LS 3603
Product Reference Guide

Advertisement

Table of Contents
loading

Related Manuals for Symbol LS 3603

Summary of Contents for Symbol LS 3603

  • Page 1 LS 3603 Product Reference Guide...
  • Page 2 LS 3063 Product Reference Guide 70-13584-01 Revision C — June 1999 Symbol Technologies, Inc. One Symbol Plaza, Holtsville N.Y. 11742...

  • Page 3: Product Reference Guide

    LS 3603 Product Reference Guide 70-13584-01 Revision C June 1999...
  • Page 4 Symbol. No right to copy a licensed program in whole or in part is granted, except as permitted under copyright law. The user shall not modify, merge, or incorporate any form or portion of a licensed program with other program material, create a derivative work from a licensed program, or use a licensed program in a network without written permission from Symbol.

  • Page 5: Table Of Contents

    Scan the Entire Symbol ........
  • Page 6 Chapter 2. Programming Overview............... . 2-1 Scanning Sequence Examples .
  • Page 7 •Wand Emulator Options ........... . 2-16 Wand Emulator Bar Output .
  • Page 8 Wand Host Interface ............. 3-37 Wand Host .

  • Page 9: Chapter 1 User's Guide

    Chapter 1 User’s Guide Scanning Made Easy The LS 3603 features Symbol Technologies’ patented “fuzzy logic” technology. This innovation provides artificial intelligence that compensates for poor quality bar codes and gives the LS 3603 the best first-time read rate anywhere.

  • Page 10: Set Up

    Set Up Unpacking Remove the scanner from its packing and inspect it for damage. If the scanner was damaged in transit, call the Symbol Support Center at one of the telephone numbers listed on page 1-15. KEEP THE PACKING. It is the approved shipping container and should be used if you ever need to return your equipment for servicing.

  • Page 11: Rs-232C

    User’s Guide RS-232C For external power operation with single-piece cable Plug the scanner into the appropriate port on the host device. • Connect the power supply to the input receptacle located near the host • end of the cable.* Typical Host Connector Figure 1-1.

  • Page 12: For Battery Operation

    LS 3603 Product Reference Guide RS-232C (Contd) For battery operation: Insert a 9-volt battery into the battery box. See the Battery Box • Operation section on page 1-10. Plug the scanner's 9-pin connector at the end of the coil cord into one •...

  • Page 13: Wand Emulation

    User’s Guide Wand Emulation For external power operation: Plug the 9-pin connector at the end of the scanner's coil cord into one • end of the battery box. Use the appropriate output cable from the battery box to connect the •...

  • Page 14: Ocia, Ocr, Ibm 4683, Keyboard Wedges

    LS 3603 Product Reference Guide Wand Emulation (Contd) Figure 1-3. Wand Emulation OCIA, OCR, IBM 4683, Keyboard Wedges See the instructions packed with the appropriate Synapse cable.

  • Page 15: Ready, Test, Scan

    Aim the scanner away from you and press the trigger. When you press the trigger, the scanning beam is energized for approximately 3.0 seconds (default). 3. Scan Make sure the symbol you want to scan is within the scanning range. See the LS 3603 Decode Zone diagram on page 1-11.

  • Page 16: Aiming

    LS 3603 Product Reference Guide Aiming Scan the Entire Symbol Your scan beam must cross every bar and space on the symbol. • The larger the symbol, the farther away you should hold the scanner. • Hold the scanner closer for symbols with bars that are close together.

  • Page 17: Hands Free

    Place the LS 3603 in the stand, and it automatically turns on in a blinking, hands-free mode. Any symbol passed over the red scan line will be decoded. To conserve power, after a short period of time of non-use, the scanner will operate in a reduced power mode.

  • Page 18: Battery Box Operation

    LS 3603 Product Reference Guide Battery Box Operation When using the LS 3603 with a battery box, you can use either an alkaline battery (recommended), or a nickel-cadmium rechargeable battery. Low battery power is signaled by four short, high tone beeps, coupled with scanning interruptions.

  • Page 19: Ls 3603 Decode Zone

    User’s Guide LS 3603 Decode Zone Figure 1-4. LS 3603 Decode Zone 1-11...

  • Page 20: Maintenance

    LS 3603 Product Reference Guide Maintenance Cleaning the exit window is the only maintenance required. Do not allow any abrasive material to touch the window. • Remove any dirt particles with a damp cloth. • Wipe the window using a damp cloth, and if necessary, a non-ammonia •...

  • Page 21: What If

    Make sure the scanner is programmed to read the type of bar code you • are scanning. Check for loose cable connections. • Check the symbol to make sure it is not defaced. • Try scanning test symbols of the same code type. • Symbol is decoded, but not transmitted to the host...

  • Page 22: Factory Service

    LS 3603 Product Reference Guide Factory Service If you have a problem, contact the Symbol Support Center at the telephone number on page 1-15. Before calling, have the model number and several of your bar code symbols at hand. Call the Support Center from a phone near the scanning equipment so that the service person can try to talk you through your problem.

