StarTech.com ICUSBAUDIO7 Instruction Manual

Instruction Manual
Virtual 7.1 USB External Sound Card
ICUSBAUDIO7
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com

Packaging Contents

• 1 x USB Audio Adapter
• 1 x Software CD
• 1 x Instruction Manual

System Requirements

• USB 2.0 enabled computer system
• Windows 2000/ XP(32/64bit)/ Vista(32/64bit)/ 7(32/64bit)/
Server 2008 R2, Linux, Mac OS X
• Windows XP/Vista for Xear 3D virtual 7.1 channel sound
software
• Stereo speaker or earphone
• Mono Microphone (optional)
For the most up-to-date information, please visit: www.startech.com
*actual product may vary from photos
Installation
Connect the USB Audio adapter to the USB port on
1.
your computer
Your operating system should automatically detect
2.
this new device and install the USB audio driver.
Connect the speaker/earphone and microphone to
3.
the sound adapter.
If your operating system is Windows XP or Vista,
4.
install the Xear 3D software from the provided
software CD. Run the setup.exe file and follow the
prompts.
Verifying Installation in Windows
2000/XP/Vista
Open Device Manager by right-clicking on My
Computer and selecting Manage, then select Device
Manager from the left window pane.
*screenshots are for reference only
Manual Revision: 01/30/2012
