Grizzly H7724 Instructions

figure 1. model h7724 Birch Workbench.

features

• Lacquer-sealed birch wood surfaces.
• Four 19 ⁄ "W x 14"d x 2
1
4
drawers.
• two 19 ⁄ "W x 14"d x 4
1
4
drawers.
• two 21 ⁄ "W x 14
1
4
nets.
• Birch-faced vise with removable top plate and
6 ⁄ " leadscrew travel, 12
3
4
• Four chrome bench dogs.
• overall dimensions: 66
x 34" tall.
• shipping weight: 148 lbs.
Safety & Limitations
• maximum workbench table load is 500 lbs.
• do not stand or climb on the workbench.
• do not apply an unbalanced load on the table
that could result in workbench tipping over.
• Keep children away from the workbench.
• do not use workbench outdoors or in wet or
damp locations.
• do not overload the dogs or vise.
Copyright © ApriL 2009 By grizzLy industriAL, inC. rEVisEd dECEmBEr, 2011 (st)
WaRNINg: NO pORTION Of THIS MaNUaL May BE REpRODUCED IN aNy SHapE
OR fORM WITHOUT THE WRITTEN appROvaL Of gRIzzLy INDUSTRIaL, INC.
(For modELs mAnuFACturEd sinCE 12/11) #Cr11708 printEd in ChinA
⁄ "h ball-bearing slide
1
4
⁄ "h ball-bearing slide
1
4
⁄ "d x 12 ⁄ "h storage cabi-
3 1
4 2
⁄ " wide x 2 ⁄
1 3
2 4
⁄ " wide x 20" in depth
1
2
60" WORKBENCH

Inventory

use the parts breakdown and listing in figure 2
and on page 4 to arrange your workbench parts
and inventory your shipment.
if any nonproprietary parts are missing (e.g. a
bolt or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
Note: Refer to Page 4 for kit item part numbers.

assembly

" thick.
use the steps and figures below and refer to the
labels on the workbench parts to properly assem-
ble your workbench.

Tools Needed

phillips screwdriver #2 ...................................... 1
hex Wrench 4mm (included) ............................. 1
hex Wrench 5mm (included) ............................. 1
To assemble your workbench:
1. place the table (A) face down on the left over
shipping cardboard to avoid scratching the
workbench top.
MODEL H7724
INSTRUCTIONS
figure 2. Fastener kit inventory.
Qty
