, birth defects or other reproductive harm. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 9: Installation Checklist
CAUTION: Any alteration to the product that VENTING causes sooting or carboning that results in damage is not the responsibility of the ® The Regency Direct Vent System (Horizontal manufacturer. Termination Kit (640-944) and the Vertical Termination with the Co-linear Flex System in... -
Page 10: Exterior Vent Terminal Locations
INSTALLATION EXTERIOR VENT TERMINAL LOCATIONS ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 11: Venting Installation
Pipe Venting - Vertical Termination" sections. are prohibited. 3) Installation of any component part not Consult your local building codes before begin- ® manufactured or approved by Regency ning installation. Industries Ltd. SAFETY PRECAUTIONS The location of the termination cap must con- 4) Installation other than as instructed by form to the requirements in the"... -
Page 12: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
SV4SU Wall Thimble-Black 46DVA-WT 4DT-WT 4DWT 4DWT SV4RSM TE-4DE90 Wall Thimble Support/Ceiling Support 46DVA-DC SV4PF TE-4DE90B Firestop Spacer 46DVA-FS 4DT-FS 4DFSP 4DFS SV4BF Trim Plate-Black 4DT-TP 4DFPB 4DCP SV4LA ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... - Page 13 Note: Horizontal runs of vent must be level, or have a 1/4” rise for every 1 foot of run towards the termination. Never allow the vent to run downward - this could cause high temperatures and may present a possible fi re hazard. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove...
-
Page 14: Rigid Pipe Venting - Vertical Terminations
To set the Vent restriction as indicated in the diagram, simply loosen the screws and push the vent restrictor plate to the correct position. Tighten the screws. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 15: Residential And Manufactured Homes / Mobile Homes Installations
INSTALLATION RESIDENTIAL AND MANUFACTURED HOMES / MOBILE HOMES INSTALLATIONS You will require the following components with your new Regency ® Rear Vent Direct Vent Freestanding Gas Stove. Please review your product to make sure you have everything you need. In the event that you are missing any part, contact your dealer. Decorative brass or chrome trim kits are available from Simpson Dura-Vent for their wall thimbles, as well as a square wall thimble cover. - Page 16 10) Seal around the outer edge of the Riser Vent 7) Install the Backing Plate into the wall penetration Backing Plate. heat shield and attach using 4 screws. Dia. 4. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove...
-
Page 17: Vertical Termination With Co-Linear Flex System
(35 ft) Exhaust Flue Air Intake U37 Rigid Pipe Adaptor Part # 640-994 Co-Linear Flex Adapter with Kit# 946-563 Inner Pipe Adapter Outer with Kit# 946-563 Pipe with Kit# 946-563 ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 18: Converting Class-Ametal Chimney Or Masonry Chimney To Direct Vent System
7) The connection between the appliance and the Retro Connector may be completed with sections of black direct vent pipe, together with an adjustable length. Diagram 2 ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 19: Converting Masonry Chimney
Be careful to insure that with an adjustable length pipe section. chimney. Diagram 7. the connector is centered in the opening and the mounting holes line up with the masonry wall. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 20: Conversion From Ng To Lp
Ground 30 in. Pull off the pilot cap to expose the pilot 904-781 Velcro Hook, Black orifi ce. Turn control knob to the “OFF” position. 904-782 Velcro Hook, Black ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... - Page 21 Allen wrench into the hexagonal key-way of the screw (Fig. LPG Configuration 2), rotate it counter- Red o-ring visible clockwise until it is free and extract it. Fig.2 Fig.5 ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove...
-
Page 22: Gas Connection
NOT covered under warranty. HIGH ELEVATION Note: Aeration Adjustment should only be ® performed by an authorized Regency This unit is approved in Canada for altitude 0 ft. Installer at the time of installation or to 4500 ft. (CAN/CGA-2.17-M91). For Natural service. - Page 23 10) Place the notch in Center Log F)02-47 over E)02-45 front pins as shown. Log E)02-45 and across the cutout on Log C)02-44 A)02-65. F)02-47 C)02-44 E)02-45 Notch Cutout ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove...
-
Page 24: Door Installation
Note: The door latch may require adjust- ment as the door gasket material compresses after a few fi res and after glass replacement. Turn the latch catch inward or outward. Diagram 3 ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 25: Louver Installation
CONTROL INSTALLATION A wall thermostat may be installed if desired. Connect the wires as per the wiring diagrams. Use the Regency ® Remote Control Kit approved Attach the top & bottom louvers to the side stove Note that the wires are connected to the "TH"... -
Page 26: Wiring Diagram
This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 27: Operating Instructions
"ticking" and "cracking" sounds. You should also be aware that as there are temperature changes within the unit these sounds will likely re-occur. Again, this is normal for steel fi reboxes. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 28: Copy Of The Lighting Plate Instructions
3) Turn off all electric power to the appliance if service is to be performed. You may shut off the pilot during prolonged non use periods to conserve fuel. DO NOT REMOVE THIS INSTRUCTION PLATE 918-474b ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 29: Maintenance Instructions
Note: If you have an incorrect fl ame pat- need replacement, you must use the proper that the fl ow of combustion and ventilation ® tern, contact your Regency dealer replacement log. The position of these logs air is not obstructed. -
Page 30: Latch Adjustment
GLASS REPLACEMENT retainers and fasten with the nuts but do not overtighten, as this can break the glass. Note: the door catch plate fi ts on top of the Your Regency ® stove is supplied with high tem- left side retainer. -
Page 31: Fan Maintenance
3) Unclip the black and white wires from the fan mo- tor. 4) Lift fan off of the ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 32: Dc Sparker Battery Replacement
fi rebox. 4) Reverse steps to put back in place. 12) To replace the burner tray assembly, simply reverse these instructions. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 33: Parts List
560-031 Side Panel Door Hinge 904-258 Side Panel Door (c/w Hook) Magnet *Not available as a replacement part. 948-255 Door Latch Flex Pipe (3" ID) Clamp for Flex Pipe ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 34: Burner & Log Assembly
Hex Key 3/16" AF 630-009 Gasket - Burner Tray / Air Passage 630-008 Gasket - Burner Tray / Firebox Air Shutter Gear Assembly (Male) *Not available as a replacement part. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... -
Page 35: Door Assemblies
Side Glass 107) 936-243 Glass Gasket 108) 940-322/P Centre Glass 111) Door Frame Fibre Paper 112) 750-015 Door Glass Extrusion 208) 940-325/P Wrap Glass *Not available as a replacement part. ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove... - Page 36 NOTES ® U37-1 Regency ULTIMATE Rear Vent Direct Vent Freestanding Gas Stove...
