RS-449 Connector Pin Assignments (Continued)
TABLE A-1
80-Pin Amp. RS-449
Pin No. Signal Name
10 TxC1(B)
11 TxCI1(A)
12 TxCI1(B)
13 DCD1(A)
14 DCD1(B)
15 DSR1(A)
16 DSR1(B)
17 CTS1(A)
18 CTS1(B)
19 RxC1(A)
20 RxC1(B)
Shield Ground SG
21 RxD2(A)
22 RxD2(B)
23 DTR2(A)
24 DTR2(B)
25 TxD2(A)
26 TxD2(B)
27 RTS2(A)
28 RTS2(B)
29 TxC2(A)
30 TxC2(B)
31 TxCI2(A)
32 TxCI2(B)
33 DCD2(A)
34 DCD2(B)
35 DSR2(A)
36 DSR2(B)
37 CTS2(A)
38 CTS2(B)
24 Sun PCI High Speed Quad Port Serial Interface Adapter User's Guide • May 2010
RS-449 DB-37
Pin No. Description
35 Port 1 Transmit Clock
5 Port 1 Transmit Clock In
23 Port 1 Transmit Clock In
13 Port 1 Data Carrier Detect
31 Port 1 Data Carrier Detect
11 Port 1 Data Set Ready
29 Port 1 Data Set Ready
9 Port 1 Clear To Send
27 Port 1 Clear To Send
8 Port 1 Receive Clock
26 Port 1 Receive Clock
1 Port 1 Shield Ground and Signal Ground
6 Port 2 Receive Data
24 Port 2 Receive Data
12 Port 2 Data Terminal Ready
30 Port 2 Data Terminal Ready
4 Port 2 Transmit Data
22 Port 2 Transmit Data
7 Port 2 Request To Send
25 Port 2 Request To Send
17 Port 2 Transmit Clock
35 Port 2 Transmit Clock
5 Port 2 Transmit Clock In
23 Port 2 Transmit Clock In
13 Port 2 Data Carrier Detect
31 Port 2 Data Carrier Detect
11 Port 2 Data Set Ready
29 Port 2 Data Set Ready
9 Port 2 Clear To Send
27 Port 2 Clear To Send
