Configuring Temperature Sensors

If you want to be notified of critical changes in temperature in a server, you can configure a
temperature sensor threshold and configure Server Manager to notify you if the threshold is
exceeded. For information on configuring Server Manager to send alerts, see the Intel
LANDesk Server Manager v3.0 Administrator's Guide.
To configure temperature sensors:
1. In the Tree pane of the Server Manager Console, log onto the server for which you want
to set temperature sensor thresholds.
2. Expand the Tools group, and select Emergency Mgmt. Card Connection.
3. If necessary, connect to the EMC.
4. Expand the Temperature Sensors group, and select either On Board or Remote. The On
Board item monitors temperatures in the computer chassis. The Remote item monitors
temperatures in the CPU area.
5. Click the Tasks tab in the List pane, and select Configure EMC Temperature Thresholds
from the displayed tasks list.
6. In the Presentation pane, follow the prompts to configure temperature thresholds.
7. Click Apply.

Configuring Voltage Sensors

If you want to be notified of critical changes in voltages in a server, you can configure a
voltage sensor threshold and configure Server Manager to notify you if the threshold is
exceeded. For information on configuring Server Manager to send alerts, see the Intel
LANDesk Server Manager v3.0 Administrator's Guide.
To configure voltage sensors:
1. In the Tree pane of the Server Manager Console, log onto the server for which you want
to set voltage sensor thresholds.
2. Expand the Tools group, and select Emergency Mgmt. Card Connection.
3. If necessary, connect to the EMC.
4. Expand the Voltage Sensors group, and select one of the voltage items: Minus 12 Volts
(voltage setting for the -12V power supply), Minus 5 Volts (voltage setting for the -5V
power supply), Plus 12 Volts (voltage setting for the +12V power supply), or Plus 5
Volts (voltage setting for the +5V power supply).
