- Page 1 MF1436-02 CMOS 4 - BIT SINGLE CHIP MICROCOMPUTER S5U1C63000H2 Manual (S1C63 Family In-Circuit Emulator)
- Page 2 No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any...
- Page 3 New configuration of product number Starting April 1, 2001, the product number has been changed as listed below. Please use the new product number when you place an order. For further information, please contact Epson sales representative. Devices 63158 Development tools...
-
Page 5: Table Of Contents
6.2 Differences from Actual IC ... 19 CHAPTER AINTENANCE AND 7.1 Diagnosis Test ... 20 7.2 Warranty ... 20 S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) ONTENTS ____________________________________________ 1 __________________________________ 2 ACKAGE _________________________________________ 9 S5U1C63000H2 __________________ 11 UNCTION OF __________________________________________ 19 ________________________________ 20 ARRANTY EPSON CONTENTS... - Page 6 9.2.1 Notes on operations ... 23 9.2.2 Difference from an actual IC ... 23 9.3 Connection with Target System ... 24 9.4 Product Specifications ... 26 ________________________________________ 21 LCD B ______________________________ 22 OARD EPSON S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR)
-
Page 7: Chapter 1 Introduction
S5U1C63000H2 system. Refer to "S5U1C63000A Manual" for use of the debugging commands. Figure 1.1 shows the external view of the S5U1C63000H2. 6 3 0 0 0 H S 5 U 1 C Fig. 1.1 External view of S5U1C63000H2 EPSON S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) -
Page 8: S5U1C63000H2 Package
(17) S5U1C63000A Manual (included in the S1C63 Family Assembler package) ACKAGE •S5U1C63000H2 •User registration card Manual •Warranty card •Precautions on using the S5U1C63000H2 EPSON EPSON S5U1C63000H2 Manual S5U1C63000H2 Manual English Japanese •S5U1C63000H2 main unit 1 2 3 4 5 6 7 8 S5U1C63000H2 •AC adapter... -
Page 9: Component Specifications
5 to 40 C -10 to 60 C 35 to 80% 20 to 90% Operating: 0.25 m/S Transportation: 1 m/S EPSON CHAPTER 2: S5U1C63000H2 PACKAGE Remarks Rubber feet included or equivalent Outside: 5 V, Inside: 0 V Remarks No condensation... -
Page 10: Specifications Of Operation Panels
2.4 Specifications of Operation Panels This section explains the operation of each switch. Figure 2.4.1 shows the external view of the panels. 1 2 3 4 5 6 7 8 RS232C S5U1C63000H2 EPSON (Front view) POWER DC 5V (Rear view) - Page 11 Tightening the connector with screws is recommended while using. DC input connector This is a connector to connect the DC cable of the AC adapter dedicated for S5U1C63000H2. Power switch Turns the S5U1C63000H2 power on and off. EPSON CHAPTER 2: S5U1C63000H2 PACKAGE Function...
-
Page 12: Setting The Dip Switch
2400 bps, 8-bit character, 1 stop bit, no parity 4800 bps, 8-bit character, 1 stop bit, no parity 19200 bps, 8-bit character, 1 stop bit, no parity 38400 bps, 8-bit character, 1 stop bit, no parity Do not set. Setting EPSON S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) -
Page 13: Chapter 3 Connection
Signal meaning Transmit data from HOST to ICE Receive data from ICE to HOST Request to send from HOST Clear to send from ICE Signal ground EPSON CHAPTER 3: CONNECTION AC line Remarks Normally used as ON Normally used as ON... -
Page 14: Installing Peripheral Circuit Board (S5U1C63Xxxp)
6 3 0 0 0 H S 5 U 1 C Peripheral circuit board (2), (3) Peripheral circuit board Fig. 3.4.2 Installing the peripheral circuit board Peripheral circuit board Fig. 3.4.3 Dismounting the peripheral circuit board EPSON (S1C63 FAMILY IN-CIRCUIT EMULATOR) S5U1C63000H2 MANUAL... -
Page 15: Chapter 4 Getting Started
When the SLP or HALT instruction is ex- ecuted, the SLP/HLT LED (yellow) goes on and the PC LEDs (red) stop. S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) CHAPTER 4: GETTING STARTED TARTED EPSON... - Page 16 RAM area, it stops after the access to the incorrect area. (4) The S5U1C63000H2 may takes approx. 5 minuets after it is turned on until it starts execution of the target program. EPSON (S1C63 FAMILY IN-CIRCUIT EMULATOR) S5U1C63000H2 MANUAL...
