Print servers connect printers to networks. This lets many users access printers from their
own workstations, a very cost effective way to share powerful and expensive printers. It is not
necessary to buy an extra personal computer to attach each printer to the network. You use
the print server instead.
Environments we support
Print servers support an extraordinarily wide range of network environments.
Any single print server on any given physical network can accept and process print jobs from
any or all of these logical networks concurrently. For example, if a MarkNet XI physically
attaches a printer to an Ethernet network, then a NetWare client and an AppleTalk user can
send print jobs to the printer simultaneously. The print jobs are processed on a first-come,
first-served basis.

Connect the hardware

Instructions on connecting the Ethernet cable to your Lexmark E320n Printer can be found in
the printer Setup Book. To view the Setup Book from this CD, click the Home icon
Resources
PDFs for Printing
www.lexmark.com
Lexmark E320/E322 Printer
Setting up the network printer
Setup Guide.
1
Other

Advertisement

Table of Contents
loading

Related Manuals for Lexmark E322 - Printer - B/W

Summary of Contents for Lexmark E322 - Printer - B/W

  • Page 1: Connect The Hardware

    Administration Connect the hardware Index Instructions on connecting the Ethernet cable to your Lexmark E320n Printer can be found in the printer Setup Book. To view the Setup Book from this CD, click the Home icon Other Resources PDFs for Printing Setup Guide.

  • Page 2: Print A Network Setup Page

    IP address, netmask and gateway appear as non-zero. • If you don’t have DHCP, there are other methods you can use to manually assign the address, such as static ARP and telnet, or a setup utility. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 3 The Print Server TCP/IP Setup Utility is a simple way to set the IP address and other Index important IP parameters in a print server. You can set up one or many print servers using this method with no need to physically visit the printers. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 4 ARP table on some computer that is on the same IP subnet as the print server. (Source Route bridging is not supported.) Then, you use telnet. To set the IP address, netmask, and gateway using static ARP entry and telnet: www.lexmark.com Lexmark E320/E322 Printer...

  • Page 5: Troubleshooting

    Follow the instructions on the screen to set the print server IP address, netmask and Index gateway. Troubleshooting If you are having trouble with a print server on a TCP/IP network, do the following steps in the order shown before you call the Customer Support Center. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 6 Using the FTP “put” command, print a file. This file can be PCL or PostScript emulations, PDF, HTML, or any other printer language the printer understands. If the Index file prints, this confirms the TCP/IP protocol is working properly in the print server. put mytest.ps or put mytest.txt www.lexmark.com Lexmark E320/E322 Printer...
  • Page 7 Try printing from some other application. If the job prints from the second Index application, the problem is with the first application. Make sure you are using the current version of the driver for the problem application. Try printing again. www.lexmark.com Lexmark E320/E322 Printer...

