Peripherals Connection - Source Technologies STm.117b User Manual

The sample of self test printout
When the printer is installed initially or when you face a problem, you can run the
self test and check the information about
-Control Circuit, Mechanism, Print Quality, ROM Version
After checking with self-test and no issues are found, you can examine other
devices and software. This function is working independent of devices and software.
Motor protection from being overheated
●
The motor should be stopped and cooled about more than 30 seconds after
continuous printing 1.5 meter
12

4. Peripherals connection

This printer can communicate with Peripherals device via Bluetooth
and cables.
4-1 Bluetooth Connection
1. Printer can be connected to the PDA and PC which can do wireless
communication.
2. By using Bluetooth function supported in PC, printer can be connected.
NOTE
Refer to the Bluetooth Manual for more details on connection.
13
