Summary of Contents for Tannoy Eclipse

  • Page 1 OWNER’S MA NUA L...

  • Page 2: Table Of Contents

    No maintenance of the loudspeaker is necessary. As part of the MUSIC Group, Tannoy is committed to providing the highest quality products, service and user experience for our customers. One element of this commitment is our after sales support which now incorporates our extended Limited Warranty.

  • Page 3: Introduction

    INTRODUCTION Thank you for selecting Eclipse loudspeakers developed in the UK by our dedicated team of design engineers. They are the choice of discriminating music lovers the world over. Musical excellence is designed into our loudspeakers from the start. Careful selection of the very best components combined with strict quality control procedures in the production process ensures this level of excellence is maintained.

  • Page 4: Fitting Of Accessories

    TWO & THREE: FLOOR STANDING MODELS The Eclipse floor standing models perform best with the plinth and carpet piercing spikes fitted, giving optimum stability and sound quality. First fit the plinth sections to the underside of the loudspeaker with the 4 screws provided, taking care not to over tighten.

  • Page 5: Positioning And Fine-Tuning

    POSITIONING AND FINE-TUNING To get best results from your new Eclipse loudspeakers it is worthwhile spending a little time finding the optimum setup configuration. Begin by angling the speakers towards your chosen listening position, usually this is on the centre line of the room, so that when seated you can just see the inner side panel of each speaker.

  • Page 6: Technical Specification

    (incl. plinth* & grille) (11.8 x 6.7 x 10”) (35.8 x 10.6 x 10.9”)* (37.8 x 10.6 x 10.9”)* Net weight 4.5 kg (9.9 lbs) 11.5 kg (25.4 lbs) 12.1 kg (26.7 lbs) Finish Black Oak Black Oak Black Oak 06_ ECLIPSE MANUAL...
  • Page 7 TECHNICAL SPECIFICATIONS ECLIPSE MINI ECLIPSE CENTRE PERFORMANCE Recommended amplifier power 15 - 60 15 - 90 (Watts RMS) Continuous power handling (Watts RMS) Peak power handling (Watts) Sensitivity (2.83 Volts @ 1 m) 86 dB 90 dB Nominal impedance (Ohms) Frequency response (-6 dB) 58 Hz –...

  • Page 8: Set Up Diagrams

    SET-UP DIAGRAMS Fig.1 Eclipse Plinth Assembly Fig. 2 Connection, All Models TO RIGHT SPEAKER POWER AMPLIFIER 08_ ECLIPSE MANUAL...
  • Page 9 SET-UP DIAGRAMS Fig.3 Recommended positioning - Stereo pair Fig.4 Recommended Positioning - Home Cinema ECLIPSE MANUAL_09...
  • Page 10 NOTES 010_ ECLIPSE MANUAL...
  • Page 11 NOTES ECLIPSE MANUAL_011...
  • Page 12 Tannoy Limited - product designed in the United Kingdom. Tannoy operates a policy of continuous research and development.The introduction of new materials or manufacturing methods will always equal or exceed the published specifications. All specifications are subject to change without notice.
