• Tape measure
Tools &
• Spirit level
Materials
• Wire Cutter
• Wire stripper
Required
• Electric drill
(not supplied)
• Torx screwdriver
• 120V 60Hz 15 or 20 Amp, 2 wire with
• Metal ductwork, 3-1/4" x 24" or 10" round
1
• Cut and remove the plastic banding on the
crate and one holding the parts box.
Step
• Remove the top of the crate by backing out
screws.
• Break-away crate sides.
Remove the
• Remove the parts box and set aside.
Packaging
• Remove plastic wrapping and padding.
and
For easier handling during installation, the hood
Disassemble
can be separated into 3 assemblies. The hood is
laying on its back, bolted to the skid in 4 loca-
tions.
• Remove the assemblies shown for easier access
to the hold-down bolts.
• Remove 8 screws located on the inside front.
(30" models have fewer screws.) Lift off the
halogen light assembly and disconnect the
Light
Assembly
and appropriate bits
ground. Properly grounded branch circuit.
for 48" wide model. 7" to 10" round or
3-1/4" x 12" to 3-1/4" x 24" for 30" and 36"
models.
Inner Liner
Disconnect

Installation

Wall Mount Installation:
• Six, 5/16" lag screws, 2" long with washers,
all models (provided).
Soffit Installation:
• Six, 5/16" lag screws, 2" long with washers,
all models (provided).
Optional for wall mount installations: (See page 9)
• 48" x 18" plywood for 48" model,
36" x 18" plywood for 36" model,
30" x 18" plywood for 30" model.
male/female plug. Set aside.
• Remove 4 screws along inside front, 5 screws
along the inside back and 3 screws on each
side (30 and 36" models have fewer screws).
Remove the inner liner, disconnect the
male/female plugs, one to the heat lamp
and one to the blower. Set aside.
CAUTION: Control panel is held in place
with set screws and may fall out when inner
liner is removed.
• Remove the 4 bolts holding the hood to the
skid.
Through Junction Box on
Rough-In-Kit, Connect to
House Wiring
To Blower Motor
Hood Inner Liner
Professional Vent Hoods
Remove Screws That
Hold Inner Liner in Place.
7
