Hardware Features

WX2200 Switch

O
WITCH VERVIEW
Table 3 WX Switch Model Numbers (continued)
Model Port Configuration
WX4400 Four dual-interface gigabit Ethernet
ports. Each port has a 1000BASE-TX
copper interface and a Gigabit
interface converter (GBIC) slot for
insertion of a 1000BASE-SX or
1000BASE-LX fiber-optic interface.
The following sections describe the WX hardware features.
A WX2200 switch is one RU high and also can be installed in a standard
48.26-cm (19-inch) equipment rack or on a tabletop. Figure 1 shows the
features of a WX2200 switch.
Figure 1 3Com WX2200 Switch
Power
supplies
Provide an Earthing Connection
90 - 240V~ / 50 - 60 Hz
2.0 / 1.0A
Power
supply LEDs
The rear of the switch contains a label with the serial ID, MAC address,
and other identifying information.
Serial
console port
Mgmt (3)
Console
Mgmt 10/100 Mini-GBIC
LED Management slots
Port
Power Supply Configuration
Two 100-120 VAC / 200-240 VAC
autosensing AC power supplies
1 2
Gigabit link
LEDs
