OPERATING INSTRUCTIONS
FP-1600
FieldPoint 10/100 Ethernet
Network Module
These operating instructions describe the installation, features, and
characteristics of the FP-1600. For more detailed information on
using the network module, refer to the FP-1600 user manual.
Features
The FP-1600 is a FieldPoint network module with the following
features:
•
Autonegotiating 10/100 Ethernet network interface
•
Built-in high efficiency power supply powers I/O modules
•
Network watchdog timer
•
SnapShot capability and programmable power-up state
•
–40 to +55 °C operation
•
Connects to an Ethernet network using the TCP/IP protocol
•
Supports up to nine I/O modules
•
Runs on 11 to 30 VDC power
Kit Contents and Optional Equipment
Your kit contains the following items:
•
FP-1600 network module
•
Accessories: protective connector cover, two DIN rail stops,
Device Description diskette
You can order the following optional equipment from National
Instruments:
•
Panel mount accessory, part number 777609-01
FieldPoint™ and natinst.com™ are trademarks of National Instruments Corporation. Product and
company names mentioned herein are trademarks or trade names of their respective companies.
322395A-01
© Copyright 1999 National Instruments Corp. All rights reserved.
July 1999

Advertisement

loading
Need help?

Need help?

Do you have a question about the FIELDPOINT FP-1600 and is the answer not in the manual?

Questions and answers

Related Manuals for National Instruments FIELDPOINT FP-1600

Summary of Contents for National Instruments FIELDPOINT FP-1600

  • Page 1 Instruments: • Panel mount accessory, part number 777609-01 FieldPoint™ and natinst.com™ are trademarks of National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of their respective companies. 322395A-01 © Copyright 1999 National Instruments Corp. All rights reserved.

  • Page 2: Installation

    • Terminal bases and I/O modules, complete list of terminal bases and I/O modules in the National Instruments online catalog at www.natinst.com • Cables • 24 VDC power supply Installation Caution To avoid damaging the FP-1600 and the terminal bases, make sure that power is not applied to the FP-1600 while you install or remove terminal bases.
  • Page 3 Lock the FP-1600 to the DIN rail by pushing the rail clip to the locked position. • Installing onto a panel mount accessory, which you can order separately from National Instruments: a. Snap the panel mount accessory onto the module, as shown in Figure 3. Press Figure 3.

  • Page 4: Network Connection

    b. Lock the panel mount accessory into place by pushing the rail clip to the locked position. c. Mount the FP-1600 and panel mount accessory onto the desired surface. You can drill pilot holes using the directions in the FieldPoint Network Module Panel Mount Accessory installation guide.
  • Page 5 Table 1. Ethernet Cable Wiring Connections Connector 2 Connector 2 Connector 1 (Normal) (Crossover) white/orange white/orange white/green orange/white orange/white green/white white/green white/green white/orange blue/white blue/white blue/white white/blue white/blue white/blue green/white green/white orange/white white/brown white/brown white/brown brown/white brown/white brown/white © National Instruments Corp. FP-1600...
  • Page 6 Figure 6 shows the connector pinouts for FieldPoint Ethernet cables. Connector 1 Connector 2 pin 1 pin 8 pin 1 pin 8 Figure 6. Ethernet Cable Powering the FP-1600 Connect the FP-1600 to the terminal base before Caution applying power to the FP-1600 to avoid damaging the FP-1600 or a terminal base.

  • Page 7: Specifications

    Maximum terminal bases per bank... 9 Maximum number of banks....determined by network topology Operating temperature ...... –40 to +55 °C Storage temperature ......–55 to +85 °C Relative humidity......5% to 90% non-condensing Weight..........250 g (8.7 oz.) © National Instruments Corp. FP-1600...
  • Page 8 Compliance Electrical safety ........ designed to meet IEC 1010 EMI emissions/immunity....CISPR 11 CE Mark Compliance This product meets applicable EU directive(s) as follows: EMC directive Immunity ........EN 50082–1:1994 Emissions ........EN 55011:1991 Group I Class A at 10 meters Mechanical Dimensions Figure 8 shows the mechanical dimensions of the FP-1600.
