MAP LED Appearance
Solid green
Alternating green and
amber
Solid amber
Blinking amber
Unlit
3 If the cable is attached to a wired end station that uses AAA through the
WX switch to access the network:
For a first-time installation, set the port type to activate the link. (For
information, see "Setting a Port for a Wired Authentication User" in
the Wireless LAN Switch and Controller Configuration
If the port type is already set for a wired authentication port, go on to
step 4.
4 If the cable is directly attached to a device other than a MAP access point:
a Observe the appearance of the Link LED for the port:
Link LED Appearance
Solid green
Solid amber
Blinking green
Blinking amber
Unlit
b If the Link LED is unlit, check the cable and verify that the device at the
other end of the link is operating.
Connecting to the Network
Meaning
For a MAP access point's active link, with PoE enabled,
all the following are true:
MAP access point has booted.
MAP access point has received a valid
configuration from the WX switch.
Management link with a MAP access point is
operational.
For a MAP access point's secondary link, the link is
present.
MAP access point is booting with an image received
from the WX switch.
PoE is on, but no MAP access point is connected to
the link.
MAP access point is unresponsive or there is a PoE
problem.
PoE is off.
Meaning
100-Mbps link is operational.
10-Mbps link is operational.
Traffic is active on the 100-Mbps link.
Traffic is active on the 10-Mbps link.
Link is not operational.
41
Guide.)