  • Page 23: Symbol Support Center

    Symbol Support Center In the U.S.A., for service information, warranty information or technical assistance call: SYMBOL SUPPORT CENTER 1-800-653-5350 If you purchased your Symbol product from a Symbol Business Partner, contact that Business Partner for service. Canada Mississauga, Ontario Canadian Headquarters...

  • Page 24: Accessories

    LS 3603 Product Reference Guide Accessories Required Accessories LS 3603 scanners are sent as a package with required accessories, listed in the Product Ordering Guide. Optional accessories are available at extra cost. Optional Accessories Optional accessories, listed in the Product Ordering Guide, include various stands and holders, which are supplied at extra cost.

  • Page 25: Technical Specifictions

    User’s Guide Technical Specifictions Table 1-1. Technical Specifications ITEM DESCRIPTION Power Requirements* 4.8 (min) to 14.0 VDC (max) Wand 150 mA @ 5V typical RS-232C 150 mA @ 5V typical 150 mA @ 5V typical Synapse Decode Capability The LS 3603 can be programmed to decode the following code types: UPC/EAN, Code 39, Code 39 Full ASCII, Codabar, Interleaved 2 of 5, Code 128, EAN 128, Discrete 2 of 5, Code 93, and MSI/Plessey.
  • Page 26 CDRH Class II IEC 825 Class 2 *For direct host power connection, make sure the host terminal supplies sufficient power for the specified operation. Symbol is not responsible for damage to host equipment or system mis-operation due to an insufficient power condition.

  • Page 27: Pin-Outs

    User’s Guide Pin-outs Table 1-2. Pin-outs RS-232 Wand Synapse Not Used Not Used Not Used 4.8-14.0V 4.8-14.0V 4.8-14.0V Ground Ground Ground Not Used RTS Output RTS Output RxD Input Not Used Not Used Not Used ZIF_CLOCK Not Used Not Used DTR Output Not Used TxD Output...
  • Page 28 LS 3603 Product Reference Guide 1-20...

  • Page 29: Chapter 2 Programming

    Chapter 2 Programming Overview Before programming, follow the instructions beginning on page 1-2 The LS 3603 is programmed by scanning appropriate bar codes. The bar codes are arranged in RS-232C, Wand and Synapse sections. Not all of the available parameters necessarily apply to your specific host systems. If, for example, the selected host is a wand emulator, and you enable Baud Rate, the parameter will be ignored until such time as a host recognizing that parameter is selected.

  • Page 30: Scanning Sequence Examples

    LS 3603 Product Reference Guide Scanning Sequence Examples In most cases you need only scan one bar code to set a specific parameter. For example, if you want to add Code 39 to the Wand parameters, simply scan the Add Code 39 bar code in the Wand Code Types section. The LS 3603 will issue a warble tone, signifying a successful parameter entry.
  • Page 31 Programming RS-232C Options Set Default Parameter Baud Rate 2-10 Host Interface Code Parity 2-10 Code Types Beep on BEL 2-10 Code Lengths Hardware Handshaking 2-10 Code 39 Full ASCI Software Handshaking 2-13 Decode Options Stop Bit Select 2-15 UPC-E/UPC-A Check Digit ASCII Data Format 2-15 Convert UPC-E to UPC-A...

  • Page 32: Parameter Descriptions

    LS 3603 Product Reference Guide Parameter Descriptions • Set Parameter Defaults Scanning the SET ALL DEFAULTS bar code on page 3-3 returns all parameters to the values listed in the Default Table. (See page 2-29.) • Host Interface Code Scan the bar code corresponding to your host type. You must select a host type when you first set up the scanner and whenever you change host types.

  • Page 33: Code 39 Full Ascii

    This parameter adds five leading zeros to decoded EAN-8 symbols to make them compatible in format to EAN-13 symbols. Transmit “No Decode” Message This feature gives you the option to transmit “NR” when a symbol does not decode. Prefixes and suffixes enabled will be appended around this message.

  • Page 34: Decode Upc/Ean Supplemental

    Code 39 Check Digit When enabled, this parameter checks the integrity of a Code 39 symbol to ensure it complies with the modulo 43 check digit algorithm. ITF-14/EAN-13 Conversion If your terminal supports EAN-13, this feature converts a 14 character I 2 of 5 code into EAN-13, and transmits to the host as EAN-13.

  • Page 35: Code 39 Buffering (Scan & Store)

    The leading space is not buffered. Decode of a valid Code 39 symbol with no leading space causes transmission in sequence of all buffered data in a first-in first-out format, plus transmission of the “triggering”...

  • Page 36: Upc/Ean Security Level

    Selection of this level will significantly impair the decoding aggressiveness of the scanner. Decode Redundancy for Codabar When enabled, a Codabar symbol must be decoded in both directions before being accepted as a successful decode.

  • Page 37: Upc A And E Preamble

    • no preamble • The system character is the digit printed to the extreme left of a UPC symbol. The country code for UPC is always zero, and it cannot be transmitted without the system character. • Data Transmission Formats Select the desired scan data format from one of the following: <data>...

