C O N C E N T R I C ™
D U A L
O W N E R ' S
M A N U A L
Advertisement
Related Manuals for Tannoy EYRIS DUAL CONCENTRIC
Summary of Contents for Tannoy EYRIS DUAL CONCENTRIC
- Page 1 Tannoy United Kingdom T: +44 (0) 1236 420199 F: +44 (0) 1236 428230 E: enquiries@tannoy.com Tannoy North America T: (519) 745 1158 F: (519) 745 2364 E: inquiries@tannoyna.com Tannoy adopts a policy of continuous improvement and product specification is subject to change.
- Page 2 If the equipment proves to be defective within this period for any reason other than accident, misuse, unauthorised modification or fair wear and tear, Tannoy will repair any such defect or, at our option, replace it without charge for instrumentation.
-
Page 3: Installation
CABLE CHOICE WARNING: Always use the best quality of cable available within your budget. High quality audio signals passing ENSURE THAT THE SPIKES ARE LEVELLED AND THAT THE LOCK NUTS ARE TIGHTENED FIRMLY. from the amplifier to the loudspeaker are unusual in their demands on the cable. Wide dynamic range THE SPIKES SHOULD BE PUSHED THROUGH THE CARPET TO LOCATE INTO THE FLOORING and frequency bandwidth information has to coexist with the ability to transmit peak currents of at least SURFACE BY APPLYING PRESSURE TO THE TOP OF THE CABINET. - Page 4 HF and LF terminals and remove the link bar and then replace the colour- To get best results from your new Tannoy Eyris DC loudspeakers it is worthwhile spending a little time coded nuts, as they will be required to clamp the bi-wire cables in place. Retain the link bars in a safe finding the optimum set-up configuration.
- Page 5 The Eyris DCC centre channel speaker is fully magnetically shielded and designed for installation and require specialist repair by your Tannoy dealer. Any such damage will not be covered under directly above or below the TV. As the main effects speaker for the front soundstage, the critical factor warranty.
-
Page 6: Technical Specifications
TECHNICAL SPECIFICATIONS SET-UP DIAGRAMS FIG. 1 Unpacking Eyris DC1 Eyris DC3 Eyris DCC PERFORMANCE Recommended amplifier power 20-150 20-175 20-175 Watts RMS Continuous power handling Watts Peak Peak power handling - Watts Sensitivity (2.83 Volts @ 1m) 88dB 89dB 89dB Nominal Impedance - Ohms Low frequency alignment (-6dB) 39Hz... - Page 7 SET-UP DIAGRAMS SET-UP DIAGRAMS FIG. 3 DC Terminal Panel FIG. 5 DC Bi-Wire Mode HIGH FREQUENCY HIGH FREQUENCY NEGATIVE(-) TERMINAL POSITIVE(+) TERMINAL TO RIGHT SPEAKER LOW FREQUENCY LOW FREQUENCY NEGATIVE(-) TERMINAL POSITIVE(+) TERMINAL TO 'GROUND' OR 'EARTH' CONNECTION POWER AMPLIFIER ON AMPLIFIER (OPTIONAL) LINKS REMOVED 'EARTH' OR 'GROUND' TERMINAL...
