18 C 1: WX S
HAPTER
O
WITCH VERVIEW
Table 5 WXR100 Status LEDs
LED
Power status
Link
(ports 1 and 2)
Fn
(port 1 only)
MAP (port 2 only)
Appearance
Solid green
Unlit
Solid green
Solid amber
Blinking green
Blinking amber
Solid green
Blinking green
Unlit
Solid green
Alternating green and
amber
Solid amber
Blinking amber
Unlit
Meaning
The switch is receiving power.
The switch is not receiving power.
100-Mbps link is operational.
10-Mbps link is operational.
Traffic is active on the 100-Mbps link.
Traffic is active on the 10-Mbps link.
The switch is booting and is loading its
configuration file. This LED state lasts
for three seconds.
The switch is booting but the Fn
switch is being pressed. The switch
does not load its configuration file but
instead contacts WX to request a
configuration.
This LED state lasts for three seconds.
The switch has finished booting.
For a MAP access point's active link,
with PoE enabled, all the following are
true:
MAP access point has booted.
MAP access point has received a valid
configuration from the WX switch.
Management link with an MAP access
point is operational.
MAP access point is booting with an
image received from the WX switch.
If the LED remains in this state
indefinitely, the boot or configuration
attempt has failed.
PoE is on but no MAP access point is
connected to the link.
MAP is not connected or is
unresponsive, or there is a PoE
problem.
Port is not configured as a MAP access
port, or PoE is off.