  • Page 38: Rs-232C Options

    LS 3603 Product Reference Guide •RS-232C Options Baud Rate Baud rate is the number of bits of data transmitted per second. The scanner's baud rate setting must match the data rate setting of the host device. If not, data will not reach the host device or may reach it in distorted form.
  • Page 39 Programming RS-232C Options (Continued) Hardware Handshaking If RTS/CTS handshaking is selected, scan data is transmitted with the following sequence: (Note that the DTR signal is hard wired active.) The scanner reads the CTS line for activity. If CTS is asserted, the scanner •...
  • Page 40 LS 3603 Product Reference Guide RS-232C Options (Continued) Figure 2-1. Hardware Handshaking 2-12...

  • Page 41: Software Handshaking

    Programming RS-232C Options (Continued) Software Handshaking This parameter controls the data transmission process. It may be used instead of, but not in conjunction with, hardware handshaking. The scanner provides five software handshaking options, listed below. Refer to the flow chart on the following page. 1.
  • Page 42 LS 3603 Product Reference Guide RS-232C Options (Continued) Software Handshaking 5. XON/XOFF When enabled, the scanner assumes an XON for the first transmission, and transmits scanned data until an XOFF is received. Transmission continues when an XON character is received. This option is automatically disabled when the unit is in Low Power mode.

  • Page 43: Stop Bit Select

    • Transmit AIM ID Character Enabling this parameter, with the Transmit Code ID Character parameter enabled allows you to send the AIM code identifier in lieu of the Symbol identifiers listed above. The identifier will be sent as a three character prefix, in accordance with AIM specifications for symbology identifiers.

  • Page 44: Power Mode

    LS 3603 Product Reference Guide • Power Mode This parameter determines whether or not power remains on after a decode attempt. When in low power mode, the scanner powers down after each decode attempt. When in continuous power mode, power remains on after each decode attempt.

  • Page 45: Supported Features By Host Type

    Programming Supported Features By Host Type Table 2-1. Supported Features by Host Type DECODE PARAMETERS RS-232C Wand Synapse Add Codes to be Decoded ASCII Format Bar High/ Bar Low Baud Rate Beep After Good Decode Beep on BEL Code 39 Buffering Code 39 Check Digit Convert All to Code 39 Convert UPC-E to A...
  • Page 46 LS 3603 Product Reference Guide Table 2-1. (Continued) Supported Features by Host Type DECODE PARAMETERS RS-232C Wand Synapse Scanstand/Intellistand Software Handshaking Transmit AIM ID Character Transmit Code ID Character Transmit MSI Check Digit Transmit No Decode Message Transmit UPC-A Check Digit...

  • Page 47: Beeper Indications

    Beeper Indications Table 2-2. Beeper Indications Standard Use Beeper Sequence Indication A bar code symbol was decoded (if decode beeper 1 Beep - short high tone is enabled). Low battery power. 4 Beeps - short high tone A format or transmission error has been detected in 4 Beeps - long low tone a scanned symbol.
  • Page 48 LS 3603 Product Reference Guide Table 2-2. (Continued) Beeper Indications Code 39 Buffering Beeper Sequence Indication 1 Beep - hi/lo tone New Code 39 data was entered into the buffer. 3 Beeps - long high tone Code 39 buffer is full.

  • Page 49: Code 39 Buffering

    Transmit Buffer) or clear the buffer. Buffer Data To buffer data, Code 39 buffering must be enabled, and a symbol must be read with a space immediately following the start pattern. • Unless symbol overflows the transmission buffer, unit gives hi/lo beep to indicate successful decode and buffering.

  • Page 50: Transmit Buffer

    If the symbol just read will result in an overflow of the transmission buffer: • Unit indicates that the symbol has been rejected by issuing three long, high beeps. • No transmission will occur. Data in buffer is not affected.