-
Page 17: Chapter 5 Operation And Function Of S5U1C63000H2
S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) CHAPTER 5: OPERATION AND FUNCTION OF S5U1C63000H2 UNCTION OF Emulation control portion Emulation program memory Emulation data memory Trace control portion Break control portion Target monitor portion Flash memory EPSON S1C63000 To peripheral circuit board... -
Page 18: Break Function
A low level is output when the S1C63000 CPU is suspended (by execution of the HALT or SLP instructions). This terminal also outputs low level during break. STOPOUT output Fig. 5.3.1 TRGOUT terminal output Indicating suspension of CPU operation Running Fig. 5.3.2 STOPOUT terminal output EPSON Coincidence with trace trigger Breaking S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) -
Page 19: Display During Execution And During Break
The above break functions, (1), (2), (3), (4), can be independently specified. When the target program is executed with all specified commands, BP, BS, BD, BR, breaks occur by meeting any condition. S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) CHAPTER 5: OPERATION AND FUNCTION OF S5U1C63000H2 (address 2 coincidence) (address 3 counted by specified EPSON... -
Page 20: Target Interrupt And Break
Trace memory Effective trace Effective trace Fig. 5.7.1 Trace function Trace information at any point can be displayed by the TD command. EPSON (S1C63 FAMILY IN-CIRCUIT EMULATOR) (TP = 8,191) Instruction just before break Earliest instruction (TP = 0) S5U1C63000H2 MANUAL... -
Page 21: Trace Mode
(2) Bus cycle count mode (a) Range of cycle measurement 1 bus cycle to (2 -1) bus cycles (= 2 10 (b) Measurement error 0 cycle S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) CHAPTER 5: OPERATION AND FUNCTION OF S5U1C63000H2 36 minutes) bus cycles) EPSON... -
Page 22: Self Diagnosis Function
Therefore, in the single step operation, a real time counting cannot be done with the timers in the S1C63xxx. Execution of emulation (running target program) Fig. 5.13.1 Operation of S1C63000 CPU EPSON Execution of monitor program (standby mode) S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) - Page 23 For instance, when the break at read cycle is set by the break data set command (BD), the dummy read hits the break condition. S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) CHAPTER 5: OPERATION AND FUNCTION OF S5U1C63000H2 EPSON...
- Page 24 IACK is at low level, and the break is occurred after jumping to the interrupt vector address. ld %a, 5 ld %a, 6 ICE monitor command ICE monitor command ld %a, 5 ld %a, 6 EPSON (S1C63 FAMILY IN-CIRCUIT EMULATOR) , the because the S5U1C63000H2 MANUAL...
-
Page 25: Chapter 6 Notes On Using
I/O terminal. Therefore, the value read on the target program may differ from the value read by the dump command. S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) CHAPTER 6: NOTES ON USING SING and V are short-circuited on EPSON... -
Page 26: Chapter 7 Maintenance And Warranty
The self diagnosis test is executed by setting SW8 of the DIP switch to OPEN and starting the debugger after power of the S5U1C63000H2 on. Debugger for S1C63 Ver x.xx Copyright(C) SEIKO EPSON CORP. xxxx Connecting with ICE ... DIAG test, please wait 5 min. -
Page 27: Chapter 8 Trouble Shooting
S5U1C63000H2 power is turned on. - Is target cable connected correctly ? - Is V or V short-circuited on a target ? Refer to "S5U1C63000A Manual" for operations of the debugger. S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) CHAPTER 8: TROUBLE SHOOTING HOOTING EPSON... -
Page 28: Pecifications Of Lcd Board
(S5U1C63xxxP). This board may be set for each model by loading mask option data (generated by the function option generator) using the ICE command. 9.1.2 External view of LCD board Fig. 9.1.2.1 External view of LCD board EPSON S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) -
Page 29: Precautions On Using
(5) LCD drive voltage The LCD drive voltage in this board may differ from that of the actual IC. S5U1C63000H2 MANUAL (S1C63 FAMILY IN-CIRCUIT EMULATOR) CHAPTER 9: SPECIFICATIONS OF LCD BOARD (= +5 V) (= +5 V) EPSON... -
Page 30: Connection With Target System
Use the connection cables (100-pin/50-pin between the LCD board and target systems. 2 flat type, 34-pin flat type) supplied for the connection mark (34-pin) To target board Fig. 9.3.1 Connection with target system EPSON I/O connection cable CN4-1 (50-pin) CN4-2 To target board (50-pin) - Page 31 Cannot be connected Cannot be connected Cannot be connected Cannot be connected Cannot be connected Cannot be connected Cannot be connected Cannot be connected Cannot be connected EPSON CN-5 connector (34-pin 2 flat type) CN5 connector Name Function COM0 COM0 COM1...
-
Page 32: Product Specifications
Weight: Approx. 220 g Power supply: DC 5 V 5%, less than 1 A (supplied from S5U1C63000H2 main unit) LCD cable Onboard connector: KEL8830E-100-170L 3M3431-5002LCSC 144.8 mm (depth) 13 mm (height) EPSON (S1C63 FAMILY IN-CIRCUIT EMULATOR) (including screws) S5U1C63000H2 MANUAL... - Page 33 EPSON HONG KONG LTD. 20/F., Harbour Centre, 25 Harbour Road Wanchai, Hong Kong Phone: +852-2585-4600 Fax: +852-2827-4346 Telex: 65542 EPSCO HX EPSON TAIWAN TECHNOLOGY & TRADING LTD. 10F, No. 287, Nanking East Road, Sec. 3 Taipei Phone: 02-2717-7360 Fax: 02-2712-9164 Telex: 24444 EPSONTB HSINCHU OFFICE 13F-3, No.
- Page 34 In pursuit of “Saving” Technology, Epson electronic devices. Our lineup of semiconductors, liquid crystal displays and quartz devices assists in creating the products of our customers’ dreams. Epson IS energy savings.
- Page 35 S5U1C63000H2 Manual (S1C63 Family In-Circuit Emulator) ELECTRONIC DEVICES MARKETING DIVISION EPSON Electronic Devices Website http://www.epsondevice.com First issue June, 2001 Printed February, 2002 in Japan...
