Owner's Manual
READ AND SAVE THESE INSTRUCTIONS
DATE CODE:
The date code of this fan may be found on
the box, stamped in ink on a white label.
You should record this data above and keep
it in a safe place for future use.
CORNERSTONE
Ceiling Fan Owner's Manual
Part No. F40BP72500002
8
TM
TM
Model No.
CF1AB01
CF1WB01
CF1PW01
™
Series
27.0
Max. Weight:
Lbs.
With Blades
®
Form No. BP7250-2
Advertisement
Table of Contents
Related Manuals for Emerson CORNERSTONE CF1AB01
Summary of Contents for Emerson CORNERSTONE CF1AB01
- Page 1 READ AND SAVE THESE INSTRUCTIONS DATE CODE: The date code of this fan may be found on the box, stamped in ink on a white label. You should record this data above and keep it in a safe place for future use.
-
Page 2: Tools Needed For Assembly
6. Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do not know enough about electrical wiring, have your fan installed by a licensed electrician. WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically approved for this fan. -
Page 3: Unpacking Instructions
Emerson Company. Substitution of parts or accessories not designated for use with this product by Emerson Company could result in personal injury or property damage. 1. Open styrofoam unit containing fan. Remove top half of styrofoam unit. -
Page 4: Assembly Instructions
1. Remove the fan motor and housing assembly from styrofoam packaging and position it so that the top of the motor is facing you. 2.Remove the hanger ball from the downrod by loosening the setscrew in the hanger ball until the ball falls freely down the downrod (Figure 1). - Page 5 HANGER BALL DOWNROD Figure 6 10. The fan comes with blue, black and white leads that are 80” long. Before installing fan, measure up approximately 6 to 9-inches above the ball/ downrod assembly. Cut off excess leads and strip back insulation 1/2-inch from end of leads.
-
Page 6: How To Hang Your Ceiling Fan
Consult a qualified electrician if in doubt. If your fan is to replace an existing ceiling light fixture, turn electricity off at the main fuse box at this time and remove the existing light fixture. -
Page 7: How To Wire Your Ceiling Fan
NOTE: CEILING COVER OMITTED FOR CLARITY. Figure 4 Figure 15 NOTE: If you are using an Emerson Light Fixture with your fan, see Light Fixture Owner’s Manual for wiring. 2. Securely connect the fan motor white wire to the supply white (neutral) wire using wire connector OUTLET supplied (Figure 15). -
Page 8: Using Your Ceiling Fan
1. Restore electrical power to the outlet box by turning the electricity on at the main fuse box. 2. Check the operation of the fan by gently pulling on the 4-position speed control pull chain switch (Figure 17). The operating sequence is as follows:... -
Page 9: Maintenance
Emerson. Substitution of parts or accessories not designated for use with this product by Emerson could result in personal injury or property damage. Trouble Shooting PROBABLE CAUSE 1. -
Page 10: Repair Parts
Repair Parts Before discarding packaging material, be certain all parts have been removed. WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: How to Order Repair Parts • PART NUMBER • PART DESCRIPTION • NAME OF ITEM • MODEL NUMBER For repair parts, phone 1-800-654-3545. - Page 11 Aux. Capacitor Harness, Wiring Screw, #8 Washerhead, 8-32 x 3/8” (4) Bulb, Decorative Downrod, 18” Trim, Downrod Owner's Manual — Repair Parts Listing Part Numbers Model No. CF1AB01 761655-3 — — — 761620-3 762077 760601 — 762108 762109 761449 761621-3...
-
Page 12: Limited Warranty
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Air Comfort Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
