what is included
Shock Sensor
Sensitivity
Adjustment
H1 Primary
Harness Port
(14-Pin Connector)
© 2001 Directed Electronics, Inc. Vista, CA
I The control module (see diagram)
I Two 470T Series remote transmitters
I Primary harness
I A plug-in status LED
I A plug-in Valet
®
switch
I An on-board shock sensor
I A back-up battery siren
I Two back-up battery siren keys
I A mercury tilt switch (for motorcycle installations)
Antenna
(2-Pin Connector)
White
LED Port
(2-Pin Connector)
Blue Valet
Switch Port
3
