Lightolier Lytespan 22GR6 Specification

Page 1 of 2
1 1/2 in
[40 mm]
1/2 in
[12 mm]
2 3/4 in
[67 mm]
Ordering Information
Catalog No. Finish
22GR6WH Matte White
22GR6BK
Matte Black
22GR6AL Metallic Aluminum
Features
1. Transformer: Class two electronic transformer for 12v halogen lamps
2. Track Attachment Fitting: Molded polycarbonate; rotates into track
3. Brass Contact: Extends for connection to second circuit
(Advent Lytespan track only)
4. Horizontal Pivot: Wireless stem profile with infinite horizontal rotation
5. Vertical Pivot: 0-90° vertical adjustment
6. Socket: Bi-pin multipoint contact low voltage halogen socket
7. Housing: Die cast aluminum
8. Frosted Glass: Included; rotate clockwise to attach
9. Glass Shield: Integral; For use with unshielded lamps
Finish
All Painted finishes are baked enamel.
Dimming
Use only dimmers specifically designed for use with electronic transformers.
Low voltage fixtures may produce audible sound when dimmed.
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2010 Philips Group • A0410
Lytespan
1
15/16 in
[24 mm]
4 3/4 in
[123 mm]
Mounting
All Lytespan Track Systems.
Does not mount on ProSpec Track.
Accessories
Accessory Holder: None
Lenses & Louvers:
Snoot Accessory:
Not permissible to use any more than one glass accessory
(lens or filter) at any time.
Labels
UL, cUL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Track Lighting System
®
Alcyon
3
2
5 3/4 in
[144 mm]
4 3/4 in
[119 mm]
4 1/4 in
[109 mm]
8
9
2 3/4 in
[69 mm]
Lamps
MR16 Lamp with out Integral lens, 50W Max
MR16 Lamp with integral lens 37W Max
None
None
Type:
22GR6
Glass Ring MR16
™
4
5
6
7
