Page 1 of 2
Features
• Efficiency 56.7%.
• Flat blade louver with lens overlay and perforated curved side
blades.
• Seamless welded form: curved top and side reflectors are formed
together without any gaps or visual barriers.
• No visible welding, screws, latches, springs, hooks, rivets or plastic
supports.
• 95% reflective Alter soft white paint finish.
• 5-1/2" deep, one-piece body for easy installation.
• Choice of white microperforated blade, white solid blade or grey
solid blade.
• Easy access to ballast through lamp compartment.
• Fits standard T-grid, exposed slot T-grid ceilings and drywall
ceilings.
• Fully recessed luminaire and lamp compartment.
• Optional hold-down clips.
• Luminaire can be row mounted.
Mounting Methods / Features
Ceiling compatibility
Suite to standard T-grid ceilings
Microperforated mesh
white lamp shields
grey solid louver
Microperforated mesh
Microperforated mesh
white lamp shields
white lamp shields
white mesh louver
white solid louver
ALTER LOUVER
MICROPERFORATED MESH WHITE LAMP SHIELD/WHITE, MESH LOUVER
Suite to standard exposed slot
T-grid ceilings
QVS2GPFLV332
2'x4' RECESSED DIRECT/INDIRECT FLUORESCENT,
Dimensions
47-13/16"
(1214mm)
23-13/16"
(605mm)
Access Plate (2)
7/8" K.O.'S
23-13/16"(605mm)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
a Genlyte Thomas Company
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902
3 LAMP, T8, 5 1/2'' DEEP
23-7/8"
(606mm)
5-1/2"
(140mm)
Type:
www.lightolier.com
Folio L30-25
