Electrical Specifications
AC Power Input
Voltage
Connector
Chassis grounding
Power supply
DC Port Power Output
Power enabling
Power pins
Maximum power/port
Maximum power, all ports active
Module-to-module isolation
Overload protection
90–264 V autoranging (46 Hz–63 Hz)
3-pin with ground
yes
single
IEEE 802.3af
Unused pairs, pins 4,5(+), 7,8(-)
15.6 W
24 ports at 15.6 W each
1500 Vrms
If current reaches 400–450 mA for 300–400
milliseconds, then the port shuts down.
Mid-Span Power Hub 24-Port User's Guide A-3
Model BL-69524ENT
