Shop fox W1787 Instruction Sheet

Model W1787
⁄ " 2600 RPM Air Drill
3
8
Instruction Sheet
Phone #: (360) 734-3482 • Online Tech Support: tech-support@shopfox.biz • Web: www.shopfox.biz
Always wear safety glasses during
use to prevent serious personal
injury!
Always disconnect tool from air to
prevent unexpected operation dur-
ing service!

Introduction

The Model W1787 is ideal for production drilling
applications. It features a paddle switch with safety
release, 2,600 RPM free speed and
ity. Recommended air pressure is 90 PSI and average air
consumption is 6 CFM. Includes a
chuck key.

Inventory

A. Air Drill ......................................................1
B. ⁄ " NPT Air Fitting ........................................1
1
4
C. Chuck Key ...................................................1

Lubricating Your New Air Drill

Lubricate your air drill with pneumatic tool oil. If you do
not have a lubricator installed in your air line, place 1–2
drops of pneumatic tool oil into the air fitting daily, as
shown in Figure 3.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
#9574JM
EYE INJURY HAZARD!
INJURY HAZARD!
INJURY HAZARD!
Never exceed 120 PSI!
⁄ " drilling capac-
3
8
⁄ " NPT air fitting and
1
4
COPYRIGHT © JUNE, 2007 BY WOODSTOCK INTERNATIONAL, INC.
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
Figure 1. Model W1787.
Quick
Quick
Connector
Connector
Your
Tool
Quick
Coupler
Quick
Air Hose
Coupler
Figure 2. Installing your tool.
Figure 3. Lubricating directly into air
fitting.
Lubricator
Regulator
Air
Compressor
Filter
Printed in China