  • Page 51: Ascii Character Set

    Programming ASCII Character Set Table 2-3. ASCII Character Set ASCII Full ASCII Keystroke ASCII Full ASCII Keystroke Code 39 Code 39 Value Value Encode Char. Encode Char 1000 CTRL 2 1024 CTRL X 1001 CTRL A 1025 CTRL Y 1002 CTRL B 1026 CTRL Z...
  • Page 52 LS 3603 Product Reference Guide Table 2-3. (Continued) ASCII Character Set ASCII Full ASCII Keystroke ASCII Full ASCII Keystroke Code 39 Code 39 Value Value Encode Char. Encode Char 1048 1073 1049 1074 1050 1075 1051 1076 1052 1077 1053...
  • Page 53 Programming Table 2-3. (Continued) ASCII Character Set ASCII Full ASCII Keystroke ASCII Full ASCII Keystroke Code 39 Code 39 Value Value Encode Char. Encode Char 1098 1113 1099 1114 1100 1115 1101 1116 1102 1117 1103 1118 1104 1119 1105 1120 1106 1121...
  • Page 54 LS 3603 Product Reference Guide Table 2-3. (Continued) ASCII Character Set ALT Keys Keystroke ALT Keys Keystroke ALT Keys Keystroke 2064 ALT 2 2075 ALT K 2086 ALT V 2065 ALT A 2076 ALT L 2087 ALT W 2066 ALT B...
  • Page 55 Programming Table 2-3. (Continued) ASCII Character Set PF Keys Keystroke PF Keys Keystroke PF Keys Keystroke 4001 PF 1 4009 PF 9 4017 PF 17 4002 PF 2 4010 PF 10 4018 PF 18 4003 PF 3 4011 PF 11 4019 PF 19 4004...
  • Page 56 LS 3603 Product Reference Guide Table 2-3. (Continued) ASCII Character Set Numeric Keystroke Numeric Keystroke Numeric Keystroke Keypad Keypad Keypad 6042 6049 6056 6043 6050 6057 6044 Undefined 6051 6058 Enter 6045 6062 6059 Num Lock 6046 6063 6060 6047...

  • Page 57: Default Table

    Programming Default Table Table 2-4. Default Table Parameter Default Host Interface RS-232C Code Types Code Length I 2 of 5 D 2 of 5 Decode Options Transmit UPC-A Check Digit Enabled Enabled Transmit UPC-E Check Digit Convert UPC-E to UPC-A Disabled Disabled EAN Zero Extend...
  • Page 58 LS 3603 Product Reference Guide Table 2-4. (Continued) Default Table Parameter Default Laser On Time-out 3 Sec Low Power (Continuous for Synapse only) Power Mode Scanstand/Intellistand Time-out 60 minutes RS-232C Options 9600 Baud Rate Parity Even Beep on BEL Disabled...

  • Page 59: Terminal Specific Rs-232C

    Programming Terminal Specific RS-232C Three RS-232C hosts are set up with their own fixed format options. Selecting the ICL, Fujitsu or Nixdorf RS-232C terminal will set the defaults listed below. Table 2-5. Terminal Specific Defaults Parameter Standard FUJITSU NIXDORF Transmit Code ID Data Transmission Format Data as is Data/Suffix...
  • Page 60 LS 3603 Product Reference Guide 2-32...

  • Page 61: Chapter 3 Parameter Menus

    Chapter 3 Parameter Menus Set Default Parameter page 3-3 Host Interface Select page 3-4 RS-232C Parameters Fixed Format Options page 3-5 Code Types page 3-6 Code 2 of 5 Lengths page 3-9 Decode Options page 3-11 UPC-A Preamble page 3-17 UPC-E Preamble page 3-18 Intercharacter Delay...
  • Page 62 LS 3603 Product Reference Guide Wand Host Parameters Wand Host Interface page 3-37 Code Types page 3-38 Code 2 of 5 Lengths page 3-41 Decode Options page 3-43 Laser On Time-out page 3-45 Scanstand/IntelliStand Time-out page 3-47 Power Mode page 3-48...

  • Page 63: Set Default Parameters

    Parameter Menus Set Default Parameters Refer to the Default Table on page 2-29 To set defaults for any or all host types, scan the appropriate bar code below. Then select a specific host interface on the next page. SET RS-232C DEFAULTS SET WAND DEFAULTS SET SYNAPSE DEFAULTS SET ALL DEFAULTS...

  • Page 64: Host Interface Select

    LS 3603 Product Reference Guide Host Interface Select To select a host interface, scan the appropriate bar code below. SET RS-232C HOST SET WAND HOST SET SYNAPSE HOST...

  • Page 65: Rs-232 Host

    Parameter Menus RS-232 Host Fixed Format Options Select fixed format options for the terminals listed below. SET NIXDORF RS-232C FORMATS SET FUJITSU RS-232C FORMATS SET ICL RS-232C FORMATS...

  • Page 66: Code Type

    LS 3603 Product Reference Guide RS-232 Host Code Type Add or delete specific code types by scanning the appropriate bar code(s). ADD CODE 39 DELETE CODE 39 DELETE UPC-A ADD UPC-A DELETE UPC-E ADD UPC-E DELETE CODABAR ADD CODABAR...
  • Page 67 Parameter Menus RS-232 Host Code Type ADD EAN-8 DELETE EAN-8 DELETE EAN-13 ADD EAN-13 DELETE I 2 OF 5 ADD I 2 OF 5 ADD D 2 OF 5 DELETE D 2 OF 5...
  • Page 68 LS 3603 Product Reference Guide RS-232 Host Code Type ADD CODE 128 DELETE CODE 128 ADD MSI/Plessey DELETE MSI/Plessey DELETE CODE ADD CODE 93 ADD EAN 128 DELETE EAN 128...

  • Page 69: Code 2 Of 5 Lengths

    Parameter Menus RS-232 Host Code 2 of 5 Lengths To set the lengths for each code type: 1. Scan the desired option. 2. Scan two bar codes on page 3-10 for each desired length. For example, for a length of “12”, scan “1” then “2”. For a length of “3”, scan “0”, then “3”. You must always scan two bar codes for each length.

