The Server Manager Console is divided into three areas or panes:
Pane
Tree
List
Presentation
Each pane has vertical or horizontal scroll bars, if needed. The scroll bars display only if
there is more information than can be displayed in the pane.
You will use the Server Manager Console to complete the configuration tasks in the rest of
this chapter.

Updating the EMC Software and EMC BIOS

After you install the ISM software and configure the EMC, you may need to update the EMC
operating system software and the EMC BIOS.
To determine if an update is necessary:
1. In the Tree pane of the Server Manager Console, expand the Intel Management
Directory group, then the Local Network group, and then the Windows NT group. A
list of EMC servers on the local network displays.
2. The server names display like groups. Expand the server name, and then the Tools
group.
3. Select the Emergency Mgmt. Card Connection group.
Description
Use this pane to configure alert actions for out-of-band EMC events received
from another server, select a server you configured in the local network or
another network, and monitor SNMP traps. When you start the Server
Manager Console, this pane always shows the Intel Management Directory
group. You can select, expand, and collapse the Intel Management Directory
group just like you select, expand, and collapse directories in Explorer or File
Manager. When you select a group in this pane, its subgroups and properties
display in the List pane.
This pane displays a Properties list and/or a Tasks list for groups you select
in the Tree pane. The Properties list shows the current settings and
information for the group you select in the Tree pane. Click the Properties
tab in the List pane to display the Properties list. The Tasks list shows the
tasks you may perform or configure for each group you select in the Tree
pane. Click the Tasks tab in the List pane to display the Tasks list.
This pane displays information about items you select in the Properties list in
the List pane. It also displays configuration dialogs for items you select from
the Task list in the List pane.
