TVP5158 Evaluation Module
User's Guide
Literature Number: SLEU108
November 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TVP5158 and is the answer not in the manual?

Questions and answers

Summary of Contents for Texas Instruments TVP5158

  • Page 1 TVP5158 Evaluation Module User's Guide Literature Number: SLEU108 November 2009...
  • Page 2 SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 3: Table Of Contents

    ......................Property Sheets ................Video Decoder Select and Write Enables ................. Example TVP5158 Property Pages ........................ Troubleshooting ....................Troubleshooting Guide ....................TVP5158 EVM Schematics SLEU108 – November 2009 Table of Contents Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 4 Schematics (3 of 8) ......................Schematics (4 of 8) ......................Schematics (5 of 8) ......................Schematics (6 of 8) ......................Schematics (7 of 8) List of Figures SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 5 Troubleshooting Setup and General Issues ............Troubleshooting with THS8200 and CompositeVideo Output ..............Troubleshooting with DM6467 DaVinci HD EVM ............. Troubleshooting I2C Connections and Cascaded EVMs SLEU108 – November 2009 List of Tables Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 6: Description

    The TMS320DM6467 Digital Video Evaluation Module is usually referred to as the DaVinci HD EVM. The TMS320DM6467 Digital Media System-on-Chip is usually referred to as the DM6467. TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 7: Board Level Description

    YPbPr video signals to component output connector J4. The TLV320DAC32 Stereo Audio DAC takes digital audio output from TVP5158 and outputs analog audio to the head phone jack J5. SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 8: Digital Video/Audio Outputs To Davinci Hd Evm

    OFF: Control by another EVM for cascade mode. I2C SCL source selection 1-2: USB controls I2C 2-3: DaVinciHD controls I2C OFF: Control by another EVM for cascade mode. TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 9: System Level Description

    The user can also connect the TVP5158EVM to a DaVinci HD EVM and then output combined video from the DaVinci HD EVM to a 1080i HD monitor. Figure 2. TVP5158EVM System Level Block Diagram SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 10: Required Hardware And Equipment

    5. USB cable from PC to TVP5158EVM. A green LED should be lit indicating that the EVM is ready for communication on the USB. 6. 5-V power supply to the dc jack on the TVP5158EVM TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 11: Setup For Tvp5158Evm With Davinci Hd Evm

    Setup for TVP5158EVM with DaVinci HD EVM The TMS320DM6467 DVEVM (digital video evaluation module) can be used as the audio/video back-end processor for evaluation of TVP5158. This EVM is available separately from Texas Instruments and is referred to as the DaVinci HD EVM in this document.
  • Page 12: Hardware Modifcation For I2S Audio To Dm6467

    I2C programming of the TVP5158. In the latter case, the PC USB interface and the Video Control Center application software are used to initialize and experiment with TVP5158 register settings through a graphical user interface. TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 13: Jumper Settings For Davinci Hd Evm As Tvp5158 I2C Master

    DaVinci HD EVM). USB should be connected to the first stage EVM if used. The Audio DAC I2C must be disconnected on the second stage, since they are both at the same I2C slave address. SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 14: Software Installation

    Start > All Programs > TVP5158EVM > TVP5158EVM Software Start > All Programs > TVP5158EVM > TVP5158EVM User Guide Figure 4. TVP5158EVM Software Setup Wizard TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 15: Select Installation Folder

    Software Installation www.ti.com Figure 5. Select Installation Folder Figure 6. Confirm Installation SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 16: Installation Complete

    Software Installation www.ti.com Figure 7. Installation Complete TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 17: Tvp5158Evm Evaluation Procedures

    9. Video from the selected video input should now be seen on the monitor and audio channels 1 and 2 should be heard from the left and right speakers respectively. Figure 8. VCC Configuration SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 18: Specifying Cascaded Devices

    TVP5158EVM Evaluation Procedures www.ti.com Figure 9. Specifying Cascaded Devices Figure 10. USB Device Not Found Error Message Figure 11. Real-Time Polling Enable TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 19: Evaluation Using The Davinci Hd Evm

    Table 7. Recommended DM6467 Clock Frequencies ARM Clock 675 MHz DDR2 Memory Clock 324 MHz DaVinci HD EVM assembly revision F or later is required. SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 20 NOTE: See the mcvip_tvp5158\README.TXT file for instructions on running or building target image and application. This is found in the zip file containing the DaVinci HD video/audio driver source code. TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 21: Browse To Command File

    6. Click the Browse… button. The Open dialog box appears (see Figure 14). Double-click the file TVP5158EVM_DaVinci_HD_Setup.CMD Figure 14. Browse to Command File The dataset descriptions table should now appear (see Figure 15). SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 22: System Initialization For Line-Interleaved Modes

    TVP5158EVM Evaluation Procedures www.ti.com Figure 15. System Initialization for Line-Interleaved Modes TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 23: Mcvip_Test Demo Application Menu

    5. Audio should be heard from the left and right speakers respectively if audio mode option selected. Repeat steps 1 through 4 for each line-interleaved video output format. SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 24: Evaluation Of Pixel-Interleaved Digital Video Output Modes

