Grizzly H7728 Instruction Sheet

Introduction

This rolling tool cart with tool box requires some
assembly. Follow the instructions under each
Figure on the following page.
To begin, lay out all of the parts and compare
quantities to the inventory list given below.
If you need additional help with these instructions,
call our service department at: (570) 546-9663.

Inventory

(Figure 1)
A. Tool Box w/ Upper Shelf ............................ 1
B. Side Support ............................................... 2
C. Bottom Shelf ............................................... 1
D. Vertical Support .......................................... 4
E. Handle ........................................................ 1
F. Plain Caster ................................................ 2
G. Pivoting Caster ........................................... 2
H. 8mm Hex Bolt ............................................. 2
I. 8mm Carriage Bolt ................................... 22
J.
8mm Hex Nut ........................................... 24
K. 6mm Phlps. Head Screw .......................... 16
L.
6mm Hex Nut ........................................... 16
M. 8mm Flat Washer ..................................... 24
N. Front/Back Support .................................... 2
O. Angle Bracket ............................................. 4
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
COPYRIGHT © SEPTEMBER, 2005 BY GRIZZLY INDUSTRIAL, INC.
#DD7590 PRINTED IN CHINA
MODEL H7728
ROLLING TOOL CART
INSTRUCTION SHEET
�
�
�
�
�
Figure 1. Inventory of parts.
�
�
�
�
�
�
�
�
�
��
