To Configure For Point-To-Point Protocol - Sun Microsystems Sun PCI High Speed User Manual

▼ To Configure for Point-to-Point Protocol

1. Change to the /etc/ppp directory and create an executable file called
conf_hsip, containing the following information:
#!/bin/ksh -x
DEVICE='echo $DEVICE | sed 's/?dev?//''
/opt/SUNWconn/bin/hsip_init $DEVICE speed=2048000 mode=fdx loopback=no \
nrzi=no txc=baud rxc=rxc txd=txd rxd=rxd signal=no 2>&1 > /dev/null
2. Create another executable file called demand, containing the following
information:
if [ -f /var/run/ppp-demand.pid ] &&
/usr/bin/kill -s 0 '/bin/cat /var/run/ppp-demand.pid'
then
:
else
env DEVICE=hihp0 /usr/bin/pppd hihp0 :qa1b-hihp0 call far-hsip
env DEVICE=hihp1 /usr/bin/pppd hihp1 :qa1b-hihp1 call far-hsip
env DEVICE=hihp2 /usr/bin/pppd hihp2 :qa1b-hihp2 call far-hsip
env DEVICE=hihp3 /usr/bin/pppd hihp3 :qa1b-hihp3 call far-hsip
fi
3. Change to the /etc/ppp/peers directory and create an executable file called
far-hsip, containing the following information:
connect '/etc/ppp/conf-hsip'
local
sync
noauth
0:
ipcp-accept-local
nodefaultroute
passive
persist
noccp
nopcomp
novj
noaccomp
4. Add the client site hosts on the server machine and add the server site hosts on
the client machine.
a. Edit the server's /etc/hosts file and add the client site local hosts.
Chapter 3 SunHSI PCI Software Installation 15
