The Server Manager Console is divided into three areas or panes:
Pane
Tree
List
Presentation
Helpful Hints
u
Each pane has vertical or horizontal scroll bars, if needed. The scroll bars display only
if there is more information than can be displayed in the pane.
u
You can view an item or a portion of the Tree pane in a separate window for better
visibility. Select an item in the Tree pane and right-click the mouse. From the popup
menu, select Explore from here.
u
You can adjust the width of the columns in the List pane by placing the cursor on the
dividing line between columns. When the cursor changes to a two-headed horizontal
arrow cursor, click and drag the column divider with the mouse. Release the mouse
button when the columns are the desired width.
u
Some items in the Tree pane can be deleted. Select the item you want to delete and
right-click the mouse. From the popup menu, select Delete.
Description
Use this pane to configure alert actions for out-of-band EMC events received
from another server, select a server you configured in the local network or
another network, and monitor SNMP traps. When you start the Server
Manager Console, this pane always shows the Intel Management Directory
group. You can select, expand, and collapse the Intel Management Directory
group just like you select, expand, and collapse directories in Explorer or File
Manager. When you select a group in this pane, its subgroups and properties
display in the List pane.
This pane displays a Properties list and/or a Tasks list for groups you select
in the Tree pane. The Properties list shows the current settings and
information for the group you select in the Tree pane. Click the Properties
tab in the List pane to display the Properties list. The Tasks list shows the
tasks you may perform or configure for each group you select in the Tree
pane. Click the Tasks tab in the List pane to display the Tasks list.
This pane displays information about items you select in the Properties list in
the List pane. It also displays configuration dialogs for items you select from
the Task list in the List pane.
