Summary of Contents for Emotiva Stealth PA-1
- Page 3 WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THE STEALTH PA-1 AMPLIFIER NEAR WATER OR IN WET LOCATIONS, DO NOT EXPOSE IT TO RAIN OR MOISTURE, DO NOT EXPOSE IT TO DRIPPING OR SPLASHING FROM OTHER SOURCES, AND ENSURE THAT NO OBJECTS FILLED WITH LIQUIDS (SUCH AS VASES) ARE PLACED ON IT.
- Page 4 The Stealth PA-1 should only be cleaned as directed in the manual. Avoid spraying liquids directly onto the unit and NEVER spray liquids into the vents. Care should be taken so that small objects do not fall into the inside of the unit.
-
Page 5: Table Of Contents
Stealth PA-1 Stealth PA-1 Balanced Class-D Monoblock Power Amplifier Contents Important Safety Precautions and Explanation of Symbols Stealth PA-1 Balanced Class-D Monoblock Power Amplifier ......1 Introduction ........................3 Features ..........................5 Unpacking ..........................6 Connections ........................7 Stealth PA-1 Front Panel ....................9 Stealth PA-1 Rear Panel ....................10 Care and Maintenance .................... - Page 6 Stealth PA-1 Page 2...
-
Page 7: Introduction
PA-1, or a pair of them side by side, in a single 1U rack space. Not only does the Stealth PA-1 sound great, but it’s also simple to configure and use. The PA-1 runs on any line voltage between 100 VAC and 264 VAC, accepts a balanced input using either an XLR or balanced 1/4”... - Page 8 Stealth PA-1 Page 4...
-
Page 9: Features
The status is updated every few seconds and, as soon as the fault is removed, the PA-1 will automatically return to normal operation. • Rated for low impedance loads - The Stealth PA-1 is rated to drive loads from 2.7 Ohms to 8 Ohms, and so will work well with virtually all loudspeakers and passive subwoofers. •... -
Page 10: Unpacking
Stealth PA-1 Unpacking Your Stealth PA-1 Class-D Monoblock Power Amplifier was carefully packed and should reach you in perfect condition. If you notice any shipping damage or other issues when you unpack it, please contact Emotiva immediately. Gently remove your PA-1 from the packing carton and remove all wrappings and shipping material. -
Page 11: Connections
This DC potential is carefully controlled and balanced by the servo-control circuitry in the PA-1, and is NOT applied across your loudspeakers. - Always make speaker and input connections to the Stealth PA-1 with the amplifier turned Off. - ONLY connect the speaker outputs on the PA-1 to the teminals on a PASSIVE loudspeaker. - Page 12 Stealth PA-1 Page 8...
-
Page 13: Stealth Pa-1 Front Panel
Stealth PA-1 Stealth PA-1 Front Panel PA - 1 STEAL TH 1. Power LED There is a single LED located in the center of the front panel. This LED is off when the PA-1 is Off or in Standby Mode and blue when the PA-1 is On. -
Page 14: Stealth Pa-1 Rear Panel
1. AC Power Switch Switches the main AC power to the Stealth PA-1 On and Off. When this switch is Off, the PA-1 will not operate; when this switch is On, the PA-1 will either be continuously on, or will turn on when it senses an input signal, depending on the position of the Auto/On Switch. -
Page 15: Balanced Input
5. Auto/On Switch When the Auto/On Switch is on the On position, operation of the Stealth PA-1 will be controlled solely by the AC Power Switch. The PA-1 will turn on immediately when the AC Power Switch is turned On, and will turn off immediately when the AC Power Switch is turned Off. -
Page 16: Care And Maintenance
Your Stealth PA-1 requires no periodic maintenance or calibration. Cleaning your Stealth PA-1 • If necessary, the Stealth PA-1 should be cleaned gently with a soft rag. • If something sticky gets on the front panel or case of the PA-1, it should be cleaned with a mild cleaning solution applied to a soft rag, followed by wiping with a clean rag dampened with plain water, and drying with a soft dry rag or cloth. -
Page 17: Specifications
Specifications Circuit Topology The Emotiva Stealth PA-1 Class-D Monoblock Power Amplifier is a fully balanced high- performance Class D power amplifier featuring the ICEpower ASC300 amplifier module. The ICEpower ASC300 is self-contained, and includes an audiophile-grade Class D power amplifier, and an integral high-performance switch mode power supply. -
Page 18: Audio Specifications
13-5/8” long x 13” wide x 6-1/2” high (boxed) Weight: 3 lbs. (unboxed) 6 lbs (boxed) Ventilation The Emotiva Stealth PA-1 requires very little ventilation and generally runs quite cool. However, the small vents on the top and bottom of the unit should remain unblocked. Page 14... -
Page 19: Emotiva Audio Corporation Five-Year Limited Warranty
The current owner must make a claim within the Term of the Warranty. A claim shall not be valid (and Emotiva has no obligation related to the claim) if it is not made within the Term and if it is not made in strict compliance with the requirements of the “How do you get service?”... - Page 20 (v) to consumable parts, such as batteries or failure of or damage to the Product caused by batteries; (vi) if any Emotiva serial number has been removed or defaced on the product; (vii) glass or plastic panels, cabinetry, trim or other appearance items; (viii) cosmetic wear or damage to remote controls by user.
- Page 21 What if my product is damaged on the way to you? Emotiva is not liable for damages that may incur while an item is in transport to us. Please purchase insurance when you ship your item. If your Product was not adequately packaged, we will refuse receipt and the damaged package will be returned to you at your cost.
-
Page 23: Notes
Notes All information contained in this manual is accurate to the best of our knowledge at the time of publication. In keeping with our policy of ongoing product improvement, we reserve the right to make changes to the design and features of our products without prior notice. User Manual v1.0 June 2018...
