Removing an accessible drive

► Open the casing (see "Opening the casing").
1
1
► Pull the data and the power supply connectors from the desired drive.
► Loosen the screws (1).
► Slide the drive out of the bay in the direction of the arrow (2) from behind.
The drive now protrudes slightly out of the casing.
► Slide the drive out of the casing (3).
► If necessary, make the required settings on the remaining hard disk drives.
A26361-K990-Z120-1-7619, Edition 6
System upgrades
2
3
61
