Shop fox W1790 Instruction Sheet

Model W1790
⁄ " Reversible Air Drill
3
8
Instruction Sheet
Phone #: (360) 734-3482 • Online Tech Support: tech-support@shopfox.biz • Web: www.shopfox.biz
Always wear safety glasses during
use to prevent serious personal
injury!
Always disconnect tool from air to
prevent unexpected operation dur-
ing service!

Specifications

Drive Size..................................................................
No Load Speed..................................................1800 RPM
Average Air Consumption...............................................6
CFM Required PSI...................................................90 PSI
Air Inlet...............................................................
Inventory
A. Air Drill ........................................................................1
B.
⁄ " NPT Quick Connect Fitting (male) ........................1
1
4
C. Chuck Key ..................................................................1
Lubrication
Lubricate your air drill with pneumatic tool oil. If you do
not have a lubricator installed in your air line, place one
drop of pneumatic tool oil into the air fitting daily, as
shown in Figure 2.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
#9580JM
EYE INJURY HAZARD!
INJURY HAZARD!
INJURY HAZARD!
Never exceed 120 PSI!
COPYRIGHT © JUNE, 2007 BY WOODSTOCK INTERNATIONAL, INC.
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
Figure 1. Model W1790.
Quick
Connector
⁄ "
3 Your
8
Tool
Quick
Coupler
⁄ " NPT
1
4
Figure 2. Installing your tool.
Figure 3. Lubricating directly into air
Quick
Lubricator
Regulator
Connector
Quick
Air Hose
Filter
Coupler
fitting.
Printed in China
Air
Compressor
