Lightolier Lytespan 6298 Specification

Page 1 of 2
4" Max
3 1/4"
2 5/8"Sq.
TRUNION MOUNTING:
Tensioned, provides 90°
vertical adjustment for
lighting unit.
Catalog No. Finishes
6298
Matte White
6299 Matte Black
6297 Matte Black Framing Projector (For performance data see Lightolier Specification Sheet 6497)
Features
Compact Lytespot with unique rounded back fits close to ceiling, integrates
®
easily with most decor. Uses to wide range of MR-16 lamps to provide precisely
controlled beam spreads from narrow to wide. Lamp is deeply regressed to
eliminate glare. Die-cast matte black step baffle supports lamp and protective
glass lamp guard. Complete baffle/lamp assembly pulls out; spring-tension clips
allow fast snap-out, snap-in relamping. Unit adjusts horizontally and vertically
up to 90° for each side. May be used with color filter, spread lens and framing
projector accessories.
Finish
All painted finished baked enamel.
Electrical
Light-weight, electronic, low voltage transformer with integral radio frequency
interference filter; soft-start feature for longer lamp life. Constant output lamp
voltage to maintain rated lamp life and light output. Two-pin base socket, pre-
wired with No. 18 braided SF-1 leads with fiberglass braided outer sleeve.
PUSH TAB: Molded
Polycarbonate detaches unit.
LYTESPAN ATTACHMENT FITTING: Die-Cast aluminum.
Fitter twists onto track and locks on.
6 13/16"
Track Mounting
All Lytespan Track Systems
Lytespan
PIVOT MOUNTING:
Tensioned; 90° horizontal
stop for each side.
MOVABLE BRASS
CONTACT: Extends
for connection to 2nd circuit
in Advent Lytespan Track.
POLARITY KEYWAY
HOUSING: .040"
Aluminum.
LAMP GUARD
STEP BAFFLE:
Die-Cast aluminum with stepped conical
surface for low brightness. Matte black finish.
4 3/16"
Lamps Accessories
35W or 37W Max IR 2" Series Color Filters, Louver, Spread Lens
MR-16 12V (See Lightolier Specification Sheet 7472.
Dimming
For Dimming control, use only those dimmers specifically designed for use with
electronic transformers like Lightolier's Sunrise and Neptune Momentum QE
series. Call (800) 526-2731 for further information.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • C1106
Track Lighting
®
GeoStar
FRAMING PROJECTOR
ACCESSORY
(Order Separately)
(order separately)
Type:
www.lightolier.com
6298
Electronic
™
6 1/2"
