BPA-1 Technical Specification
Rated Power Output:
Total Harmonic Distortion (THD):
Signal-to-Noise Ratio:
Maximum Noise+Hum:
Crossover Freq. Response (-3dB):
Auto Turn On Sensitivity:
Delay Turn Off Time:
Input Sensitivity Line In:
Input Impedance Line In:
Line Out Freq. Response (-3dB):
Maximum noise+hum (Vol Max):
Clearance for ventilation (Back):
Electrical Power Requirement:
Raw Weight:
Shipping Weight:
Dimensions:
Page 14
75 Watts (Stereo) into 4
150 Watts (Bridged) into 8
<0.1% 20Hz-20kHz with 80kHz measurement bandwidth
>100dB, Unweighted (Full Output Reference)
<200µV (Volume @ Max)
@ Min position 50Hz, 18dB/octave
@ Max position 150Hz, 18dB/octave
3mv
15 - 20 minutes
36dB
(27dB@1 o'clock position)
(29dB@2 o'clock position)
(-3dB) 20Hz +/-5Hz - 20 KHz +/-50Hz 1KHz/0dB ref
<1.0mV, Input Shorted
Minimum 2" / 50 mm
115V 60Hz (Can be modified to 230V@50Hz - Contact Emotiva)
7.8lbs / 3.6 kg
8.6lbs / 3.9 kg
6.0" W x 5.5" H (including feet) x 11.4375" D
152mm W x 140mm H x 290mm D