  • Page 70: Host

    LS 3603 Product Reference Guide RS-232 Host Code Lengths CANCEL 3-10...

  • Page 71: Decode Options

    Parameter Menus RS-232 Host Decode Options DO NOT TRANSMIT UPC-A TRANSMIT UPC-A CHECK DIGIT CHECK DIGIT DO NOT TRANSMIT UPC-E TRANSMIT UPC-E CHECK DIGIT CHECK DIGIT DO NOT CONVERT CONVERT UPC-E TO UPC-A UPC-E TO UPC-A 3-11...
  • Page 72 LS 3603 Product Reference Guide RS-232 Host Decode Options DECODE UPC/EAN IGNORE UPC/EAN WITH SUPPLEMENTALS WITH SUPPLEMENTALS AUTODISCRIMINATE UPC/EAN WITH SUPPLEMENTALS ENABLE EAN ZERO EXTEND DISABLE EAN ZERO EXTEND TRANSMIT “NO DECODE” DO NOT TRANSMIT MESSAGE “NO DECODE” MESSAGE 3-12...
  • Page 73 Parameter Menus RS-232 Host Decode Options ENABLE CLSI EDITING DISABLE CLSI EDITING ENABLE NOTIS EDITING DISABLE NOTIS EDITING DISABLE CODE 39 ENABLE CODE 39 FULL ASCII FULL ASCII VERIFTY CODE 39 DO NOT VERIFY CODE 39 CHECK DIGIT CHECK DIGIT 3-13...
  • Page 74 LS 3603 Product Reference Guide RS-232 Host Decode Options ITF-14/EAN-13 CONVERSION ITF-14/EAN-13 CONVERSION DISABLED ENABLED DO NOT BEEP AFTER GOOD DECODE BEEP AFTER GOOD DECODE DO NOT BUFFER CODE 39 BUFFER CODE 39 3-14...
  • Page 75 Parameter Menus RS-232 Host Decode Options UPC/EAN SECURITY LEVEL 0 UPC/EAN SECURITY LEVEL 1 UPC/EAN SECURITY LEVEL 2 UPC/EAN SECURITY LEVEL 3 3-15...
  • Page 76 LS 3603 Product Reference Guide RS-232 Host Decode Options ENABLE 2 MSI/Plessey ENABLE 1 MSI/Plessey CHECK DIGITS CHECK DIGIT MSI 2 CHECK DIGITS MSI 2 CHECK DIGITS MOD 10 - MOD 10 MOD 11 - MOD 10 ENABLE CODABAR DISABLE CODABAR...

  • Page 77: Upc-A Preamble

    Parameter Menus RS-232 Host UPC-A Preamble Select one option for UPC-A preamble by scanning the appropriate bar code. NONE SYSTEM CHARACTER SYSTEM CHARACTER & COUNTRY CODE 3-17...

  • Page 78: Upc-E Preamble

    LS 3603 Product Reference Guide RS-232 Host UPC-E Preamble Select one option for UPC-E preamble by scanning the appropriate bar code. NONE SYSTEM CHARACTER SYSTEM CHARACTER & COUNTRY CODE 3-18...

  • Page 79: Intercharacter Delay

    Parameter Menus RS-232 Host Intercharacter Delay To set a host communications intercharacter delay: 1. Scan the INTERCHARACTER DELAY bar code below. 2. Scan two bar codes on the next page which represent the desired delay (from 00 to 99 msec). You must always scan two bar codes. 3.
  • Page 80 LS 3603 Product Reference Guide RS-232 Host Intercharacter Delay CANCEL 3-20...

  • Page 81: Data Transmission Formats

    Parameter Menus RS-232 Host Data Transmission Formats Scan the option you wish to set. DATA AS IS <PREFIX> <DATA> <DATA> <SUFFIX> <PREFIX> <DATA> <SUFFIX> 3-21...

  • Page 82: Prefix/Suffix Values

    LS 3603 Product Reference Guide RS-232 Host Prefix/Suffix Values To set a PREFIX/SUFFIX value: 1. Scan the option bar code you wish to set. 2. Scan four bar codes on the next page which correspond to the ASCII value or keystroke you wish to assign. The ENTER key is the default for all options.
  • Page 83 Parameter Menus RS-232 Host Prefix/Suffix Values CANCEL 3-23...

  • Page 84: Transmit Code Id Character

    LS 3603 Product Reference Guide RS-232 Host Transmit Code ID Character Select whether to enable or disable this parameter. TRANSMIT CODE ID CHARACTER DO NOT TRANSMIT CODE ID CHARACTER 3-24...

  • Page 85: Transmit Aim Id Character

    Parameter Menus RS-232 Host Transmit AIM ID Character Select whether to enable or disable this parameter. TRANSMIT AIM ID CHARACTER DO NOT TRANSMIT AIM ID CHARACTER 3-25...

