2.
Periodically clean the table surface with a glass cleaning solution.
3.
Clean the monitor screen as required with a glass cleaning solution.
Activate the Stereoscopic Display
Verify that the stereo sync interface cable connects properly to the stereo port on the graphics
board (in the TDZ workstation base unit). Then follow the instructions in this section to view
images displayed by a 3D software application running on the system.
To activate the stereoscopic display:
1.
From the Windows NT Start menu, go to Settings/Control Panel/Display/Intergraph
Monitor (tab).
2.
Select the type of monitor connected to the system. The choices of monitor types for
ImageStation ZIII are as follows:
Intergraph 21sd115 (MDSP14709) is the 21-inch monitor
Intergraph 24hd96 (MDSP15104) is the 24-inch monitor
Intergraph 28hd96 (MDSP14305) is the 28-inch monitor
3.
Select Apply.
4.
Select Intergraph Settings (tab) and select the Advanced button.
5.
Select Enable Stereo Display and set the Monitor Scan to Interlaced; then select OK.
6.
Select Apply.
7.
Select Settings (tab) and set the resolution to 1280 x 1024.
8.
Select Test. After the test completes, select Apply.
9.
Restart the system.
10. In the Display Properties dialog, select the Settings tab and set the appropriate monitor
resolution. The recommended settings are 1280 x 1024 for a 21-inch monitor and 1920 x
1080 for the 24-inch and 28-inch monitors.
11. Select Test. After the test completes, select Apply.
12. Exit from the Display Properties dialog.
To view images in 3D:
1.
Activate the infrared glasses by opening the ear frames. The lenses turn black when they
are on and have a reddish-gold tint when they are off.
2.
Put on the infrared glasses to view images in 3D.
9
