Lightolier Tangent FXG9P Specification

Page 1 of 1
3
5
Ordering Information
Catalog No. Finish
FXG9P Silver
Features
1. Track Attachment fitting: Molded thermoplastic clamping adapter with
captive, nickel-plated steel pin. Clockwise rotation of pin secures fixture
adapter to track.
2. Splicing Chamber: Allows for field cutting of power cord.
3. Power Cord: 7/32" dia. cord with braided metal sleeving and a clear
coating; field cuttable; 6' max suspension.
4. Socket: Ceramic G9 halogen socket.
5. Lamp Husk: Die-cast aluminum with brushed finish; circular brim supports
shades.
Compatible with all Lytejacks shades.
Tangent
2
1 1/8 in
[28 mm]
4
Track Mountings
For use on all Tangent Track systems. For
ceiling or suspended track installation. Not
for use on wall mounted track.
Finish
All Painted finishes are baked enamel.
Accessories
No accessory capability.
Labels
cULus Listed
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • A0407
™
Track Lighting System
1 in
[27 mm]
1
3 3/8 in
[84 mm]
Lamps
120V T4 Halogen
G9 Base
40W Max
Frosted or Clear
Type:
a Genlyte company
FXG9P
G9 Pendant
www.lightolier.com