  • Page 86: Laser On Time-Out

    LS 3603 Product Reference Guide RS-232 Host Laser On Time-out To select a laser on time-out, scan the bar code below or on the next page corresponding to the desired time. 0.5 SECONDS 1.0 SECONDS 2.0 SECONDS 1.5 SECONDS 3.0 SECONDS 2.5 SECONDS...
  • Page 87 Parameter Menus RS-232 Host Laser On Time-out 3.5 SECONDS 4.0 SECONDS 4.5 SECONDS 5.0 SECONDS 3-27...

  • Page 88: Scanstand/Intellistand Time-Out

    LS 3603 Product Reference Guide RS-232 Host Scanstand/IntelliStand Time-out To select a Scanstand/IntelliStand time-out, scan the bar code below corresponding to the desired time-out. 15 MINUTES 60 MINUTES 75 MINUTES 30 MINUTES 90 MINUTES 45 MINUTES 3-28...

  • Page 89: Baud Rate

    Parameter Menus RS-232 Host Baud Rate Set the baud rate for RS-232C transmission. 4800 1200 9600 2400 19200 3-29...

  • Page 90: Parity

    LS 3603 Product Reference Guide RS-232 Host Parity Set the type of parity for RS-232C transmission. EVEN MARK SPACE NONE 3-30...

  • Page 91: Beep On Bel

    Parameter Menus RS-232 Host Beep on BEL Select whether or not enable this parameter. BEEP ON BEL DO NOT BEEP ON BEL 3-31...

  • Page 92: Hardware Handshaking

    LS 3603 Product Reference Guide RS-232 Host Hardware Handshaking Select the type of RS-232C hardware handshaking protocol. NONE RTS/CTS 3-32...

  • Page 93: Software Handshaking

    Parameter Menus RS-232 Host Software Handshaking Select the type of RS-232C software handshaking protocol. NONE ACK/NAK ENQ ONLY ACK/NAK with ENQ XON/XOFF 3-33...

  • Page 94: Stop Bit Select

    LS 3603 Product Reference Guide RS-232 Host Stop Bit Select Select the desired number of stop bits for RS-232C communications. 1 STOP BIT 2 STOP BITS 3-34...

  • Page 95: Ascii Data Format

    Parameter Menus RS-232 Host ASCII Data Format Select either 7-bit or 8-bit ASCII format for RS-232C communications. 7-BIT 8-BIT 3-35...

  • Page 96: Power Mode

    LS 3603 Product Reference Guide RS-232 Host Power Mode Select whether the laser remains on continuously, or turns off after a decode attempt (Low Power). CONTINUOUS ON LOW POWER 3-36...

  • Page 97: Wand Host Interface

    Parameter Menus Wand Host Interface Select the appropriate host by scanning one of the bar codes below. SYMBOLLINK CONTROLLER SYMBOL PORTABLE TERMINAL NORAND TERMINAL 3-37...

  • Page 98: Wand Host

    LS 3603 Product Reference Guide Wand Host Code Type Add or delete specific code types by scanning the appropriate bar code(s). ADD CODE 39 DELETE CODE 39 ADD UPC-A DELETE UPC-A DELETE UPC-E ADD UPC-E DELETE CODABAR ADD CODABAR 3-38...
  • Page 99 Parameter Menus Wand Host Code Type ADD EAN-8 DELETE EAN-8 DELETE EAN-13 ADD EAN-13 ADD I 2 OF 5 DELETE I 2 OF 5 DELETE D 2 OF 5 ADD D 2 OF 5 3-39...
  • Page 100 LS 3603 Product Reference Guide Wand Host Code Type DELETE CODE 128 ADD CODE 128 ADD MSI/Plessey DELETE MSI/Plessey DELETE CODE ADD CODE 93 DELETE EAN 128 ADD EAN 128 3-40...

  • Page 101: Code 2 Of 5 Lengths

    Parameter Menus Wand Host Code 2 of 5 Lengths To set the lengths for each code type: 1. Scan the desired option. 2. Scan two bar codes on page 3-42 for each desired length. For example, for a length of “12”, scan “1” then “2”. For a length of “3”, scan “0”, then “3”. You must always scan two bar codes for each length.
  • Page 102 LS 3603 Product Reference Guide Wand Host Code Lengths CANCEL 3-42...
  • Page 103 Parameter Menus Wand Host Decode Options DECODE UPC/EAN IGNORE UPC/EAN WITH SUPPLEMENTALS WITH SUPPLEMENTALS AUTODISCRIMINATE UPC/EAN WITH SUPPLEMENTALS DO NOT BEEP AFTER GOOD DECODE BEEP AFTER GOOD DECODE ENABLE 1 MSI/Plessey ENABLE 2 MSI/Plessey CHECK DIGITS CHECK DIGIT 3-43...
  • Page 104 LS 3603 Product Reference Guide Wand Host Decode Options MSI 2 CHECK DIGITS MSI 2 CHECK DIGITS MOD 10 - MOD 10 MOD 11 - MOD 10 ENABLE CODABAR DISABLE CODABAR DECODE REDUNDANCY DECODE REDUNDANCY UPC/EAN SECURITY LEVEL 0 UPC/EAN SECURITY LEVEL 1...