    Click the PROGRAM button. The TVP5158 is now programmed to automatically detect the video standard received at the input and output video in the above pixel-interleaved format. Figure 17. System Initialization for Pixel Interleave Modes TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 25: Vcc Software In Depth

    NOTE: To save registers to a file, check the Histogram Enable checkbox and click Read All. Click Show to view the saved file. Figure 18. TVP5158 Register Map Editor SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 26: Property Sheets

    Edit Box with Up/Down Arrows Use up/down arrows or type a number Type a number: After Apply Slider Slide a lever Immediately Pushbutton Initiate an action Immediately TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 27: Video Decoder Select And Write Enables

    NOTE: The command files used by the System Initialization tool can override the write enable button settings. They are generally setup for writing to all decoders independent of the current write enable buttons setting. SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 28: Example Tvp5158 Property

    The Audio property page only exists for video decoder 1. To access the Audio controls Decoder 1 must be the selected decoder. TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 29: Tvp5158 Output Formatter Property Page With Decoder 1 Selected

    VCC Software in Depth www.ti.com Figure 21. TVP5158 Output Formatter Property Page With Decoder 1 Selected SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 30: Tvp5158 Output Formatter Property Page With Decoder 4 Selected

    VCC Software in Depth www.ti.com Figure 22. TVP5158 Output Formatter Property Page With Decoder 4 Selected TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 31: Tvp5158 Noise Reduction And Auto Contrast Property Page

    VCC Software in Depth www.ti.com Figure 23. TVP5158 Noise Reduction and Auto Contrast Property Page SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 32: Tvp5158 Audio Property Page (Seen Only When Decoder 1 Is Selected)

    VCC Software in Depth www.ti.com Figure 24. TVP5158 Audio Property Page (Seen Only When Decoder 1 is Selected) TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 33: Tdm I2S Audio Data Configuration

    TDM I2S audio data can be configured. Jumper W9 can be used to select the SD_R (default) or SD_M I2S output to the audio DAC. Figure 25. TDM I2S Audio Data Configuration SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 34: Troubleshooting

    Wrong digital audio Set jumper W9 across pins 2-3 to hear the record output (SD_R) or across output selected. 1-2 to hear the mixer output (SD_M). TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 35: Troubleshooting With Dm6467 Davinci Hd Evm

    HD EVM. Any changes to the above setup require that VCC be exited and restarted so that the correct I2C slave address(es) can be selected. SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 36: Tvp5158 Video Format Property Page

    Troubleshooting www.ti.com Figure 26. TVP5158 Video Format Property Page TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 37: Ths8200 Input Controls / Status Property Page

    Troubleshooting www.ti.com Figure 27. THS8200 Input Controls / Status Property Page SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 38: Tvp5158 Evm Schematics

    TVP5158 EVM Schematics www.ti.com TVP5158 EVM Schematics This section contains the TVP5158EVM schematics. Figure 28. Schematics (1 of 8) TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 39: Schematics (2 Of 8)

    TVP5158 EVM Schematics www.ti.com Figure 29. Schematics (2 of 8) SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 40: Schematics (3 Of 8)

    TVP5158 EVM Schematics www.ti.com TRSTn Figure 30. Schematics (3 of 8) TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 41: Schematics (4 Of 8)

    VSS33 VSS26 VSS20 VSS14 VSS12 VSS6 VSS1 VSSA1.8_124 VSSA1.8_123 VSSA1.8_117 VSSA1.8_111 VSSA1.8_110 VSSA1.8_100 VSSA1.8_98 VSSA1.8_96 VSSA1.1_118 VSSA1.1_105 VSSA1.1_104 Figure 31. Schematics (4 of 8) SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 42: Schematics (5 Of 8)

    AVSS12 AVDD11 GND_DLL VDD_DLL DVSS78 DVDD79 DVSS58 DVDD59 DVSS31 DVDD32 GND_IO72 VDD_IO70 GND_IO45 VDD_IO46 GND_IO20 VDD_IO19 N.C.80 N.C.1 Figure 32. Schematics (5 of 8) TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 43: Schematics (6 Of 8)

    TVP5158 EVM Schematics www.ti.com GND.1 GND.2 GND.3 GND.4 GND.5 GND.6 GND.7 GND.8 GND.1 GND.2 GND.3 GND.4 GND.5 GND.6 GND.7 GND.8 Figure 33. Schematics (6 of 8) SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 44: Schematics (7 Of 8)

    P3.3 P2.2 P3.4 NC23 P3.5 P2.0 P3.6 P3.7 NC64 NC63 VCC10 VDDOUT GND24 VCC39 GND42 VCC62 GND59 GND5 Figure 34. Schematics (7 of 8) TVP5158 Evaluation Module SLEU108 – November 2009 Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 45 TVP5158 EVM Schematics www.ti.com Figure 35. Schematics (8 of 8) SLEU108 – November 2009 TVP5158 Evaluation Module Submit Documentation Feedback Copyright © 2009, Texas Instruments Incorporated...
  • Page 46: Important Notice

    IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete.