  • Page 8: Step 2: Set Up To Print

    Network Port. Index Set up LexIP printing on Windows NT 4.0/2000 You can view this file online before you begin installing, or print the file to an alternate network printer that is already set up. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 9 Network Support (TCP/IP) When the list of printers is offered, select the model of the printer you want to install, Index and then click Add. When the printer appears in the Selected Printers list, click Next. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 10 Files are copied to the computer and printer objects are created in the Windows printers folder. A message appears when installation is complete. Index Part 2: Create a Network Port Click Start Settings Printers. Select the printer you just created. Click File Properties. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 11 Press the operator panel button with a brief button press to print a test page to verify printer installation. If the Printer Properties window is still open, click Print Test Page Index on the General tab. If you have closed the Printer Properties, do the following: Click Start Settings Printers. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 12 Launch the drivers CD. If you still have the CD running, click Back to return to the first Administration screen. Click Printer Software. Index Click the icon to install the version of software on the CD. Agree to the license agreement. Select Custom Install, and then click Next. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 13 On the Network Support tab, select TCP/IP. Index Note: If a shaded check mark is beside an option, support for that environment is already installed and will be updated with this installation. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 14 Enter the information to create the port. Assign a logical port name. This can be any name that reminds you of the printer such as “E322_lab4”. This name eventually appears in the list of available ports. Index www.lexmark.com Lexmark E320/E322 Printer...
  • Page 15 If you have closed the Printer Properties, do the following: Administration Click Start Settings Printers. Click File Properties. On the General tab, click Print Test Page. Index When a test page prints successfully, client setup is complete. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 16 Click the icon to install the version of software on the CD. Index Agree to the license agreement. Select Custom Install, and then click Next. When asked where you want the software installed, click Local Computer. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 17 On the Network Support tab, select TCP/IP. Index Note: If a shaded check mark is beside an option, support for that environment is already installed and will be updated with this installation. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 18 Enter the information to create the port. Assign a logical port name. This can be any name that reminds you of the printer such as “E322_lab4”. This name eventually appears in the list of available ports. Index www.lexmark.com Lexmark E320/E322 Printer...
  • Page 19 On the General tab, click Print Test Page. Index When a test page prints successfully, printer setup is complete. Part 3: Sharing the printer on the network Click Start Settings Printers. Select the printer you just created. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 20 – Browse Network Neighborhood. Find the host name of the server and look for the shared name you assigned to the printer. The printer is now shared and ready to be installed on network clients. Index www.lexmark.com Lexmark E320/E322 Printer...
  • Page 21 Setting up clients (peer-to-peer) Administration • The printer driver is fully installed on the client computer. Network clients retain control of driver modifications. • Client computer handles the print job processing. Index www.lexmark.com Lexmark E320/E322 Printer...
  • Page 22 Troubleshooting Print a test page to verify printer installation. Click Start Settings Printers. Administration Click File Properties. On the General tab, click Print Test Page. When a test page prints successfully, printer installation is complete. Index www.lexmark.com Lexmark E320/E322 Printer...
  • Page 23 Note: If this is a new printer, you may be prompted to install a printer driver. If no Index system driver is available, then you will need to provide a path to available drivers. Select whether you want this printer to be the default printer for the client, and then click Finish. www.lexmark.com Lexmark E320/E322 Printer...

  • Page 24: Troubleshooting

    (activated) in the print server. If TCP/IP is turned off, use the IPX protocol to activate it. Select the printer and then select the TCP/IP task. Check the Enable box to activate TCP/IP. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 25 Reset both the print server and the printer. Index If possible, shut down Windows NT Server and restart the server. There could be a spooler problem that requires a restart. Try printing again. www.lexmark.com Lexmark E320/E322 Printer...

  • Page 26: Novell Netware

    Install the Network Printer Utility for NetWare on the workstation. This software is located the following directory on the drivers CD that shipped with your printer (X=the drive letter of your CD-ROM drive). Index X:/Interwin/instwin.exe Double-click instwin.exe. Select your language, and then click OK. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 27 MarkNet print server is defined. You also need to create or select queues to be serviced. – If you want to manage bindery queues, you must first specify the file servers. Afterward, you must create or select queues to be serviced. www.lexmark.com Lexmark E320/E322 Printer...

  • Page 28: Choosing Nprinter/Rprinter Or Pserver

    NetWare servers. This print server obtains print jobs from queues located on one or more file Index servers. PSERVER print servers actually log into NetWare servers as a NetWare client and require one NetWare user license per PSERVER device. www.lexmark.com Lexmark E320/E322 Printer...

  • Page 29: Nprinter In Intranetware Nds

    This is inherent in the NetWare design. Index Notes about printing performance: Many people prefer to configure their print servers in PSERVER. In early versions of NetWare, PSERVER performance was significantly better than NPRINTER/RPRINTER performance. www.lexmark.com Lexmark E320/E322 Printer...