  • Page 105: Laser On Time-Out

    Parameter Menus Wand Host Laser On Time-out To select a laser on time-out, scan the bar code below or on the next page corresponding to the desired time. 0.5 SECONDS 1.0 SECONDS 2.0 SECONDS 1.5 SECONDS 3.0 SECONDS 2.5 SECONDS 3-45...
  • Page 106 LS 3603 Product Reference Guide Wand Host Laser On Time-out 3.5 SECONDS 4.0 SECONDS 4.5 SECONDS 5.0 SECONDS 3-46...

  • Page 107: Scanstand/Intellistand Time-Out

    Parameter Menus Wand Host Scanstand/IntelliStand Time-out To select a Scanstand/IntelliStand time-out, scan the bar code below corresponding to the desired time-out. 60 MINUTES 15 MINUTES 75 MINUTES 30 MINUTES 45 MINUTES 90 MINUTES 3-47...

  • Page 108: Power Mode

    LS 3603 Product Reference Guide Wand Host Power Mode Select whether the laser remains on continuously, or turns off after a decode attempt (Low Power). CONTINUOUS ON LOW POWER 3-48...

  • Page 109: Wand Emulator Bar Output

    Parameter Menus Wand Host Wand Emulator Bar Output Select the option that matches your host system. BAR HIGH BAR LOW 3-49...

  • Page 110: Variable Leading Margin

    LS 3603 Product Reference Guide Wand Host Variable Leading Margin Select a variable leading margin. 80 msec 110 msec 90 msec 120 msec 100 msec 130 msec 3-50...
  • Page 111 Parameter Menus Wand Host Variable Leading Margin 140 msec 170 msec 180 msec 150 msec 190 msec 200 msec 160 msec 3-51...

  • Page 112: Convert All To Code 39

    LS 3603 Product Reference Guide Wand Host Convert All to Code 39 Select whether or not to convert the decoded output to Code 39. CONVERT ALL TO CODE 39 DO NOT CONVERT ALL TO CODE 39 3-52...

  • Page 113: Synapse

    Parameter Menus Synapse Code Type Add or delete specific code types by scanning the appropriate bar code(s). ADD CODE 39 DELETE CODE 39 ADD UPC-A DELETE UPC-A ADD UPC-E DELETE UPC-E ADD CODABAR DELETE CODABAR 3-53...
  • Page 114 LS 3603 Product Reference Guide Synapse Code Type ADD EAN-8 DELETE EAN-8 DELETE EAN-13 ADD EAN-13 DELETE I 2 OF 5 ADD I 2 OF 5 DELETE D 2 OF 5 ADD D 2 OF 5 3-54...
  • Page 115 Parameter Menus Synapse Code Type ADD CODE 128 DELETE CODE 128 ADD MSI/Plessey DELETE MSI/Plessey ADD CODE 93 DELETE CODE ADD EAN 128 DELETE EAN 128 3-55...

  • Page 116: Code 2 Of 5 Lengths

    LS 3603 Product Reference Guide Synapse Code 2 of 5 Lengths To set the lengths for each code type: 1. Scan the desired option. 2. Scan two bar codes on page 3-57 for each desired length. For example, for a length of “12”, scan “1” then “2”. For a length of “3”, scan “0”, then “3”.
  • Page 117 Parameter Menus Synapse Code Lengths CANCEL 3-57...

  • Page 118: Decode Options

    LS 3603 Product Reference Guide Synapse Decode Options TRANSMIT UPC-A DO NOT CHECK DIGIT TRANSMIT UPC-A CHECK DIGIT TRANSMIT UPC-E DO NOT CHECK DIGIT TRANSMIT UPC-E CHECK DIGIT CONVERT DO NOT UPC-E TO UPC-A CONVERT UPC-E TO UPC-A 3-58...
  • Page 119 Parameter Menus Synapse Decode Options DECODE UPC/EAN IGNORE UPC/EAN WITH SUPPLEMENTALS WITH SUPPLEMENTALS AUTODISCRIMINATE UPC/EAN WITH SUPPLEMENTALS ENABLE EAN ZERO EXTEND DISABLE EAN ZERO EXTEND TRANSMIT “NO DECODE” DO NOT TRANSMIT MESSAGE “NO DECODE” MESSAGE 3-59...
  • Page 120 LS 3603 Product Reference Guide Synapse Decode Options ENABLE CLSI EDITING DISABLE CLSI EDITING ENABLE NOTIS EDITING DISABLE NOTIS EDITING ENABLE CODE 39 DISABLE CODE 39 FULL ASCII FULL ASCII VERIFTY CODE 39 DO NOT VERIFY CODE 39 CHECK DIGIT...
  • Page 121 Parameter Menus Synapse Decode Options ITF-14/EAN-13 CONVERSION ITF-14/EAN-13 CONVERSION DISABLED ENABLED DO NOT BEEP AFTER GOOD DECODE BEEP AFTER GOOD DECODE BUFFER CODE 39 DO NOT BUFFER CODE 39 3-61...
  • Page 122 LS 3603 Product Reference Guide Synapse Decode Options UPC/EAN SECURITY LEVEL 0 UPC/EAN SECURITY LEVEL 1 UPC/EAN SECURITY LEVEL 3 UPC/EAN SECURITY LEVEL 2 3-62...
  • Page 123 Parameter Menus Synapse Decode Options ENABLE 1 MSI/Plessey ENABLE 2 MSI/Plessey CHECK DIGIT CHECK DIGITS MSI 2 CHECK DIGITS MSI 2 CHECK DIGITS MOD 10 - MOD 10 MOD 11 - MOD 10 ENABLE CODABAR DISABLE CODABAR DECODE REDUNDANCY DECODE REDUNDANCY 3-63...

