Hardware Guide - StarTech.com PCISOUND4LP User Manual

Hardware Guide

1
2
3
4
1. Line In (blue)
2. Mic In (pink)
3. Front-Speaker (green)
phones or Audio-in of home stereo
4. Rear-Speaker (black)
channel speakers mode is enabled
In addition to the rear panel jacks, this 4 Channel Sound Card also has
the following internal connections:
5. Aux-in
6. Analog CD/IN Port
7. Analog CD/IN Port
Instruction Manual
– Line-In Connect to the audio output port of stereo
– Connect to the Microphone (Mono)
– Output to speakers with the amplifier or ear
– Connect to the rear speakers while four
(Signals: L-G-G-R)
(Signals: G-R-G-L)
5
2
6
7
