5.1 Channel PCI Surround Sound Card - 16 bit
PCISOUND5CH2
*actual product may vary from photos
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 03/13/2014
Advertisement
Table of Contents
Related Manuals for StarTech.com PCISOUND5CH2
Summary of Contents for StarTech.com PCISOUND5CH2
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 03/13/2014...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Product Overview ..................2 Internal Headers ............................3 Internal Jumpers ............................3 Installation ....................3 Hardware Installation ..........................4 Driver and Software Installation ......................5 Verifying Installation ..........................6 Specifications ..................7 Technical Support ..................8 Warranty Information ................8... -
Page 4: Introduction
Introduction Packaging Contents • 1x PCI 5.1 Surround Sound Card • 1x Low Profile Bracket • 1x Driver CD • 1x Instruction Manual System Requirements • Available 5V PCI Slot • Microsoft DirectX® 8.1 or later • Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64), Windows Server® 2012, 2008 R2, 2003 (32/64), Linux 2.6.x and up (Tested up to 3.5) Instruction Manual... -
Page 5: Product Overview
Product Overview JP1 & JP2 1. Line In: Connect to Tape/CD/DVD player, or other audio sources for output mixing and/or recording 2. Mic In: Connect to microphone 3. Front-Speaker: Output to speakers with amplifier or earphones or audio-in of home stereo 4. -
Page 6: Internal Headers
Internal Headers Note: The header pinout is Pin 1 to Pin 4 from left to right for all headers (6, 7, 8). 7. J2 - Analog CD/IN: Signals: G-R-G-L 6. J1 - Analog CD/IN: Signals: L-G-G-R Pin # Description Pin # Description Left channel signal Right channel ground... -
Page 7: Hardware Installation
WARNING! PCI cards, like all computer equipment, can be severely damaged by static electricity. Be sure that you are properly grounded before opening your computer case or touching your PCI card. StarTech.com recommends that you wear an anti-static strap when installing any computer component. If an anti-static strap is unavailable, discharge yourself of any static electricity build-up by touching a large grounded metal surface (such as the computer case) for several seconds. -
Page 8: Driver And Software Installation
Driver and Software Installation Windows Upon starting Windows, if the Found New Hardware wizard appears on the screen, cancel/ close the window and insert the included Driver CD into your CD/DVD drive. If Autoplay is enabled, select the “Open folder to view files” option when the dialog appears. -
Page 9: Verifying Installation
Verifying Installation Windows 1. Open the Device Manager by right-clicking on Computer, and then select Manage. In the new Computer Management window, select Device Manager from the left window panel (For Windows 8, open the Control Panel and select Device Manager). 2. -
Page 10: Specifications
Specifications Warranty 2 Years Bus Type PCI v2.2 (5V) Standard profile installed, low-profile Card Type included Chipset ID C-Media 8738LX Internal Ports 3 x MPC2 (4 pin; Audio) Male External Ports 5 x 3.5 mm Mini-Jack (3 Position) Female Audio Specifications Supports 5.1 Channel 16 bit stereo audio Full Duplex Support Dimensions... -
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 12 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