  • Page 124: Upc-A Preamble

    LS 3603 Product Reference Guide Synapse UPC-A Preamble Select one option for UPC-A preamble by scanning the appropriate bar code. NONE SYSTEM CHARACTER SYSTEM CHARACTER & COUNTRY CODE 3-64...

  • Page 125: Upc-E Preamble

    Parameter Menus Synaps UPC-E Preamble Select one option for UPC-E preamble by scanning the appropriate bar code. NONE SYSTEM CHARACTER SYSTEM CHARACTER & COUNTRY CODE 3-65...

  • Page 126: Data Transmission Formats

    LS 3603 Product Reference Guide Synapse Data Transmission Formats Scan the option you wish to set. DATA AS IS <PREFIX> <DATA> <DATA> <SUFFIX> <PREFIX> <DATA> <SUFFIX> 3-66...

  • Page 127: Prefix/Suffix Values

    Parameter Menus Synapse Prefix/Suffix Values To set a PREFIX/SUFFIX value: 1. Scan the option bar code you wish to set. 2. Scan four bar codes on the next page which correspond to the ASCII value or keystroke you wish to assign. The ENTER key is the default for all options.
  • Page 128 LS 3603 Product Reference Guide Synapse Prefix/Suffix Values CANCEL 3-68...

  • Page 129: Transmit Code Id Character

    Parameter Menus Synapse Transmit Code ID Character Select whether to enable or disable this parameter. TRANSMIT CODE ID CHARACTER DO NOT TRANSMIT CODE ID CHARACTER 3-69...

  • Page 130: Transmit Aim Id Character

    LS 3603 Product Reference Guide Synapse Transmit AIM ID Character Select whether to enable or disable this parameter. TRANSMIT AIM ID CHARACTER DO NOT TRANSMIT AIM ID CHARACTER 3-70...

  • Page 131: Laser On Time-Out

    Parameter Menus Synapse Laser On Time-out To select a laser on time-out, scan the bar code below or on the next page corresponding to the desired time. 0.5 SECONDS 1.0 SECONDS 2.0 SECONDS 1.5 SECONDS 3.0 SECONDS 2.5 SECONDS 3-71...
  • Page 132 LS 3603 Product Reference Guide Synapse Laser On Time-out 3.5 SECONDS 4.0 SECONDS 4.5 SECONDS 5.0 SECONDS 3-72...

  • Page 133: Scanstand/Intellistand Time-Out

    Parameter Menus Synapse Scanstand/IntelliStand Time-out To select a Scanstand/IntelliStand time-out, scan the bar code below corresponding to the desired time-out. 15 MINUTES 60 MINUTES 75 MINUTES 30 MINUTES 90 MINUTES 45 MINUTES 3-73...

  • Page 134: Power Mode

    LS 3603 Product Reference Guide Synapse Power Mode Select whether the laser remains on continuously, or turns off after a decode attempt (Low Power). CONTINUOUS ON LOW POWER 3-74...
  • Page 135 (so that the maximum possible exposure level cannot be exceeded under any condition), or are safe by virtue of their engineering design. CHECK DIGIT - A digit used to verify a correct symbol decode. The scanner inserts the decoded data into an arithmetic formula and checks that the resulting number matches the encoded check digit.
  • Page 136 CODE 93 - An industrial symbology compatible with Code 39 but offering a full character ASCII set and a higher coding density than Code 39. CONTINUOUS CODE - A bar code or symbol in which all spaces within the symbol are parts of characters. There are no intercharacter gaps in a continuous code.
  • Page 137 PROGRAMMING MODE - The state in which a scanner is configured for parameter values. See SCANNING MODE. QUIET ZONE - A clear space, containing no dark marks, which precedes the start character of a bar code symbol and follows the stop character.
  • Page 138 LS 3603 Product Reference Guide SCANNER - An electronic device used to scan bar code symbols and produce a digitized pattern that corresponds to the bars and spaces of the symbol. Its three main components are: 1. Light source (laser or photoelectric cell) - illuminates a bar code.

Table of Contents
