Instruction Manual
Product Dimensions
Weight.......................................................................................................... 270 lbs.
Width (side-to-side) x Depth (front-to-back) x Height........................................ 14 x 24 x 64 in.
Footprint (Length x Width)......................................................................... 22-1/2 x 11 in.
Shipping Dimensions
Type.................................................................................................... Cardboard Box
Content........................................................................................................ Machine
Weight.......................................................................................................... 185 lbs.
Length x Width x Height........................................................................... 21 x 56 x 11 in.
Electrical
Power Requirement.................................................................... 110V, Single-Phase, 60 Hz
Prewired Voltage................................................................................................. 110V
Full-Load Current Rating......................................................................................... 10A
Minimum Circuit Size............................................................................................. 15A
Connection Type......................................................................................... Cord & Plug
Power Cord Included.............................................................................................. Yes
Power Cord Length.......................................................................................... 8-1/2 ft.
Power Cord Gauge............................................................................................ 16 AWG
Plug Included....................................................................................................... Yes
Included Plug Type............................................................................................... 5-15
Switch Type............................................................. Toggle Safety Switch w/Removable Key
Motors
Main
Type......................................................................... TEFC Capacitor-Start Induction
Horsepower................................................................................................. 1 HP
Phase.............................................................................................. Single-Phase
Amps.......................................................................................................... 10A
Speed.................................................................................................. 1725 RPM
Power Transfer ................................................................................... V-Belt Drive
Bearings............................................................... Shielded & Permanently Lubricated
Main Specifications
Construction
Table............................................................................. Precision-Ground Cast Iron
Spindle Housing....................................................................................... Cast Iron
Column..................................................................................................... Steel
Head.................................................................................................... Cast Iron
Base.................................................................................................... Cast Iron
Paint..................................................................................................... Enamel
MODEL W1680
1 HP 17" FLOOR MODEL DRILL PRESS
Model W1680 Machine Specifications, Page 1 of 3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Shop fox SHOP FOX W1680
Summary of Contents for Shop fox SHOP FOX W1680
- Page 1 MODEL W1680 1 HP 17" FLOOR MODEL DRILL PRESS Product Dimensions Weight......................270 lbs. Width (side-to-side) x Depth (front-to-back) x Height........14 x 24 x 64 in. Footprint (Length x Width)................. 22-1/2 x 11 in. Shipping Dimensions Type....................Cardboard Box Content......................
- Page 2 Head Information Head Swivel................... 360 deg. Other Related Information Base Length....................18 in. Base Width....................11 in. Quill Diameter..................2.040 in. Depth Stop Type............Threaded Rod with Positive Stop Column Diameter..................3.150 in. Mobile Base..................... D2057A Has Work Light....................Yes Light Socket Type................
- Page 3 Features Threaded Depth Stop Crank Handle Operated Rack and Pinion Vertical Table Movement Includes Built-in Light Table and Base are Cast Iron 1HP Motor 12 Speeds Huge 4-3/4" Spindle Travel Cushioned Grip Quill Handles 1/16"-5/8" Drill Chuck Model W1680 Machine Specifications, Page 3 of 3...
