Lightolier Lytespan 8113 Specification

Page 1 of 2
9
8
6.25"
Catalog No. Finish
8113WH White
8113BK
Black
8113AL Aluminum
Features
1. Track Attachment Fitting: Molded polycarbonate, rotates into track.
2. Push Tab: Molded polycarbonate. Locks and detaches unit.
3. Track Adaptor Housing: Die-cast aluminum.
4. Movable Contact: Solid brass. Extends for connection to 2nd circuit in
Advent track.
5. Ballast Housing: Extruded aluminum housing with die-cast aluminum
end caps.
6. Ballast: High Power Factor metal halide electronic ballast. Thermally
protected, 0.64A maximum input current, 77W input power.
7. Tension Pivot Mounts: Allows for 350° horizontal and 180° vertical
rotation with tensioned mounts for controlled aim.
8. Lamp Housing: Die-cast aluminum.
9. Lampholder: 5kV (600V) pulse rated glazed porcelain body socket with
plated nickel screw shell and lamp contacts; 18AWG SEW-2 leads encased
in fiberglass sleeving.
Accessories
Holder: 8473, holds one accessory
Diffusion/ Special Filters: AF3 series
Color Filters: ADF3 series
Louver (Hex Cell): AL3HC
4
1
6.88"
7
Bottom View
Lamp
70W PAR30 CMH (M98) E26 base
Not Included
Lytespan
Step Spot Mini HID 70W PAR30 CMH
5.88"
Mounting
All Monopoint, Multipoint, recessed track, suspension track, suspension
stems, sloped ceiling adapter, Basic, Advent and Radius track systems only.
Ceiling and horizontal or vertical wall mounted. Not compatible with ProSpec
track system.
Finish
All painted finishes are baked powder or enamel.
Markings
cCSAus Certified for dry locations only.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • A0207
Track Lighting
®
2
3
5
6
4.63"
Type:
www.lightolier.com
8113
