Model BL-69524ENT

Physical/Mechanical Specifications

Table A-1
Power Hub.
Table A-1 Physical and Mechanical Specifications
Item
Chassis Type
Chassis Size
Module Type
Weight

LED Indicators/Module

Table A-2
Table A-2 LED States and Their Definitions
LED Color
Blue
Green

Physical/Environmental Specifications

Table A-2
24-port Mid-Span Power Hub.
Table A-3 Physical and Environmental Specifications
Item
Operating Temperature
Storage Temperature
Relative Humidity
Operating Altitude
A-2
provides physical and mechanical specifications for the 24-port Mid-Span
provides module LED states and their definitions.
provides physical and environmental specifications for the BL-69524ENT
Specification
48.26 cm (19.0 in.) rackmount with 3 modules
44.45 cm W x 41.28 cm D x 4.45 cm H
(17.5 in. W x 16.25 in. D x 1.75 in. H)
Removable, hot swappable
9.0 kg (20.0 lbs)
Status
Detect/Power Forwarding
Power from Chassis
Specification
0° C to 40° C (32° to 105° F)
-10° C to 60° C (14° F to 140° F)
10% to 90% non-condensing
-1,000 to 10,000 feet