  • Page 30: Pserver In Intranetware Nds

    If printing is a significant part of your network traffic, and if network traffic is a proven concern for your network, you may find it better to use the print servers in PSERVER. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 31 RPRINTER vs. PSERVER in NetWare 3.x Print servers are fully supported in NetWare 3.x, using either RPRINTER or PSERVER. Administration RPRINTER in NetWare 3.x Advantage of using RPRINTER in NetWare 3.x: Index Does not require a NetWare server user license www.lexmark.com Lexmark E320/E322 Printer...
  • Page 32 In NPRINTER/RPRINTER, NetWare uses SPX to transfer packets. Packet size for Index data transmitted in SPX is 512 bytes. In PSERVER, NetWare uses IPX to transfer packets. Packet size for data transmitted in IPX is up to 1 Kilobyte for Ethernet networks. www.lexmark.com Lexmark E320/E322 Printer...

  • Page 33: Queue-Based Printing

    If you are having trouble with your print server on a NetWare network, do these steps in the order shown. Index Queue-based printing Press the operator panel button with a brief button press to print a network settings page. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 34 Make sure you are using the current version of the driver for the problem application. Place a job in the queue using a Novell utility such as PCONSOLE. Index www.lexmark.com Lexmark E320/E322 Printer...

  • Page 35: Finding The Default Appletalk Name

    AppleTalk for Zone. Index Select the new printer. If you don’t know which printer to select, look on the network setup page under AppleTalk. The default name of the printer is listed beside Name. Click Create. www.lexmark.com Lexmark E320/E322 Printer...

  • Page 36: Changing The Zone

    If you haven’t already done so, install MarkVision. On the drivers CD, click Install Index printer software. Do a Custom Install and select MarkVision. Launch MarkVision. Click View, and then Select Zones. Select the zone that contains the new printer. www.lexmark.com Lexmark E320/E322 Printer...

  • Page 37: Changing The Printer Name

    Select the zone that contains the new printer. Find the new printer in the list and highlight it. Index To specify the printer name you prefer, click Adapter Settings. Select Parallel from the settings pop-up list. Change the adapter name. www.lexmark.com Lexmark E320/E322 Printer...

  • Page 38: Updating Printer Hardware

    Select the Printing menu, and then select Change Setup. Index Select Auto Setup to automatically reconfigure the printer options. (Or, you can manually reconfigure the printer options if you want.) QuickDraw GX environment: Select the desktop printer object to be updated. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 39 If yes, make sure the printer name in the Chooser exactly matches the AppleTalk name listed on the network setup page. Check all connections. Check the cables on the back of the Macintosh workstation. Check the cable between the printer and the workstation or network. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 40 CD. These tips can save you a lot of time. To download the document to your workstation, launch the drivers CD, click Installer, select Documentation, and then Paper handling click Install. Look in the Extras folder for the document titled Optimize Printer Output. Maintenance Troubleshooting Administration Index www.lexmark.com Lexmark E320/E322 Printer...

  • Page 41: Print Server Light Patterns

    Setting up the network printer Printing Print server light patterns The four indicator lights on the print server indicate activity, status, and errors, depending on Paper handling the light pattern. Menu Maintenance Test Troubleshooting Administration Index www.lexmark.com Lexmark E320/E322 Printer...

  • Page 42: Normal Conditions

    Flash – you may Troubleshooting printer. damage the firmware. The lights cycle on and blinking Administration off, starting at the top and traveling blinks briefly down before blinking then returns reversing to Ready Index direction. www.lexmark.com Lexmark E320/E322 Printer...
  • Page 43 Setting up the network printer Printing In the following illustration, each binary number corresponds to an error light sequence: Paper handling Menu Maintenance Test Troubleshooting Administration Index www.lexmark.com Lexmark E320/E322 Printer...

  • Page 44: Error Conditions

    Status. If it shows the printer server is not binary 6 (for 1 sec) network. connected: repeat continuously. • Make sure the Ethernet cable is firmly plugged in. • Try another wall outlet. www.lexmark.com Lexmark E320/E322 Printer...
