Lightolier QVS2GPFLV317 Specification

Page 1 of 2
Features
• Efficiency 55.4%.
• Flat blade louver with lens overlay and perforated curved side blades.
• Seamless welded form: curved top and side reflectors are formed
together without any gaps or visual barriers.
• No visible welding, screws, latches, springs, hooks, rivets or plastic
supports.
• 95% reflective Alter soft white paint finish.
• 5-1/2" deep, one-piece body for easy installation.
• Choice of white microperforated blade, white solid blade or grey
solid blade.
• Easy access to ballast through lamp compartment.
• Fits standard T-grid, exposed slot T-grid ceilings and drywall ceilings.
• Fully recessed luminaire and lamp compartment.
• Optional hold-down clips.
• Luminaire can be row mounted.
Mounting Methods / Features
Ceiling compatibility
Suite to standard T-grid ceilings
Microperforated mesh
white lamp shields
grey solid louver
Microperforated mesh Microperforated mesh
white lamp shields white lamp shields
white mesh louver white solid louver
ALTER LOUVER
2' X 2' RECESSED DIRECT/INDIRECT FLUORESCENT, 3 LAMP, T8, 5 1/2" DEEP
MICROPERFORATED MESH WHITE LAMP SHIELD/WHITE, MESH LOUVER
Suite to standard exposed slot
T-grid ceilings
QVS2GPFLV317
Dimensions
23-13/16"
(605mm)
23-13/16"
(605mm)
23-13/16"(605mm)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
a Genlyte Thomas Company
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902
ACCESS
PLATE (2)
7/8" K.O.'S
11-7/8"
(302mm)
5-1/2"
(140mm)
Type:
www.lightolier.com
Folio L10-40
